[MAIN UNIT]
C332 4030017460 S.CERAMIC ECJ0EB1E102K T
C333 4030017730 S.CERAMIC ECJ0EB1E471K T
C334 4030016930 S.CERAMIC ECJ0EB1A104K T
C335 4030017440 S.CERAMIC ECJ0EC1H221J T
C336 4030017450 S.CERAMIC ECJ0EB1E271K T
C337 4030011810 S.CERAMIC C1608 JB 1A 224K-T T
C338 4030017730 S.CERAMIC ECJ0EB1E471K B
C339 4030017720 S.CERAMIC ECJ0EB1H331K T
C340 4030008680 S.CERAMIC C2012 JF 1C 105Z-T T
C341 4030008680 S.CERAMIC C2012 JF 1C 105Z-T B
C343 4550006390 S.TANTALUM TEESVA 1C 335M8L T
C344 4030016950 S.CERAMIC ECJ0EB1A473K T
C345 4030017730 S.CERAMIC ECJ0EB1E471K T
C346 4030017430 S.CERAMIC ECJ0EC1H101J T
C347 4510004630
S.ELECTROLYTIC
ECEV1CA100SR T
C348 4510005860
S.ELECTROLYTIC
ECEV1HA2R2SR T
C349 4030017460 S.CERAMIC ECJ0EB1E102K B
C350 4030016930 S.CERAMIC ECJ0EB1A104K B
C351 4030016930 S.CERAMIC ECJ0EB1A104K T
C352 4030016930 S.CERAMIC ECJ0EB1A104K B
C354 4510005430
S.ELECTROLYTIC
ECEV0JA220SR T
C355 4030017780 S.CERAMIC ECJ0EB1E472K T
C356 4030016930 S.CERAMIC ECJ0EB1A104K T
C357 4030017730 S.CERAMIC ECJ0EB1E471K T
C358 4550006880 S.TANTALUM TEESVD2 0J 157M12R T
C359 4030017720 S.CERAMIC ECJ0EB1H331K T
C360 4030017460 S.CERAMIC ECJ0EB1E102K T
C361 4030017730 S.CERAMIC ECJ0EB1E471K T
C362 4030016930 S.CERAMIC ECJ0EB1A104K B
C363 4030017460 S.CERAMIC ECJ0EB1E102K T
C364 4550006250 S.TANTALUM TEESVA 1A 106M8L T
C365 4030016930 S.CERAMIC ECJ0EB1A104K B
C366 4030016930 S.CERAMIC ECJ0EB1A104K T
C367 4030017730 S.CERAMIC ECJ0EB1E471K T
C368 4030017720 S.CERAMIC ECJ0EB1H331K B
C369 4030017730 S.CERAMIC ECJ0EB1E471K T
C371 4030017720 S.CERAMIC ECJ0EB1H331K B
C372 4030016930 S.CERAMIC ECJ0EB1A104K T
C373 4030017460 S.CERAMIC ECJ0EB1E102K T
C374 4030017420 S.CERAMIC ECJ0EC1H470J B
C375 4030017730 S.CERAMIC ECJ0EB1E471K T
C376 4550006250 S.TANTALUM TEESVA 1A 106M8L T
C377 4030017720 S.CERAMIC ECJ0EB1H331K T
C378 4030016930 S.CERAMIC ECJ0EB1A104K B
C379 4030017730 S.CERAMIC ECJ0EB1E471K T
C380 4030017730 S.CERAMIC ECJ0EB1E471K T
C381 4030017730 S.CERAMIC ECJ0EB1E471K B
C382 4030016790 S.CERAMIC ECJ0EB1C103K B
C383 4030016930 S.CERAMIC ECJ0EB1A104K B
C384 4030016790 S.CERAMIC ECJ0EB1C103K T
C385 4030017460 S.CERAMIC ECJ0EB1E102K B
C386 4030017460 S.CERAMIC ECJ0EB1E102K B
C387 4030017460 S.CERAMIC ECJ0EB1E102K B
C388 4030017460 S.CERAMIC ECJ0EB1E102K B
C389 4030016930 S.CERAMIC ECJ0EB1A104K T
C390 4030008680 S.CERAMIC C2012 JF 1C 105Z-T T
C392 4030017460 S.CERAMIC ECJ0EB1E102K B
C393 4030017460 S.CERAMIC ECJ0EB1E102K B
C394 4030017460 S.CERAMIC ECJ0EB1E102K B
C395 4030017460 S.CERAMIC ECJ0EB1E102K B
C396 4030017460 S.CERAMIC ECJ0EB1E102K B
C397 4030016930 S.CERAMIC ECJ0EB1A104K T
C398 4030017720 S.CERAMIC ECJ0EB1H331K T
C399 4030017790 S.CERAMIC ECJ0EB1E682K T
C400 4030017460 S.CERAMIC ECJ0EB1E102K B
C401 4030017780 S.CERAMIC ECJ0EB1E472K T
C402 4030016780 S.CERAMIC ECJ0EB1C153K B
J300 6510023500 S.CONNECTOR AXK6S20545P T
J301 6450001060 CONNECTOR HSJ1493-01-010 T
J302 6450002130 CONNECTOR 04-730A2-02BKA T
J303 6450000130 CONNECTOR HSJ1102-01-540 T
DS300 5030002520 LCD L2-0494TAY B
DS301 5040002230 S.LED CL-200YG-C-TS B
MC300 7700002160 MICROPHON KUC3523-040245 B
S304 2260001900 SWITCH SW-149 (SKHLLD) T
W300 7030010040 S.RESISTOR ERJ2GE-JPW T
W301 7030010040 S.RESISTOR ERJ2GE-JPW B
W302 7120000470 JUMPER ERDS2T0 T
S.=Surface mount
6 - 2
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
W305 7030010040 S.RESISTOR ERJ2GE-JPW T
W307 7030010040 S.RESISTOR ERJ2GE-JPW B
EP1 0910056431 PCB B 6003A
EP300 6910012350 S.BEAD MMZ1608Y 102BT B
EP301 6910014690 S.BEAD MPZ1608S221A-T B
EP302 6910014690 S.BEAD MPZ1608S221A-T B
EP303 6910012350 S.BEAD MMZ1608Y 102BT B
EP304 6910012350 S.BEAD MMZ1608Y 102BT B
EP305 6910012350 S.BEAD MMZ1608Y 102BT B
EP306 6910012350 S.BEAD MMZ1608Y 102BT B
EP307 6910012350 S.BEAD MMZ1608Y 102BT B
EP308 6910012350 S.BEAD MMZ1608Y 102BT B
EP309 8930059580 LCD CONTACT SRCN-2628-SP-N-W B
IC1 1110003490 S.IC TA31136FN (D,EL) B
IC2 1130007610 S.IC µPD3140GS-E1 (DS8) B
IC3 1190001830 S.IC BH2220FVM-TR T
Q1 1530002930 S.TRANSISTOR 2SC4228 (M) -T1 R45 T
Q2 1580000740 S.FET 3SK320 (TE85L) B
Q3 1530002600 S.TRANSISTOR 2SC4215-O (TE85R) B
Q4 1560001270 S.FET 2SK3078A (TE12L) B
Q5 1530000370 S.TRANSISTOR 2SC3356-T1B B
Q6 1530002940 S.TRANSISTOR 2SC4228-T1 R44 B
Q7 1530003320 S.TRANSISTOR 2SC5108-Y (TE85R) T
Q8 1530003320 S.TRANSISTOR 2SC5108-Y (TE85R) T
Q9 1530003010 S.TRANSISTOR 2SC4117-GR (TE85R) T
Q10 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R) T
Q11 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R) T
Q12 1590001450 S.FET 2SJ144-GR (TE85R) T
Q13 1530002920 S.TRANSISTOR 2SC4226-T1 R25 B
Q14 1530003090 S.TRANSISTOR 2SC4213-B (TE85R) T
D1 1790001620 S.DIODE 1SV308 (TPL3) B
D2 1790001620 S.DIODE 1SV308 (TPL3) T
D3 1790001620 S.DIODE 1SV308 (TPL3) T
D4 1790001620 S.DIODE 1SV308 (TPL3) T
D5 1790001240 S.DIODE MA2S728-(TX) B
D6 1790001260 S.DIODE MA2S077-(TX) B
D7 1790001260 S.DIODE MA2S077-(TX) B
D8 1720000640 S.VARICAP 1SV284 (TPH3) T
D9 1720000640 S.VARICAP 1SV284 (TPH3) T
D10 1790001250 S.DIODE MA2S111-(TX) T
D11 1790001250 S.DIODE MA2S111-(TX) T
D12 1750000770 S.VARICAP HVC376BTRF T
FI2 2010002320 MONOLITH FL-297 (21.700 MHz) B
FI3 2020001410 CERAMIC CFWLB450KGFA-B0 T
FI4 2040001580 S.SAW NSVS647 T
X1 6070000190
S.DISCRIMINATOR
CDBCB450KCAY24-R0 T
X2 6050010900 S.XTAL CR-669 (21.2500 MHz) T
L2 6200008270 S.COIL 0.26-1.0-5TL 17N B
L3 6200008270 S.COIL 0.26-1.0-5TL 17N B
L4 6200005710 S.COIL ELJRE 27NG-F B
L5 6200001650 S.COIL ELJNC 18NK-F T
L6 6200002470 S.COIL ELJNC 12NK-F T
L7 6200009980 S.COIL C2012C-18NG T
L8 6200005710 S.COIL ELJRE 27NG-F B
L9 6200003280 S.COIL NL 252018T-2R2J B
L10 6200004480 S.COIL MLF1608D R82K-T B
L11 6200010500 S.COIL 0.3-1.1-3TR 9.5N B
L12 6200008680 S.COIL 0.26-0.8-3TR 6.8N B
L13 6200005720 S.COIL ELJRE 33NG-F B
L14 6200005700 S.COIL ELJRE 22NG-F B
L15 6200005700 S.COIL ELJRE 22NG-F B
L18 6200003640 S.COIL MLF1608E 100K-T T
L19 6200007000 S.COIL ELJRE 82NG-F T
L20 6200005720 S.COIL ELJRE 33NG-F T
L21 6200002350 S.COIL LQW31HN27NJ01L T
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
[RF UNIT]
