Thickness detection sensor
Connector for double layer stacking of 2 machines
Connector + jumper for indication of the lower machine
6 orange LEDs for each output
7 green LEDs for each input
4 red LEDs for status/alarm (flashing) stand by – ice – full - wash
4.3. Alarms
They detect operational malfunctions. They are indicated with the flashing status LEDs LE1-4.
During some alarms a second operation retry attempt is carried out and if repeated again, the
Time alarm valuation jumper
Curtain micro relay contact jumper NC/NO
Water inlet valve e/w timeout
