Icom IC-7610

5-34
REF PART
DESCRIPTION M.
H/V
NO. NO. LOCATION
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
[BPF-B UNIT]
C1208 4030023720 S.CER 0603N470J500CT T 33.5/13.5
C1209 4030023400 S.CER 0603N8R0D500CT T 32.2/13.5
C1210 4030023580 S.CER 0603N220J500CT T 37.5/16.3
C1211 4030023500 S.CER 0603N150J500CT T 37.5/17.5
C1212 4030023720 S.CER 0603N470J500CT T 38.5/14.0
C1213 4030023520 S.CER 0603N180J500CT T 39.8/14.0
C1214 4030023530 S.CER 0603N181J500CT T 41.8/14.3
C1215 4030023720 S.CER 0603N470J500CT T 43.0/14.3
C1216 4030023870 S.CER 0603B104K500CT T 48.8/14.3
C1301 4030023490 S.CER 0603N121J500CT T 19.5/47.8
C1302 4030023520 S.CER 0603N180J500CT T 20.8/47.8
C1303 4030023870 S.CER 0603B104K500CT T 15.8/47.0
C1304 4030023670 S.CER 0603N330J500CT T 27.0/47.8
C1305 4030023520 S.CER 0603N180J500CT T 28.3/47.8
C1306 4030023450 S.CER 0603N100D500CT T 32.0/51.0
C1307 4030023670 S.CER 0603N330J500CT T 32.0/49.8
C1308 4030023720 S.CER 0603N470J500CT T 30.0/46.8
C1309 4030023450 S.CER 0603N100D500CT T 31.3/46.8
C1310 4030023670 S.CER 0603N330J500CT T 35.0/51.0
C1311 4030023450 S.CER 0603N100D500CT T 35.0/49.8
C1312 4030023670 S.CER 0603N330J500CT T 36.3/47.8
C1313 4030023520 S.CER 0603N180J500CT T 37.5/47.8
C1314 4030023490 S.CER 0603N121J500CT T 39.5/47.8
C1315 4030023520 S.CER 0603N180J500CT T 40.8/47.8
C1316 4030023870 S.CER 0603B104K500CT T 47.8/46.3
C1401 4030023460 S.CER 0603N101J500CT T 20.5/30.5
C1403 4030023870 S.CER 0603B104K500CT T 17.3/28.8
C1404 4030023580 S.CER 0603N220J500CT T 27.3/30.0
C1405 4030023480 S.CER 0603N120J500CT T 28.5/30.0
C1406 4030023480 S.CER 0603N120J500CT T 31.5/32.3
C1407 4030023580 S.CER 0603N220J500CT T 31.5/33.5
C1408 4030023580 S.CER 0603N220J500CT T 30.5/29.5
C1409 4030023390 S.CER 0603N7R0D500CT T 31.8/29.5
C1410 4030023580 S.CER 0603N220J500CT T 34.5/33.5
C1411 4030023480 S.CER 0603N120J500CT T 34.5/32.3
C1412 4030023580 S.CER 0603N220J500CT T 36.5/29.5
C1413 4030023480 S.CER 0603N120J500CT T 37.8/29.5
C1414 4030023460 S.CER 0603N101J500CT T 40.7/30.5
C1416 4030023870 S.CER 0603B104K500CT T 44.5/28.0
C1501 4030023460 S.CER 0603N101J500CT T 25.2/24.2
C1502 4030023730 S.CER 0603N471J500CT T 27.5/22.1
C1503 4030023870 S.CER 0603B104K500CT T 20.5/24.0
C1504 4030023510 S.CER 0603N151J500CT T 27.5/20.9
C1505 4030023750 S.CER 0603N560J500CT T 30.5/24.6
C1506 4030023720 S.CER 0603N470J500CT T 32.7/23.8
C1507 4030023790 S.CER 0603N820J500CT T 32.7/25.0
C1508 4030023520 S.CER 0603N180J500CT T 34.8/22.3
C1509 4030023760 S.CER 0603N680J500CT T 34.8/25.1
C1510 4030023870 S.CER 0603B104K500CT T 41.6/20.9
J1001 6510030150 S.CON 40RF-JMCS-G-1B-TF
(N) (LF) (SN) B 50.0/27.3
J1002 6510030220 S.CON 50RF-JMCS-G-1B-TF
(N) (LF) (SN) B 10.0/27.3
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION= See the BOARD LAYOUTS for details
