Icom IC-7610

D Command formats
• Operating frequency
Command: 00, 03, 05, 1C 03
q
XX X X X
w e
X
r t
XX 00
10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–6 1 MHz digit: 0–9 1 GHz digit: 0 (Fixed) 100 MHz digit: 0 (Fixed)
• Operating mode
Command: 01, 04, 06
q w
XX X X
q
Receiving mode
w
Filter setting
00:LSB 05:FM 01:FIL1
01:USB 07:CW-R 02:FIL2
02:AM 08:RTTY-R 03:FIL3
03:CW 12:PSK —
04:RTTY 17:PSK-R —
L Filter setting (w) can be skipped with command 01 and
06. In that case, “FIL1” is selected with command 01
and the default lter setting of the receiving mode is
automatically selected with command 06.
• Codes for CW message contents
Command: 17 Up to 30 characters
To send CW messages, use the following character
codes.
Character ASCII code
0–9 30–39
A–Z 41–5A
a–z 61–7A
/ 2F
? 3F
. 2E
− 2D
, 2C
: 3A
Character ASCII code
’ 27
( 28
) 29
= 3D
+ 2B
” 22
@ 40
Space 20
L“FF” stops sending CW messages.
L “^” is used to transmit a string of characters with no
inter-character space.
• Band edge frequency settings
Command: 02*, 1E 01, 1E 03
* When obtaining the edge number (by command “02”),
the edge number (q) is not returned.
q
X X X
w e r t y u i o !0 !1 !2
X X X X X X X 0 0 2 D X X X X X X X X 0 0
10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–6 1 MHz digit: 0–9 1000 MHz digit: 0 (fixed) 100 MHz digit: 0 (fixed) 10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–6 1 MHz digit: 0–9 1000 MHz digit: 0 (fixed) 100 MHz digit: 0 (fixed) Separator (fixed)
Lower edge Higher edge
Edge number*: 01–30
• Band stacking register
Command: 1A 01
q
XXXX
w
q Frequency band codes
Code Freq. band Frequency range (unit: MHz)
01 1.8 1.800000 ~ 1.999999
02 3.5 3.400000 ~ 4.099999
03 7 6.900000 ~ 7.499999
04 10 9.900000 ~ 10.499999
05 14 13.900000 ~ 14.499999
06 18 17.900000 ~ 18.499999
07 21 20.900000 ~ 21.499999
08 24 24.400000 ~ 25.099999
09 28 28.000000 ~ 29.999999
10 50 50.000000 ~ 54.000000
11 GENE Other than above
w Register codes
Code Registered number
01 1 (latest)
02 2
03 3 (oldest)
For example, when sending/reading the oldest
contents in the 21 MHz band, the code “0703” is
used.
Remote control
10
