Icom IC-4088SR - Section 6 Parts List

[MAIN UNIT][MAIN UNIT]
IC300 1130011230 S.IC BR24C02FV-WE2 T
IC301 1140011430 S.IC
µPD789407AGK-A81-9EU (FX2624A3) B
IC302 1110005820 S.IC R3112N281A-TR T
IC303 1180002430 S.REG R1121N301B-TR T
IC304 1130007382 S.IC AK2342B T
IC305 1110002810 S.IC NJM2070M-T1 T
Q302 1590001330 S.TRANSISTOR DTA114EUA T106 B
Q303 1590002490 S.TRANSISTOR UMZ2N TR T
Q304 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R) T
Q305 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R) B
Q306 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R) T
Q307 1510000580 S.TRANSISTOR 2SA1362-GR (TE85R) T
Q308 1520000200 S.TRANSISTOR 2SB798-T2 DK B
Q309 1590001050 S.TRANSISTOR DTC114TUA T106 T
Q310 1590001040 S.TRANSISTOR DTA113ZU T106 T
Q311 1530003090 S.TRANSISTOR 2SC4213-B (TE85R) B
Q312 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q313 1560000840 S.FET 2SK1829 (TE85R) T
Q314 1520000450 S.TRANSISTOR 2SB1132 T100 Q T
Q315 1590002950 S.FET HAT1023R-EL T
Q316 1590001390 S.FET 2SJ144-Y (TE85R) B
Q317 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q318 1590000850 S.TRANSISTOR DTC114YUA T106 T
Q319 1590001650 S.TRANSISTOR XP4601 (TX) B
D301 1790001250 S.DIODE MA2S111-(TX) T
D302 1790001250 S.DIODE MA2S111-(TX) B
D303 1790001250 S.DIODE MA2S111-(TX) B
D305 1790000670 S.DIODE SB07-03C-TB T
D306 1750000880 S.DIODE RB551V-30TE-17 B
D307 1790001240 S.DIODE MA2S728-(TX) B
D308 1790000860 S.DIODE MA133 (TX) T
D310 1790001250 S.DIODE MA2S111-(TX) T
D313 1790001250 S.DIODE MA2S111-(TX) T
D314 1790001250 S.DIODE MA2S111-(TX) T
D317 1790001250 S.DIODE MA2S111-(TX) T
D318 1750000880 S.DIODE RB551V-30TE-17 T
X300 6050008860 S.XTAL CR-465 (3.6864 MHz) B
R300 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R301 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R304 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) B
R305 7030009290 S.RESISTOR ERJ2GEJ 562 X (5.6 kΩ) B
R307 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R308 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R327 7030005700 S.RESISTOR ERJ2GEJ 274 X (270 kΩ) B
R328 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R329 7030005310 S.RESISTOR ERJ2GEJ 124 X (120 kΩ) T
R330 7030003880 S.RESISTOR ERJ3GEYJ 244 V (240 kΩ) T
R331 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R332 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ) T
R333 7030009290 S.RESISTOR ERJ2GEJ 562 X (5.6 kΩ) B
R334 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ) B
R335 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) B
R338 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ) B
R340 7030008410 S.RESISTOR ERJ2GEJ 392 X (3.9 kΩ) B
R343 7030005590 S.RESISTOR ERJ2GEJ 680 X (68 Ω) B
R344 7030005720 S.RESISTOR ERJ2GEJ 563 X (56 kΩ) T
R345 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R346 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) T
R347 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω) T
R348 7030003880 S.RESISTOR ERJ3GEYJ 244 V (240 kΩ) T
R349 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R350 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) B
R356 7030005600 S.RESISTOR ERJ2GEJ 273 X (27 kΩ) T
R357 7030005720 S.RESISTOR ERJ2GEJ 563 X (56 kΩ) T
R358 7030005720 S.RESISTOR ERJ2GEJ 563 X (56 kΩ) T
R359 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R360 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R361 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) T
R362 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R364 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R365 7510001440 S.THERMISTOR NTCG16 3NH 221KT T
R366 7030009140 S.RESISTOR ERJ2GEJ 272 X (2.7 kΩ) T
R368 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ) T
S.=Surface mount
R369 7030007570 S.RESISTOR ERJ2GEJ 122X (1.2 kΩ) B
R373 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ) T
R374 7030009140 S.RESISTOR ERJ2GEJ 272 X (2.7 kΩ) T
R375 7030007310 S.RESISTOR ERJ2GEJ 155 X (1.5 MΩ) T
R376 7030007570 S.RESISTOR ERJ2GEJ 122X (1.2 kΩ) T
R377 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ) B
R378 7030005230 S.RESISTOR ERJ2GEJ 334 X (330 kΩ) T
R379 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω) B
R381 7030005600 S.RESISTOR ERJ2GEJ 273 X (27 kΩ) T
R382 7030008010 S.RESISTOR ERJ2GEJ 123 X (12 kΩ) T
R383 7030005710 S.RESISTOR ERJ2GEJ 121 X (120 Ω) T
R384 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R385 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω) T
R386 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) T
R387 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R388 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) T
R389 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) T
R390 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R391 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R392 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R393 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω) T
R394 7030009290 S.RESISTOR ERJ2GEJ 562 X (5.6 kΩ) T
R395 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R396 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) T
R397 7030000130 S.RESISTOR MCR10EZHJ 8.2 Ω (8R2) T
R399 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) T
R400 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R401 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R402 7030007300 S.RESISTOR ERJ2GEJ 332 X (3.3 kΩ) T
R403 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R404 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ) B
R405 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R406 7210001970 VARIABLE RV-244 (RK0971110) 10KA T
R409 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R410 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R411 7030008280 S.RESISTOR ERJ2GEJ 271 X (270 Ω) B
R412 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R413 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R414 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R415 7510001660 S.THRMISTOR NTCG16 4LH 473KT B
R416 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R417 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R418 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R419 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R420 7030007320 S.RESISTOR ERJ2GEJ 225 X (2.2 MΩ) T
R421 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R422 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R423 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) T
R424 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R426 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ) T
R427 7030007320 S.RESISTOR ERJ2GEJ 225 X (2.2 MΩ) B
R428 7030007060 S.RESISTOR ERJ2GEJ 684X (680 kΩ) T
R430 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ) T
R431 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) T
R432 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R433 7030005600 S.RESISTOR ERJ2GEJ 273 X (27 kΩ) T
C300 4030017410 S.CERAMIC ECJ0EC1H240J B
C301 4030017410 S.CERAMIC ECJ0EC1H240J B
C303 4030016790 S.CERAMIC ECJ0EB1C103K B
C304 4030016930 S.CERAMIC ECJ0EB1A104K T
C311 4030016930 S.CERAMIC ECJ0EB1A104K B
C312 4030016930 S.CERAMIC ECJ0EB1A104K T
C313 4030017430 S.CERAMIC ECJ0EC1H101J B
C314 4030016930 S.CERAMIC ECJ0EB1A104K T
C315 4550006620 S.TANTALUM ECST0JY226R T
C316 4030009660 S.CERAMIC C1608 JF 1C 224Z-T B
C317 4030016930 S.CERAMIC ECJ0EB1A104K T
C319 4030016930 S.CERAMIC ECJ0EB1A104K T
C320 4030008680 S.CERAMIC C2012 JF 1C 105Z-T T
C321 4030008680 S.CERAMIC C2012 JF 1C 105Z-T B
C323 4030017040 S.CERAMIC ECJ0EB1A333K T
C324 4030016930 S.CERAMIC ECJ0EB1A104K T
C325 4030008680 S.CERAMIC C2012 JF 1C 105Z-T B
C326 4030008680 S.CERAMIC C2012 JF 1C 105Z-T B
C327 4030017720 S.CERAMIC ECJ0EB1H331K T
C328 4510005900
S.ELECTROLYTIC ECEV0GA101SR T
C329 4030017420 S.CERAMIC ECJ0EC1H470J T
C330 4030016930 S.CERAMIC ECJ0EB1A104K T
C331 4030016930 S.CERAMIC ECJ0EB1A104K T
6 - 1
SECTION 6 PARTS LIST
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
