Icom IC-2200H

Feb. 2010
8
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
C206 4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [EUR] T 101.2/55.6
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [TPE]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [USA]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [KOR]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [SEA]
4030011110 S.CER GRM31M2C2H9R0DV01L
(GRM42-6 CH) [THA]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [EXP]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [EUR-1]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [AUS]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [SEA-1]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [EXP-1]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [CHN]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [CHN-01]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [CHN-02]
C207 4510006021 ELE 16 ME 2200 HC
C208 4030011210 S.CER GRM31M2C2H330JV01L
(GRM42-6 CH) T 102.8/82.7
C209 4030011600 S.CER C1608 JB 1E 104K-T B 111/49.8
C210 4030011160 S.CER GRM31M2C2H150JV01L
(GRM42-6 CH) T 106.7/90.9
C211 4030006860 S.CER C1608 JB 1H 102K-T B 111/51.2
C212 4030006860 S.CER C1608 JB 1H 102K-T B 18.4/32.6
C215 4030011600 S.CER C1608 JB 1E 104K-T T 66.5/60.6
C216 4030011600 S.CER C1608 JB 1E 104K-T T 109.4/18
C217 4030011230 S.CER GRM31M2C2H390JV01L
(GRM42-6 CH) T 102.8/77.3
C218 4030011190 S.CER GRM31M2C2H270JV01L
(GRM42-6 CH) T 106.8/60.3
C221 4030010780 S.CER C1608 CH 1H 1R5C-T T 117.6/47.3
C222 4030006900 S.CER C1608 JB 1H 103K-T B 102/39.4
C224 4030011600 S.CER C1608 JB 1E 104K-T B 114.3/24.1
C225 4030017200 S.CER GRM31BR32J102KY01L T 106.8/57.7
C227 4030011210 S.CER GRM31M2C2H330JV01L
(GRM42-6 CH) T 106.8/65.5
C228 4030006900 S.CER C1608 JB 1H 103K-T T 75.1/17.6
C230 4510008540 S.ELE EEE1CA100SR [EUR] T 105.1/24.7
4510008540 S.ELE EEE1CA100SR [TPE]
4510008540 S.ELE EEE1CA100SR [USA]
4510008540 S.ELE EEE1CA100SR [KOR]
4510008540 S.ELE EEE1CA100SR [SEA]
4510008540 S.ELE EEE1CA100SR [THA]
4510008540 S.ELE EEE1CA100SR [EXP]
4510008540 S.ELE EEE1CA100SR [EUR-1]
4510008540 S.ELE EEE1CA100SR [CHN]
4510008540 S.ELE EEE1CA100SR [CHN-01]
C232 4030011600 S.CER C1608 JB 1E 104K-T B 100.1/13
C233 4030011600 S.CER C1608 JB 1E 104K-T B 107.4/11
C240 4030006860 S.CER C1608 JB 1H 102K-T B 66.2/30.6
C241 4030011600 S.CER C1608 JB 1E 104K-T B 78/23.1
C242 4030006860 S.CER C1608 JB 1H 102K-T B 48.5/34.8
C243 4030017810 S.CER C1608 CH 1H 102J-T B 78/27.4
C244 4030011600 S.CER C1608 JB 1E 104K-T B 99.7/26.6
C245 4030008680 S.CER C2012 JF 1C 105Z-T B 98.2/41
C246 4030006860 S.CER C1608 JB 1H 102K-T T 67.1/65.6
C247 4030006860 S.CER C1608 JB 1H 102K-T T 46.3/62.5
C250 4030007100 S.CER C1608 CH 1H 560J-T B 42/53.9
C251 4030006860 S.CER C1608 JB 1H 102K-T B 37.8/52.8
C252 4030006860 S.CER C1608 JB 1H 102K-T B 39.1/52.8
C253 4030007020 S.CER C1608 CH 1H 120J-T B 38.5/44.8
C254 4550006080 S.TAN TEESVB2 1C 106M8R B 35.5/54.3
C255 4030006860 S.CER C1608 JB 1H 102K-T T 84.4/48.9
C256 4030006860 S.CER C1608 JB 1H 102K-T T 90.5/53.7
C257 4030006860 S.CER C1608 JB 1H 102K-T T 83.7/52.3
C258 4030006860 S.CER C1608 JB 1H 102K-T T 90.5/55.1
C259 4030006860 S.CER C1608 JB 1H 102K-T T 84.9/35.2
C265 4030006860 S.CER C1608 JB 1H 102K-T T 102.2/5.2
C266 4030006860 S.CER C1608 JB 1H 102K-T T 110/16.1
C267 4030006860 S.CER C1608 JB 1H 102K-T T 111.8/4.9
C268 4030006900 S.CER C1608 JB 1H 103K-T T 105/5.2
C269 4030006900 S.CER C1608 JB 1H 103K-T T 106.9/13.4
C271 4550007610 S.TAN F931E474MAABMA T 102.6/14
C272 4030011600 S.CER C1608 JB 1E 104K-T T 104.3/13.4
C273 4550006480 S.TAN TEESVA 1C 475M8R T 111.8/9
C278 4510008580 S.ELE EEE0JA470SR T 25.1/16.8
C279 4510008550 S.ELE EEE1HA010SR T 23.3/24.2
C280 4340000250 S.MYL ECHU 1C 104JX5 B 23.6/26.4
C281 4510009160 S.ELE EEE1HA010NR T 88.1/14.3
C282 4030006860 S.CER C1608 JB 1H 102K-T B 98.5/65.5
C283 4030006860 S.CER C1608 JB 1H 102K-T B 97.2/65.5
C284 4030008880 S.CER C1608 JB 1H 223K-T B 14.4/9.9
C285 4030008920 S.CER C1608 JB 1H 473K-T [EUR] T 112.7/16.4
4030008920 S.CER C1608 JB 1H 473K-T [TPE]
4030008920 S.CER C1608 JB 1H 473K-T [USA]
4030008920 S.CER C1608 JB 1H 473K-T [KOR]
4030008920 S.CER C1608 JB 1H 473K-T [SEA]
4030008920 S.CER C1608 JB 1H 473K-T [THA]
4030008920 S.CER C1608 JB 1H 473K-T [EXP]
4030008920 S.CER C1608 JB 1H 473K-T [EUR-1]
4030008920 S.CER C1608 JB 1H 473K-T [CHN]
4030008920 S.CER C1608 JB 1H 473K-T [CHN-01]
C286 4030006860 S.CER C1608 JB 1H 102K-T B 104.4/44.7
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
C287 4030017810 S.CER C1608 CH 1H 102J-T B 25.9/7.4
C288 4030011810 S.CER C1608 JB 1A 224K-T B 86.9/58.1
C289 4030006860 S.CER C1608 JB 1H 102K-T T 66.5/16.9
C290 4030006860 S.CER C1608 JB 1H 102K-T T 77.8/24.2
C291 4030006860 S.CER C1608 JB 1H 102K-T T 64.1/17.3
C292 4030006860 S.CER C1608 JB 1H 102K-T T 70.8/11.8
C293 4030006860 S.CER C1608 JB 1H 102K-T B 87.8/48.6
C294 4030006860 S.CER C1608 JB 1H 102K-T B 87.3/62
C295 4030006850 S.CER C1608 JB 1H 471K-T T 35.6/64
C296 4030006860 S.CER C1608 JB 1H 102K-T T 82.5/46.8
C297 4030006860 S.CER C1608 JB 1H 102K-T B 86.9/60.7
C299 4030012600 S.CER C2012 JB 1A 105M-T T 51.2/7.6
C300 4030006860 S.CER C1608 JB 1H 102K-T T 80.5/53.5
C301 4030006860 S.CER C1608 JB 1H 102K-T T 75.2/55.6
C302 4030006860 S.CER C1608 JB 1H 102K-T T 70.9/57.4
C303 4030006860 S.CER C1608 JB 1H 102K-T
J4 6510025940 CON PJ-3047S <XIN>
J6 6510014961 S.CON B2B-ZR-SM4-TF(LF)(SN) T 28.7/39.1
J7 6510027740 CON HSJ2462-010010
J11 6510024241 S.CON 04-6274-036-000-800 T 78.3/7.2
W5 7030012290 JUM RDS2T0R0
EP1 6910012350 S.BEA MMZ1608Y 102BT B 65.2/25.2
EP2 6910012350 S.BEA MMZ1608Y 102BT B 69.4/25.2
EP3 6910012350 S.BEA MMZ1608Y 102BT T 23.4/90.4
EP4 6910012350 S.BEA MMZ1608Y 102BT T 22.2/87.7
EP5 6910012350 S.BEA MMZ1608Y 102BT B 76.3/1.6
EP6 6910012350 S.BEA MMZ1608Y 102BT B 77.6/1.6
EP7 6910012350 S.BEA MMZ1608Y 102BT T 64.6/19.1
EP8 6910012350 S.BEA MMZ1608Y 102BT B 73/16.8
EP11 6910000640 BEA FSRH090160RN000B
(FSOH090RN) [EUR]
6910000640 BEA FSRH090160RN000B
(FSOH090RN) [USA]
6910000640 BEA FSRH090160RN000B
(FSOH090RN) [EUR-1]
EP12 6910000640 BEA FSRH090160RN000B
(FSOH090RN) [EUR]
6910000640 BEA FSRH090160RN000B
(FSOH090RN) [USA]
6910000640 BEA FSRH090160RN000B
(FSOH090RN) [EUR-1]
