Icom IC-2200H

Feb. 2010
9
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
IC1 1130008351 S.IC LV2105V-TLM-E B 65.1/20
IC2 1130011760 S.IC CD4094BPWR T 59/6.5
IC4 1110007720 S.IC AA32416A <SLVJ> B 106/17.7
IC5 1190000350 S.IC M62363FP-650C B 86.5/17.5
IC6 1110004050 S.IC NJM3404AV-TE1-#FMZB B 90.5/49.5
IC7 1180001252 S.IC TA7808F(TE16L1,NQ) B 15.5/47.9
IC8 1180000970 S.IC AN78L05M-(E1) B 23.8/61.6
IC9 1110002550 IC TA7252AP
IC10 1150002182 IC S-AV36A(I,Q) [TPE-1]
1150002182 IC S-AV36A(I,Q) [KOR-1]
1150002182 IC S-AV36A(I,Q) [SEA-2]
1150002300 IC S-AV39(I,Q) [THA-1]
1150002182 IC S-AV36A(I,Q) [EXP-2]
1150002182 IC S-AV36A(I,Q) [AUS-1]
1150002182 IC S-AV36A(I,Q) [SEA-3]
1150002182 IC S-AV36A(I,Q) [EXP-3]
IC11 1110004050 S.IC NJM3404AV-TE1-#FMZB T 87.1/49.5
IC12 1130011781 S.IC SN74AHC2G53HDCT3 T 98.8/6.8
Q1 1530002851 S.TRA 2SC4116-BL(TE85R,F) B 33.4/38.2
Q2 1590001650 S.TRA XP4601(TX) B 34.8/17.3
Q3 1530002851 S.TRA 2SC4116-BL(TE85R,F) B 28.3/31.7
Q4 1530002851 S.TRA 2SC4116-BL(TE85R,F) B 76/21.3
Q5 1530002851 S.TRA 2SC4116-BL(TE85R,F) B 29.3/34.9
Q6 1530002920 S.TRA 2SC4226-T1 R25 T 34.8/25
Q7 1530002920 S.TRA 2SC4226-T1 R25 T 40.5/26
Q8 1590001040 S.TRA DTA113ZU T106 B 33.8/34.9
Q9 1530002920 S.TRA 2SC4226-T1 R25 T 50.2/26.2
Q10 1560000811 S.FET 2SK1069-4-TL-E T 50.1/35.9
Q11 1530002920 S.TRA 2SC4226-T1 R25 T 56.6/24.7
Q12 1530002920 S.TRA 2SC4226-T1 R25 T 55.4/18.5
Q13 1590000720 S.TRA DTA144EUA T106 [TPE-1] T 110.5/20
1590000720 S.TRA DTA144EUA T106 [KOR-1]
1590000720 S.TRA DTA144EUA T106 [SEA-2]
1590000720 S.TRA DTA144EUA T106 [THA-1]
1590000720 S.TRA DTA144EUA T106 [EXP-2]
Q14 1510000591 S.TRA 2SA1362-Y(TE85L,F) T 32.4/48.8
Q15 1530002851 S.TRA 2SC4116-BL(TE85R,F) T 38.5/50.6
Q16 1530003221 S.TRA 2SC4406-4-TL-E B 103.7/26.2
Q17 1530000370 S.TRA 2SC3356-T1B B 41.1/39.8
Q19 1580000731 S.FET 3SK293(TE85L,F) B 77.3/35.9
Q21 1590001010 S.TRA DTB113ZK T146 T 38.2/42.8
Q22 1590000430 S.TRA DTC144EUA T106 T 34.9/43.2
Q25 1590001010 S.TRA DTB113ZK T146 T 64.8/24.5
Q26 1590000720 S.TRA DTA144EUA T106 B 86.4/54.8
Q27 1580000731 S.FET 3SK293(TE85L,F) B 105.5/42
Q28 1530003910 S.TRA 2SC4684 (TE16L1 NQ) B 15.5/59.9
Q29 1530003091 S.TRA 2SC4213-B(TE85R,F) B 16.3/7.9
Q30 1510000890 S.TRA DTA143TU T106 T 23.8/64.1
Q31 1590001320 S.TRA DTC143ZUA T106 T 23.8/66.6
Q34 1530002851 S.TRA 2SC4116-BL(TE85R,F) B 103.9/11
Q35 1530003270 S.TRA 2SC4703-T1 SF B 44/50.7
Q36 1590001040 S.TRA DTA113ZU T106 T 101.7/10.1
Q37 1590001190 S.TRA XP6501-(TX).AB T 109.1/13.6
Q38 1590001190 S.TRA XP6501-(TX).AB T 108.4/6.6
Q39 1590000430 S.TRA DTC144EUA T106 B 83.3/53.1
Q40 1590000430 S.TRA DTC144EUA T106 B 86.2/52.2
Q41 1530003630 S.TRA 2SC4617 TLS B 16.6/10.2
#D12 1710001061 DIO L407CDB [EXP-2] only
#D19 1710001081 DIO L308CCB [EXP-2] only
#D20 1730000521 ZEN RD20E-AZ B2 [EXP-2] only
#D21 1790000700 DIO DSA3A1 [EXP-2] only
#D27 1710001061 DIO L407CDB [EXP-2] only
D1 1790001251 S.DIO MA2S1110GL B 35.3/38.2
D2 1750000721 S.VAR HVC375BTRF-E T 36.5/17
D3 1750000771 S.VAR HVC376BTRF-E T 87.8/21.3
D4 1720000730 S.VAR MA2S30400L T 36.5/18.3
D5 1720000730 S.VAR MA2S30400L T 41.5/18.2
D6 1790000620 S.DIO MA77(TX) B 53.1/32.9
D7 1790000620 S.DIO MA77(TX) B 64.4/32.3
D9 1750000711 S.VAR HVC350BTRF-E B 84.8/39.2
D10 1750000711 S.VAR HVC350BTRF-E B 88.7/39.2
D11 1750000711 S.VAR HVC350BTRF-E B 94/39.2
D12 1710001061 DIO L407CDB
D13 1750000711 S.VAR HVC350BTRF-E B 117.8/42.7
D14 1790000981 S.DIO MA3J7420GL T 107.2/69.9
D15 1750000550 S.DIO 1SS355 TE-17 T 117.9/48.9
D16 1710000871 S.DIO HVU131TRF-E T 117.9/50.7
D17 1790000981 S.DIO MA3J7420GL T 102.3/72.8
D18 1790001251 S.DIO MA2S1110GL B 93.9/45.2
D19 1710001081 DIO L308CCB
D20 1730000521 ZEN RD20E-AZ B2
D21 1790000700 DIO DSA3A1
D23 1790001251 S.DIO MA2S1110GL [TPE-1] B 117.1/24.1
1790001251 S.DIO MA2S1110GL [KOR-1]
1790001251 S.DIO MA2S1110GL [SEA-2]
1790001251 S.DIO MA2S1110GL [THA-1]
1790001251 S.DIO MA2S1110GL [EXP-2]
D24 1790001251 S.DIO MA2S1110GL [TPE-1] T 108.8/25.8
1790001251 S.DIO MA2S1110GL [KOR-1]
1790001251 S.DIO MA2S1110GL [SEA-2]
1790001251 S.DIO MA2S1110GL [THA-1]
1790001251 S.DIO MA2S1110GL [EXP-2]
D25 1790001251 S.DIO MA2S1110GL [TPE-1] T 111.4/17.3
1790001251 S.DIO MA2S1110GL [KOR-1]
1790001251 S.DIO MA2S1110GL [SEA-2]
1790001251 S.DIO MA2S1110GL [THA-1]
1790001251 S.DIO MA2S1110GL [EXP-2]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
D26 1790001251 S.DIO MA2S1110GL [TPE-1] B 116.3/22.8
1790001251 S.DIO MA2S1110GL [KOR-1]
1790001251 S.DIO MA2S1110GL [SEA-2]
1790001251 S.DIO MA2S1110GL [THA-1]
1790001251 S.DIO MA2S1110GL [EXP-2]
D27 1710001061 DIO L407CDB
D29 1750000370 S.DIO DA221 TL B 98.8/28.5
D30 1750000550 S.DIO 1SS355 TE-17 B 38.2/46.4
D38 1720000730 S.VAR MA2S30400L T 40.2/15.5
D39 1750001820 S.DIO LRB706F-40T1G <SLVJ> B 105/24
FI1 2020002380 CER LT450FW <JJE>
FI2 2020002510 CER LTW450HT <JJE> [TPE-1]
2020002510 CER LTW450HT <JJE> [KOR-1]
2020002510 CER LTW450HT <JJE> [SEA-2]
2020002510 CER LTW450HT <JJE> [THA-1]
2020002510 CER LTW450HT <JJE> [EXP-2]
FI3 2030000270 MON MCF21R15AB 21.7 MHz (FL-363)
FI4 2030000270 MON MCF21R15AB 21.7 MHz (FL-363)
X1 6050011871 S.XTA CR-779A SX-2112 21.250 MHz T 81.9/19.5
X2 6070000290 DIS JTB450C24 <JJE>
L1 6200009351 S.COI ELJRE R22GFA T 39.4/18
L2 6200003550 S.COI MLF1608A 4R7K-T T 36.4/15.1
L3 6200001620 S.COI ELJFC 1R0K-F B 45.9/31.6
L6 6200009920 S.COI C2012C-R10G-A T 34/20
L7 6200010570 S.COI C6342A-R11J-A T 45.9/19.3
L8 6200004870 S.COI ELJFC 2R7K-F T 37.7/27
L9 6200004880 S.COI ELJFC 3R3K-F T 44.6/25.5
L10 6200001620 S.COI ELJFC 1R0K-F B 45.9/29.1
L11 6200009351 S.COI ELJRE R22GFA T 50.2/28.1
L12 6200009351 S.COI ELJRE R22GFA T 55.4/28.2
L13 6200006981 S.COI ELJRE R10GFA T 57.6/21.2
L14 6200006991 S.COI ELJRE 56NGFA B 56.2/27.8
L15 6200007001 S.COI ELJRE 82NGFA T 56.3/15.8
L18 6200005731 S.COI ELJRE 39NGFA B 46.4/38.4
L19 6200004920 S.COI MLF1608A 2R2K-T B 103.8/22
L20 6200005741 S.COI ELJRE 47NGFA B 73/34.1
L21 6200006671 S.COI ELJRE 68NGFA B 41.3/42.2
L22 6200006981 S.COI ELJRE R10GFA B 75.1/33.4
L25 6200003281 S.COI NLV25T-2R2J B 77.6/30.6
L31 6200009890 S.COI C2012C-82NG-A T 84.6/41.6
L32 6200009890 S.COI C2012C-82NG-A T 90.1/41.7
L37 6200010050 S.COI AS080547-47N T 112.5/62.9
L38 6200009930 S.COI C2012C-68NG-A T 100.2/43
L39 6200010050 S.COI AS080547-47N T 112.6/73
L40 6200010420 S.COI FHW1210HC 1R0JGT <JJE> T 84/61.9
L42 6200007370 S.COI ELJFC R82K-F B 105/66.9
L43 6200013020 S.COI 0.25-1.9-7TL 61N <COMO> T 114.7/45.2
L45 6200012760 S.COI 0.35-1.6-7TL 37.5N <COMO> T 114.1/52
L46 6200010060 S.COI AS080647-56N T 106.2/51.4
L47 6200010060 S.COI AS080647-56N T 108.6/79.8
L48 6200010060 S.COI AS080647-56N T 109.5/86.6
L52 6200002631 S.COI NLV25T-R10J B 113.8/44.6
L56 6200006671 S.COI ELJRE 68NGFA B 39.8/50.7
L57 6190001690 S.COI ZBFS5105-PT-01 T 77.6/68.8
L58 6190001690 S.COI ZBFS5105-PT-01 T 77.6/65.5
L59 6190001690 S.COI ZBFS5105-PT-01 T 77.6/62.2
L60 6190001690 S.COI ZBFS5105-PT-01 T 77.6/58.9
L61 6200003640 S.COI MLF1608E 100K-T T 79.7/56.6
L62 6200003640 S.COI MLF1608E 100K-T T 73.9/56.3
R1 7030003660 S.RES ERJ3GEYJ 683 V (68K) T 32.9/14.9
R2 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 91.2/16.6
R3 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 92.5/16.6
R4 7030003310 S.RES ERJ3GEYJ 820 V (82) T 33.7/17
R5 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 36.6/38.2
R6 7030003400 S.RES ERJ3GEYJ 471 V (470) B 39.2/13.7
R7 7510001661 S.THR NTCG16 4LH 473JT T 69.3/17.5
R8 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 70.1/20.7
R9 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 74.3/16.8
R10 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 88.8/17.9
R11 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 75.6/16.8
R12 7030003320 S.RES ERJ3GEYJ 101 V (100) B 49.4/10.8
R13 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) B 32.6/17.2
R14 7030003800 S.RES ERJ3GEYJ 105 V (1M) B 37.1/17.1
R15 7030003730 S.RES ERJ3GEYJ 274 V (270K) B 56.9/22.2
R16 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 28.4/28.5
R17 7030003720 S.RES ERJ3GEYJ 224 V (220K) B 78/20.3
R18 7030003390 S.RES ERJ3GEYJ 391 V (390) B 54.9/18.9
R19 7030003550 S.RES ERJ3GEYJ 822 V (8.2K) T 35/21.8
R20 7030003530 S.RES ERJ3GEYJ 562 V (5.6K) T 42.7/23.1
R21 7030003320 S.RES ERJ3GEYJ 101 V (100) B 59.8/17.6
R22 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 31.4/34.9
R23 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 35/23.1
R24 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 72.8/22.7
R25 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 40.4/24.1
R26 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 79.3/20.3
R27 7030003470 S.RES ERJ3GEYJ 182 V (1.8K) T 32.9/27
R28 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 36.6/29.5
R29 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 54.9/21.9
R30 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) T 38.3/23.8
R31 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 47.3/23.9
R32 7030003200 S.RES ERJ3GEYJ 100 V (10) T 44.4/29.3
R33 7030003200 S.RES ERJ3GEYJ 100 V (10) T 44.4/28
R34 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 46.6/27.3
R35 7030003380 S.RES ERJ3GEYJ 331 V (330) T 50.2/29.4
R36 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 47.9/35.7
R37 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 48.9/40.4
R39 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 54.7/26.1
