Icom IC-7610

Cmd. Sub cmd. Data Description
0026 0050 ~ 0200 Function > Beep Sound (MAIN)
(0050=500 Hz to 0200=2000 Hz)
0027 0050 ~ 0200 Function > Beep Sound (SUB)
(0050=500 Hz to 0200=2000 Hz)
0028 00 ~ 02 Function > RF/SQL Control
(00=Auto, 01=SQL, 02=RF+SQL)
0029 00 ~ 05 Function > TX Delay > HF
(00=OFF, 01=10 ms, 02=15 ms,
03=20 ms, 04=25 ms, 05=30 ms)
0030 00 ~ 05 Function > TX Delay > 50M
(00=OFF, 01=10 ms, 02=15 ms,
03=20 ms, 04=25 ms, 05=30 ms)
0031 00 ~ 05 Function > Time-Out Timer (CI-V)
( 00=OFF, 01=3 min., 02=5 min., 03=10 min.,
04=20 min., 05=30 min.)
0032 00 or 01 Function > Quick Dualwatch
(00=OFF, 01=ON)
0033 00 or 01 Function > SPLIT > Quick SPLIT
(00=OFF, 01=ON)
( Setting the [SPLIT] key operation when it is
held down for 1 second.)
0034 00 or 01 Function > SPLIT >
Display Keypad on Quick SPLIT
(00=OFF, 01=ON)
0035 see p. 12 Function > SPLIT > FM SPLIT Offset (HF)
0036 see p. 12 Function > SPLIT > FM SPLIT Offset (50M)
0037 00 or 01 Function > SPLIT > SPLIT LOCK
(00=OFF, 01=ON)
0038 00 or 01 Function > Tuner > PTT Start
(00=OFF, 01=ON)
0039 00 or 01 Function > Transverter Function
(00=Auto, 01=ON)
0040 see p. 12 Function > Transverter Offset
0041 00 ~ 02 Function > RTTY Mark Frequency
(00=1275 Hz, 01=1615 Hz, 02=2125 Hz)
0042 00 ~ 02 Function > RTTY Shift Width
(00=170 Hz, 01=200 Hz, 02=425 Hz)
0043 00 or 01 Function > RTTY Keying Polarity
(00=Normal, 01=Reverse)
0044 00 ~ 02 Function > PSK Tone Frequency
(00=1000 Hz, 01=1500 Hz, 02=2000 Hz)
0045 00 or 01 Function > SPEECH > SPEECH Language
(00=English, 01=Japanese)
0046 00 or 01 Function > SPEECH > SPEECH Speed
(00=Slow, 01=Fast)
0047 00 or 01 Function > SPEECH > S-Level SPEECH
(00=OFF, 01=ON)
0048 00 or 01 Function > SPEECH > MODE SPEECH
(00=OFF, 01=ON)
0049 0000 ~ 0255 Function > SPEECH > SPEECH Level
(0000=0% to 0255=100%)
0050 00 or 01 Function > [SPEECH/LOCK] Switch
(00=SPEECH/LOCK, 01=LOCK/SPEECH)
0051 00 or 01 Function > Lock Function
(00=MAIN DIAL, 01=PANEL)
0052 00 or 01 Function > Memo Pad Quantity
(00=5 ch, 01=10 ch)
0053 00 to 02 Function > MAIN DIAL Auto TS
(00=OFF, 01=Low, 02=High)
0054 00 or 01 Function >
MAIN DIAL Select (USB DIAL–SUB Only)
(00=Main only, 01=Main/Sub)
0055 00 or 01 Function >
MAIN/SUB Tracking [MAIN/SUB] Switch
(00=OFF, 01=ON)
0056 00 or 01 Function > MIC Up/Down Speed
(00=Slow, 01=Fast)
0057 00 or 01 Function > Quick RIT/
∂
TX Clear
(00=OFF, 01=ON)
0058 00 ~ 02 Function > [NOTCH] Switch (SSB)
(00=Auto, 01=Manual, 02=Auto/Manual)
0059 00 ~ 02 Function > [NOTCH] Switch (AM)
(00=Auto, 01=Manual, 02=Auto/Manual)
0060 00 or 01 Function > FILTER Screen MAIN/SUB Select
( 00=Fix, 01=Auto (by FILTER, PBT Operation))
0061 00 or 01 Function > SSB/CW Synchronous Tuning
(00=OFF, 01=ON)
D Command table (Continued)
Cmd. Sub cmd. Data Description
0062 00 or 01 Function > CW Normal Side
(00=LSB, 01=USB)
0063 00 or 01 Function > Screen Keyboard Type
(00=Ten-key, 01=Full Keyboard)
0064 00 ~ 02 Function > Screen Full Keyboard Layout
(00=English, 01=German, 02=French)
0065 00 or 01 Function > Screen Capture [POWER] Switch
(00=OFF, 01=ON)
0066 00 or 01 Function >
Screen Capture Keyboard [Print Screen]
(00=OFF, 01=ON)
0067 00 or 01 Function > Screen Capture Storage Media
(00=SD Card, 01=USB ash drive)
0068 00 or 01 Function > Screen Capture File Type
(00=PNG, 01=BMP)
0069 00 or 01 Function > Calibration Marker
(00=OFF, 01=ON)
0070 0000 ~ 0511 Function > REF Adjust
(0000=0%, 0511=100%)
0071 00 ~ 30 Connectors > Phones > Level
(00=–15 dB to 30=+15 dB)
0072 00 or 01 Connectors > Phones > L/R Mix
(00=OFF, 01=ON)
0073 00 or 01 Connectors > ACC AF/IF Output >
AF/SQL Output Select
(00=MAIN, 01=SUB)
0074 00 or 01 Connectors > ACC AF/IF Output > Output
Select
(00=AF, 01=IF)
0075 00 or 01 Connectors > ACC AF/IF Output >
AF/IF XFC Output (SPLIT ON)
(00=MAIN, 01=SUB)
0076 0000 ~ 0255 Connectors > ACC AF/IF Output >
AF Output Level
(0000=0% to 0255=100%)
0077 00 or 01 Connectors > ACC AF/IF Output > AF SQL
(00=OFF (Open), 01=ON)
0078 00 or 01 Connectors > ACC AF/IF Output >
AF Beep/Speech... Output
(00=OFF, 01=ON)
0079 0000 ~ 0255 Connectors > ACC AF/IF Output >
ACC IF Output Level
(0000=0% to 0255=100%)
0080 00 or 01 Connectors > USB AF/IF Output > Output
Select
(00=AF, 01=IF)
0081 00 or 01 Connectors > USB AF/IF Output >
AF/IF XFC Output (SPLIT ON)
(00=MAIN, 01=SUB)
0082 0000 ~ 0255 Connectors > USB AF/IF Output >
AF Output Level
(0000=0%, 0255=100%)
0083 00 or 01 Connectors > USB AF/IF Output > AF SQL
(00=OFF (Open), 01=ON)
0084 00 or 01 Connectors > USB AF/IF Output >
AF Beep/Speech... Output
(00=OFF, 01=ON)
0085 0000 ~ 0255 Connectors > USB AF/IF Output > IF Output
Level
(0000=0%, 0255=100%)
0086 00 or 01 Connectors > LAN AF/IF Output > Output
Select
(00=AF, 01=IF)
0087 00 or 01 Connectors > LAN AF/IF Output > AF SQL
(00=OFF (Open), 01=ON)
0088 0000 ~ 0255 Connectors > MOD Input > ACC MOD Level
(0000=0% to 0255=100%)
0089 0000 ~ 0255 Connectors > MOD Input > USB MOD Level
(0000=0% to 0255=100%)
0090 0000 ~ 0255 Connectors > MOD Input > LAN MOD Level
(0000=0% to 0255=100%)
0091 00 ~ 05 Connectors > MOD Input > DATA OFF MOD
( 00=MIC, 01=ACC, 02=MIC,ACC, 03=USB,
04=MIC,USB, 05=LAN)
1A* 05 1A* 05
Remote control
5
