Icom IC-7610

Cmd. Sub cmd. Data Description
07 00 or 01 Read the Overow status
( 00=OVF indicator is OFF, 01=OVF indicator is ON)
11 0000 ~ 0255 Read the PO meter level
(0000=0% to 0143=50% to 212=100%)
12 0000 ~ 0255 Read SWR meter level
( 0000=SWR1.0, 0048=SWR1.5,
0080=SWR2.0, 0120=SWR3.0)
13 0000 ~ 0255 Read ALC meter level
(0000=Min. to 0120=Max.)
14 0000 ~ 0255 Read COMP meter level
(0000=0 dB, 0130=15 dB, 0241=30 dB)
15 0000 ~ 0255 Read Vd meter level
(0000=0 V, 0151=10 V, 0211=16 V)
16 0000 ~ 0255 Read Id meter level
( 0000=0A, 0077=10A, 0165=20A, 0241=30A)
16* 02 00 Preamp OFF
01 Preamp 1 ON
02 Preamp 2 ON
12 01 ~ 03 Set the AGC time constant
(01=FAST, 02=MID, 03=SLOW)
22 00 or 01 Set the Noise blanker
(00=OFF, 01=ON)
32 00 Audio peak lter OFF
01 Audio peak lter WIDE ON
(320 Hz is selected when SHARP APF is set)
02 Audio peak lter MID ON
(160 Hz is selected when SHARP APF is set)
03 Audio peak lter NAR ON
(80 Hz is selected when SHARP APF is set)
40 00 or 01 Set the Noise reduction
(00=OFF, 01=ON)
41 00 or 01 Set the Auto Notch function
(00=OFF, 01=ON)
42 00 or 01 Set the Repeater tone
(00=OFF, 01=ON)
43 00 or 01 Set the Tone squelch
(00=OFF, 01=ON)
44 00 or 01 Set the Speech compressor
(00=OFF, 01=ON)
45 00 or 01 Set the Monitor [MONI] function
(00=OFF, 01=ON)
46 00 or 01 Set the VOX function
(00=OFF, 01=ON)
47 00 BK-IN function OFF
01 Semi BK-IN function ON
02 Full BK-IN function ON
48 00 or 01 Set the Manual Notch function
(00=OFF, 01=ON)
4E 00 or 01 Set the DIGI-SEL function
(00=OFF, 01=ON)
4F 00 or 01 Set the Twin peak lter
(00=OFF, 01=ON)
( Can be turned ON only when Mark and Shift
are set to 2125 Hz and 170 Hz, respectively)
50 00 or 01 Set the Dial lock function
(00=OFF, 01=ON)
53*
2
00 or 01 Set the ANT-RX I/O
(00=OFF, 01=ON)
56 00 or 01 Set the DSP IF lter type
(00=SHARP, 01=SOFT)
57 00 ~ 02 Set the Manual Notch width
(00=WIDE, 01=MID, 02=NAR)
58 00 ~ 02 Set the SSB transmit bandwidth
(00=WIDE, 01=MID, 02=NAR)
( One of following values is applied, depending
on the “COMP” status (ON or OFF):
WIDE (Command: 1A 05 0015),
MID (Command: 1A 05 0016) or
NAR (Command: 1A 05 0017))
5E 00 or 01 MAIN/SUB Tracking function
(00=OFF, 01=ON)
65 00 or 01 Set the IP Plus function
(00=OFF, 01=ON)
D Command table (Continued)
Cmd. Sub cmd. Data Description
17*
3
see p. 10 Send CW messages
18 00 Turn OFF the transceiver
01*
4
Turn ON the transceiver
19 00 Read the transceiver ID
1A* 00 see p. 11 Send/read memory contents
01 see p. 10 Send/read band stacking register contents
02*
6
see p. 13 Send/read memory keyer contents
03 see p. 12 Send/read the selected IF lter width
04 see p. 12 Send/read the selected AGC time constant
05 0001 see p. 12 Tone Control > RX >
Send/read SSB RX HPF/LPF settings
0002 00 ~ 10 Tone Control > RX >
Send/read SSB RX Tone (Bass) level
(00=–5 to 10=+5)
0003 00 ~ 10 Tone Control > RX >
Send/read SSB RX Tone (Treble) level
(00=–5 to 10=+5)
0004 see p. 12 Tone Control > RX >
Send/read AM RX HPF/LPF settings
0005 00 ~ 10 Tone Control > RX >
Send/read AM RX Tone (Bass) level
(00=–5 to 10=+5)
0006 00 ~ 10 Tone Control > RX >
Send/read AM RX Tone (Treble) level
(00=–5 to 10=+5)
0007 see p. 12 Tone Control > RX >
Send/read FM RX HPF/LPF settings
0008 00 ~ 10 Tone Control > RX >
Send/read FM RX Tone (Bass) level
(00=–5 to 10=+5)
0009 00 ~ 10 Tone Control > RX >
Send/read FM RX Tone (Treble) level
(00=–5 to 10=+5)
0010 see p. 12 Tone Control > RX >
Send/read CW RX HPF/LPF settings
0011 see p. 12 Tone Control > RX >
Send/read RTTY RX HPF/LPF settings
0012 see p. 12 Tone Control > RX >
Send/read PSK RX HPF/LPF settings
0013 00 ~ 10 Tone Control > TX >
Send/read SSB TX Tone (Bass) level
(00=–5 to 10=+5)
0014 00 ~ 10 Tone Control > TX >
Send/read SSB TX Tone (Treble) level
(00=–5 to 10=+5)
0015 see p. 12 Tone Control > TX >
Send/read SSB TX bandwidth for wide
0016 see p. 12 Tone Control > TX >
Send/read SSB TX bandwidth for mid
0017 see p. 12 Tone Control > TX >
Send/read SSB TX bandwidth for narrow
0018 00 ~ 10 Tone Control > TX >
Send/read AM TX Tone (Bass) level
(00=–5 to 10=+5)
0019 00 ~ 10 Tone Control > TX >
Send/read AM TX Tone (Treble) level
(00=–5 to 10=+5)
0020 00 ~ 10 Tone Control > TX >
Send/read FM TX Tone (Bass) level
(00=–5 to 10=+5)
0021 00 ~ 10 Tone Control > TX >
Send/read FM TX Tone (Treble) level
(00=–5 to 10=+5)
0022 0000 ~ 0255 Function > Beep Level
(0000=min. to 0255=max.)
0023 00 or 01 Function > Beep Level Limit
(00=OFF, 01=ON)
0024 00 or 01 Function > Beep (Conrmation)
(00=OFF, 01=ON)
0025 00 or 01 Function > Band Edge Beep
(00=OFF, 01=ON)
( ON = Beep sounds with a default amateur
band)
02 Function > Band Edge Beep
(02=ON (User))
03 Function > Band Edge Beep
(03=ON (User) & TX Limit)
15
Remote control
4
