Icom IC-2800 - Page 24

S.=Surface mount
R103 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R104 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R105 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R106 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R107 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R108 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R109 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R110 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R111 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R112 7030000180 S.RESISTOR MCR10EZHJ 22 Ω (220)
R113 7030000180 S.RESISTOR MCR10EZHJ 22 Ω (220)
R114 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R115 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R116 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R117 7030001050 S.RESISTOR MCR50JZHJ 22 Ω (220)
R118 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R119 7310003580 S.TRIMMER EVM-1XSX50 B15 (104)
R120 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R121 7310003580 S.TRIMMER EVM-1XSX50 B15 (104)
R122 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R123 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R124 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R125 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R126 7030003790 S.RESISTOR ERJ3GEYJ 824 V (820 kΩ)
R127 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R128 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R129 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R130 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R131 7030001190 S.RESISTOR MCR50JZHJ 330 Ω (331)
R132 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R133 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R134 7030001130 S.RESISTOR MCR50JZHJ 100 Ω (101)
R135 7030000280 S.RESISTOR MCR10EZHJ 150 Ω (151)
R136 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R137 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R138 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R139 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R140 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R141 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R142 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R143 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R144 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R145 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R146 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R147 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R148 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R149 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R150 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R151 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R152 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R153 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R154 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R155 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R156 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R157 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R158 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R159 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R160 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R162 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R163 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R164 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R165 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R166 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R167 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R168 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R169 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R170 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R171 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R172 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R173 7030000280 S.RESISTOR MCR10EZHJ 150 Ω (151)
R174 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R175 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 kΩ)
R176 7030003820 S.RESISTOR ERJ3GEYJ 155 V (1.5 MΩ)
R177 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R178 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R179 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R180 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
R181 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R182 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R183 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R184 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω)
R185 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω)
6 - 7
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
R186 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R187 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω)
R188 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R189 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R190 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R191 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R192 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R193 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R194 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
[EUR], [ITA]
7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) other
R195 7510001180 S.THERMISTOR NTCCM1608 3NH 221KC
R196 7310003610 S.TRIMMER EVM-1XSX50 B14 (103)
R197 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
[EUR], [ITA] only
R198 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
[EUR], [ITA]
7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) other
R199 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R200 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R201 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R202 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R203 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
[EUR], [ITA]
7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) other
R204 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R205 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
[EUR], [ITA] only
R206 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
[EUR], [ITA] only
R207 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
[EUR], [ITA] only
R208 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
[EUR], [ITA] only
R209 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R210 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R211 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R212 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R213 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R214 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R215 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R216 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R217 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R219 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R220 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R221 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R222 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R223 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R224 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R225 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R226 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R227 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R228 7510001250 S.THERMISTOR NTCCM1608 3NH 471KC
R229 7310003610 S.TRIMMER EVM-1XSX50 B14 (103)
R230 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R231 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R232 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R233 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R234 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R235 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R236 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R237 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R238 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R239 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R240 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R241 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R242 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R244 7030009550 S.RESISTOR ERJ3EKF 1203 V (120 kΩ)
R245 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R246 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R247 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R248 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R249 7030003270 S.RESISTOR ERJ3GEYJ 390 V (39 Ω)
R250 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R251 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R252 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R253 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R254 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R255 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R256 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R257 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R258 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
