OmniRig Setup for the IC-7000 series transceivers
To enter setup menu in MDSR-SA, select the tool icon at the bottom right
and select “OmniRig Configuration & Status”, select the key icon
“Configure OmniRig”. Only configure RIG 1.
• Select the transceiver to be controlled
from the drop down menu.
• Select the port of the computer. If the
Com port is not known, go to the
“Device Manager” and select the ports
icon. The port number should be listed
there.
• The Baud Rate has to match the
setting in the Transceiver. The default
setting for the IC-7000 is “auto”. The
highest rate is 19200.
• All the other settings should be as
displayed here.
o
That completes the installation of the LIF port of the FT-950. The MDSR team
wishes you all the best. If you like the performance of the MDSR software please
tell all your friends about it.
73
The MDSR development team
To order the PCB kit or for more information please go to;
Note: if you are interested in the TX – BiLiF option contact VE7DXW directly.
http://users.skynet.be/myspace/mdsr
specify: 455kHz IF

Icom IC-7000 Specifications

General

Input voltage	13.8 V
Microphone included	Yes
Product type	Portable CB radio
Product color	Black
Housing material	-
Frequency range	0.5 - 455000 MHz
Channels quantity	503 channels

Weight and Dimensions

Depth	180 mm
Width	167 mm
Height	58 mm
