[PA]
UNIT
[FILTER]
UNIT
REF. NO.
DESCRIPTION
PART NO.
REF. NO.
DESCRIPTION
PART NO.
C26 Barrier Lay
0.1
12V
01
Diode
1N60
C27
Barrier Lay
0.1
12V
02
Diode 1N60
03
Diode GP08B
L1 Choke
LW·22
L2 Trans
LR117
L1 Coil
LA139
L3
Choke
LW18
L2 Coil
LR49
L4
Trans
LR113
L3
Coil
LR50
L5
Choke
LW18
L5 Coil
LR52
L6
Choke
LW18
L6 Coil
LR51
L7
Trans
LR83
L7
Coil
LR90
L8 Trans
LR114
L8 Coil
LR91
L9 Coil
LR53
S1
Thermal
OHD70M
L10
Coil
LR54
L11 Coil
LR55
J1
Connector
LLR·6
L12 Coil
LR56
L13
Coil LR57
P1
Connector
5250-02A
L14
Coil
LR58
P2
Connector
525Q-04A
L15
Coil LR123
P3
Connector
5250-04A
L16 Coil
102 L4
P4
Connector
1545R·1
L17
Coil
LA139
P5
Connector
SMF-Qn·1.3
R1
Resistor
68
R25
B1
P.C. Board
B-479A
R3
Resistor
47K ELR26
R4
Resistor
47K ELR25
R5
Resistor
47K ELR25
R6
Resistor
12K
ELR25
R7
Resistor
12K
ELR25
C1 Dip Mica
DM19 680P 500V 1CR
C2 Ceramic
DD31-Q.SL 82P 5OOV02
C3 Dip Mica
DM20
1200P 5OOV1CR
C4
Ceramic
DD31·2·SL220P 5OOV02
C5 Dip Mica
DM19
68)P 500V 1CR
C6 Dip Mica
DM19
470P 500V 1CR
C7 Ceramic
DD31·2·SL120P 5OOV02
C8
Dip Mica
DM19 680P
500V 1CR
C9 Ceramic
DD35-Q.SL 39P 5OOV02
C10 Dip Mica
DM19 390P
500V 1CR
C11 Dip Mica
DM19 390P
500V 1CR
C12 Ceramic
DD38-Q.SL 27P 5OOV02
C13 Dip Mica
DM19
470P 500V 1CR
C14
Ceramic
DD38-Q.SL 6SP 5OOV02
C15 Ceramic
DD31·2·SL220P 5OOV02
C16
Ceramic
DD31·2·SL18>P 5OOV02
C17 Ceramic
DD35-Q.SL 1SP 5OOV02
C18
Ceramic
DD31-4·SL330P 5OOV02
C19 Ceramic
DD36-Q·SL 56P 5OOV02
C20
Ceramic
DD31-Q.SL2ooP 5OOV02
C21
Ceramic
DD38-Q.SL1ooP 5OOV02
C22 Ceramic
DD35-Q.SL 10P 5OOV02
C23
Ceramic
DD31·2·SL150P 5OOV02
C24 Ceramic
DD35-Q.SL 39P 5OOV02
C25
Ceramic
DD31-Q.SL150P 5OOV02
C26 Ceramic
DD35-Q.SL 47P 5OOV02
C27
Ceramic
DD35-Q.SL l5P 5OOV02
C28
Ceramic
DD31-Q·SL120P 5OOV02
C29 Ceramic
DD3S-Q-SL 27P 5OOV02
C30 Ceramic
DD38-Q.SL lOOP 5OOV02
C31 Trimmer
FCV·IZW20X40
C32 Ceramic
220P 50V
C33
Ceramic
lOOP
50V
C34
Ceramic
lOOP
50V
C35
Ceramic
lOOP 50V
C36 Ceramic
100P 50V
10 -11
