Icom IC-A220T Service Manual

The underlined parts have been updated from the addendum of the previous version, or from the original page.
5-29g
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[VOLUME UNIT] (for IC-A210 and IC-A210E)
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
(Amended page)
July 2019
R1 7210003270 VAR TP76N00NA-26F-10KB-2974
R2 7030003440 S.RES ERJ3GEYJ 102 V (1 k) [#01] T 28.4/11.1
7030003440 S.RES ERJ3GEYJ 102 V (1 k) [#02]
7030015130 S.RES RMC1/16-102JTP (1 k) [#03]
7030003440 S.RES ERJ3GEYJ 102 V (1 k) [#05]
7030003440 S.RES ERJ3GEYJ 102 V (1 k) [#11]
7030003440 S.RES ERJ3GEYJ 102 V (1 k) [#21]
7030015130 S.RES RMC1/16-102JTP (1 k) [#23]
7030003440 S.RES ERJ3GEYJ 102 V (1 k) [#25]
R3 7030003320 S.RES ERJ3GEYJ 101 V (100) [#01] T 31.6/11.1
7030003320 S.RES ERJ3GEYJ 101 V (100) [#02]
7030015010 S.RES RMC1/16-101JTP (100) [#03]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#05]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#11]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#21]
7030015010 S.RES RMC1/16-101JTP (100) [#23]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#25]
C1 4030006900 S.CER C1608 JB 1H 103K-T [#01] T 3.0/3.3
4030006900 S.CER C1608 JB 1H 103K-T [#02]
4030023860 S.CER 0603B103K500CT [#03]
Eqv. 4030026180 S.CER MG18B103K500CT [#03]
C1 4030006900 S.CER C1608 JB 1H 103K-T [#05] T 3.0/3.3
4030006900 S.CER C1608 JB 1H 103K-T [#11]
4030006900 S.CER C1608 JB 1H 103K-T [#21]
4030023860 S.CER 0603B103K500CT [#23]
4030006900 S.CER C1608 JB 1H 103K-T [#25]
C2 4030006900 S.CER C1608 JB 1H 103K-T [#01] T 3.0/7.8
4030006900 S.CER C1608 JB 1H 103K-T [#02]
4030023860 S.CER 0603B103K500CT [#03]
Eqv. 4030026180 S.CER MG18B103K500CT [#03]
C2 4030006900 S.CER C1608 JB 1H 103K-T [#05] T 3.0/7.8
4030006900 S.CER C1608 JB 1H 103K-T [#11]
4030006900 S.CER C1608 JB 1H 103K-T [#21]
4030023860 S.CER 0603B103K500CT [#23]
4030006900 S.CER C1608 JB 1H 103K-T [#25]
C3 4030006860 S.CER C1608 JB 1H 102K-T [#01] B 8.2/7.0
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C3 4030006860 S.CER C1608 JB 1H 102K-T [#05] B 8.2/7.0
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C4 4030006860 S.CER C1608 JB 1H 102K-T [#01] B 8.2/3.8
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C4 4030006860 S.CER C1608 JB 1H 102K-T [#05] B 8.2/3.8
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
J1 6510026160 S.CON 06FLZ-SM2-TB (LF) (SN) T 20.8/116.0
