REMOTE CONTROL
Remote control (CI-V) information
D Command formats
• RIT frequency settings
Command: 21 00
10 Hz: 0 ~ 9
100 Hz: 0 ~ 9 1 Hz: 0
~ 9
1 kHz: 0 ~ 9
X X X X X X
00: + (plus)
01: – (minus)
• DV TX data
Command: 22 00
1 ~ 
X X X X
∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙
(Variable length)
1 ~ : TX data (Up to 30 Byte)
L “FA” to “FF” are entered after converted to “FF 0A” to “FF
0F” automatically� Up to 60 Byte data can be entered in
this case�
• DV RX data (transceive)
Command: 22 01 01
1 ~ : RX data (Up to 30 Byte)
L “FA” to “FF” are entered after converted to “FF 0A” to “FF
0F” automatically� Up to 60 Byte data can be entered in
this case�
• MY position data
Command: 23 00
X X X X
1 ~ 5
X X X X
6 ~ 
X X X X
 ~ 
X X X X
 ~ 
X X X X
 ~ 
X X

X X
∙∙∙∙∙∙∙ ∙∙∙∙∙∙∙
∙∙∙∙∙∙∙ ∙∙∙∙∙∙∙
∙∙∙∙∙∙∙
1 ~ 5: Latitude (dd°mm�mmm format)
6 ~ : Longitude (ddd°mm�mmm format)
 ~ : Altitude (0�1 meter steps)
, : Course (1 degree steps)
 ~ : Speed (0�1 km/h steps)
 ~ : Date (UTC: yyyymmddHHMMSS)
( y: Year, m: Month, d: Day,
H: Hour, M: Minute, S: Second)
• Selected or unselected VFO frequency settings
Command: 25
X X X X X X X X X X X X
Operating frequency
00=Selected VFO
01=Unselected VFO
See “Operating frequency�” (p� 16)
L When using the DR function, the transceiver returns
“FA” (NG) because these cannot be set to 01�
• When VFO A is selected
00=frequency of VFO A changes
01=frequency of VFO B changes
• When VFO B is selected
00=frequency of VFO B changes
01=frequency of VFO A changes
• Selected or unselected VFO’s operating mode
and lter settings
Command: 26
Both data and filter settings can be skipped� In that
case, “DATA OFF” and the default filter setting of the
operating mode is automatically selected�
1Operating mode setting
2Data mode setting
3Filter setting
00=Selected VFO
01=Unselected VFO
XX X X XX XX
L When using the DR function, the transceiver returns “FA”
(NG) because these cannot be set to 01�
• When VFO A is selected
00 = operating mode of VFO A changes
01 = operating mode of VFO B changes
• When VFO B is selected
00 = operating mode of VFO B changes
01 = operating mode of VFO A changes
1 Operating mode
setting
2 Data mode
setting
3 Filter
setting
00:LSB 07:CW-R 00: Data mode OFF*
2
01:FIL1
01:USB 08:RTTY-R 01: Data mode ON 02:FIL2
02:AM 17:DV — 03:FIL3
03:CW 22:DD*
1
— —
04:RTTY 23:ATV*
1
— —
05:FM — — —
*
1
The commands can be set when the 1200 MHz or higher
band is selected�
*
2
When 00 is set, also set 00 to 3�
