Icom IC-A220T Service Manual

The underlined parts have been updated from the addendum of the previous version, or from the original page.
5-30g
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[FRONT UNIT] (for IC-A210 and IC-A210E)
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[FRONT UNIT] (for IC-A210 and IC-A210E)
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
(Amended page)
July 2019
IC3 1110006260 S.IC BD5242G-TR B 18.7/53.7
IC4 1140014368 S.IC HD64F38347WV T 54.2/92.4
IC5 1130011581 S.IC 24LC64T-I/SN G T 49.9/133.5
IC6 1130013540 S.IC TC74LVX4245FS (ELF) [#01] T 70.5/82.0
1130013540 S.IC TC74LVX4245FS (ELF) [#02]
1130019190 S.IC SN74LVC 4245A DBR [#03]
1130013540 S.IC TC74LVX4245FS (ELF) [#05]
1130013540 S.IC TC74LVX4245FS (ELF) [#11]
1130013540 S.IC TC74LVX4245FS (ELF) [#21]
1130019190 S.IC SN74LVC 4245A DBR [#23]
1130013540 S.IC TC74LVX4245FS (ELF) [#25]
IC7 1130013540 S.IC TC74LVX4245FS (ELF) [#01] T 91.0/79.0
1130013540 S.IC TC74LVX4245FS (ELF) [#02]
1130019190 S.IC SN74LVC 4245A DBR [#03]
1130013540 S.IC TC74LVX4245FS (ELF) [#05]
1130013540 S.IC TC74LVX4245FS (ELF) [#11]
1130013540 S.IC TC74LVX4245FS (ELF) [#21]
1130019190 S.IC SN74LVC 4245A DBR [#23]
1130013540 S.IC TC74LVX4245FS (ELF) [#25]
IC10 1120003050 S.IC ADM202EARUZ-REEL7 B 120.3/22.9
IC11 1130006551 S.IC TC7S08FU (TE85RF) B 107.4/13.3
IC12 1130006551 S.IC TC7S08FU (TE85RF) B 109.9/13.3
IC13 1110006490 S.IC LMV321IDCKR Only [#03] B 109.9/16.4
IC14 1130006891 S.IC TC7S04FU (TE85RF) B 107.4/16.4
IC15 1130013460 S.IC NJU6060V-TE1-#ZZZB B 134.5/24.7
IC16 1180000421 S.IC TA78L05F (TE12RF) T 133.9/109.7
IC17 1130013770 S.IC TC7S00FU (TE85LF) T 101.3/111.5
IC18 1130008361 S.IC TC7SHU04FU (TE85LJF) B 99.7/21.7
Q4 1590001040 S.TRA DTA113ZU T106 T 89.2/17.6
Eqv. 1590004850 S.TRA PDTA113ZU115
Q5 1590001040 S.TRA DTA113ZU T106 T 78.0/22.4
Eqv. 1590004850 S.TRA PDTA113ZU115
Q6 1530002381 S.TRA 2SC4215-Y (TE85LF) B 99.5/24.6
Q7 1590001040 S.TRA DTA113ZU T106 T 86.7/17.6
Eqv. 1590004850 S.TRA PDTA113ZU115
D4 1730002531 S.ZEN NNCD6.2G-T1-A B 27.4/19.1
X1 6050012011 S.XTA CR-789A (9.8304 MHz) [#01] B 106.4/18.3
6050012011 S.XTA CR-789A (9.8304 MHz) [#02]
6050012012 S.XTA CR-789B (9.8304 MHz) [#03]
6050012011 S.XTA CR-789A (9.8304 MHz) [#05]
6050012011 S.XTA CR-789A (9.8304 MHz) [#11]
6050012011 S.XTA CR-789A (9.8304 MHz) [#21]
6050012011 S.XTA CR-789A (9.8304 MHz) [#23]
6050012011 S.XTA CR-789A (9.8304 MHz) [#25]
L1 6200003181 S.COI NLV32T-390J-PF B 103.7/22.5
R5 7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#01] T 64.0/11.8
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#02]
7030015370 S.RES RMC1/16-104JTP (100 k) [#03]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#05]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#11]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#21]
7030015370 S.RES RMC1/16-104JTP (100 k) [#23]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#25]
R6 7030003320 S.RES ERJ3GEYJ 101 V (100) [#01] B 134.5/8.0
7030003320 S.RES ERJ3GEYJ 101 V (100) [#02]
7030015010 S.RES RMC1/16-101JTP (100) [#03]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#05]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#11]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#21]
7030015010 S.RES RMC1/16-101JTP (100) [#23]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#25]
R7 7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#01] B 93.1/2.9
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#02]
7030015330 S.RES RMC1/16-473JTP (47 k) [#03]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#05]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#11]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#21]
7030015330 S.RES RMC1/16-473JTP (47 k) [#23]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#25]
R8 7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#01] B 91.9/2.9
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#02]
7030015330 S.RES RMC1/16-473JTP (47 k) [#03]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#05]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#11]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#21]
7030015330 S.RES RMC1/16-473JTP (47 k) [#23]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#25]
R9 7030006550 S.RES ERJ3GEYJ 914V (910 k) [#01] T 84.3/18.4
7030006550 S.RES ERJ3GEYJ 914V (910 k) [#02]
7030019000 S.RES RMC1/16-914JTP (910 k) [#03]
7030006550 S.RES ERJ3GEYJ 914V (910 k) [#05]
7030006550 S.RES ERJ3GEYJ 914V (910 k) [#11]
7030006550 S.RES ERJ3GEYJ 914V (910 k) [#21]
7030019000 S.RES RMC1/16-914JTP (910 k) [#23]
7030006550 S.RES ERJ3GEYJ 914V (910 k) [#25]
R10 7030003740 S.RES ERJ3GEYJ 334 V (330 k) [#01] T 85.7/7.7
7030003740 S.RES ERJ3GEYJ 334 V (330 k) [#02]
7030015430 S.RES RMC1/16-334JTP (330 k) [#03]
7030003740 S.RES ERJ3GEYJ 334 V (330 k) [#05]
7030003740 S.RES ERJ3GEYJ 334 V (330 k) [#11]
7030003740 S.RES ERJ3GEYJ 334 V (330 k) [#21]
7030015430 S.RES RMC1/16-334JTP (330 k) [#23]
7030003740 S.RES ERJ3GEYJ 334 V (330 k) [#25]
R11 7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#01] B 131.3/9.3
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#02]
7030015250 S.RES RMC1/16-103JTP (10 k) [#03]
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#05]
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#11]
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#21]
7030015250 S.RES RMC1/16-103JTP (10 k) [#23]
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#25]
R12 7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#01] B 134.5/9.3
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#02]
7030015370 S.RES RMC1/16-104JTP (100 k) [#03]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#05]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#11]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#21]
7030015370 S.RES RMC1/16-104JTP (100 k) [#23]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#25]
R13 7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#01] B 134.5/14.5
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#02]
7030015370 S.RES RMC1/16-104JTP (100 k) [#03]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#05]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#11]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#21]
7030015370 S.RES RMC1/16-104JTP (100 k) [#23]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#25]
R14 7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#01] B 134.5/13.2
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#02]
7030015250 S.RES RMC1/16-103JTP (10 k) [#03]
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#05]
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#11]
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#21]
7030015250 S.RES RMC1/16-103JTP (10 k) [#23]
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#25]
R19 7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#01] B 140.5/17.2
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#02]
7030015370 S.RES RMC1/16-104JTP (100 k) [#03]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#05]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#11]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#21]
7030015370 S.RES RMC1/16-104JTP (100 k) [#23]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#25]
R20 7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#01] B 94.8/2.9
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#02]
7030015330 S.RES RMC1/16-473JTP (47 k) [#03]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#05]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#11]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#21]
7030015330 S.RES RMC1/16-473JTP (47 k) [#23]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#25]
R21 7030003390 S.RES ERJ3GEYJ 391 V (390) [#01] B 138.6/4.5
7030003390 S.RES ERJ3GEYJ 391 V (390) [#02]
7030015080 S.RES RMC1/16-391JTP (390) [#03]
7030003390 S.RES ERJ3GEYJ 391 V (390) [#05]
7030003390 S.RES ERJ3GEYJ 391 V (390) [#11]
7030003390 S.RES ERJ3GEYJ 391 V (390) [#21]
7030015080 S.RES RMC1/16-391JTP (390) [#23]
7030003390 S.RES ERJ3GEYJ 391 V (390) [#25]
R22 7030003580 S.RES ERJ3GEYJ 153 V (15 k) [#01] B 74.8/7.9
7030003580 S.RES ERJ3GEYJ 153 V (15 k) [#02]
7030015270 S.RES RMC1/16-153JTP (15 k) [#03]
7030003580 S.RES ERJ3GEYJ 153 V (15 k) [#05]
7030003580 S.RES ERJ3GEYJ 153 V (15 k) [#11]
7030003580 S.RES ERJ3GEYJ 153 V (15 k) [#21]
7030015270 S.RES RMC1/16-153JTP (15 k) [#23]
7030003580 S.RES ERJ3GEYJ 153 V (15 k) [#25]
R23 7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#01] B 70.1/9.4
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#02]
7030015330 S.RES RMC1/16-473JTP (47 k) [#03]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#05]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#11]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#21]
7030015330 S.RES RMC1/16-473JTP (47 k) [#23]
7030003640 S.RES ERJ3GEYJ 473 V (47K ) [#25]
R26 7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#01] B 107.2/24.4
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#02]
7030015250 S.RES RMC1/16-103JTP (10 k) [#03]
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#05]
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#11]
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#21]
7030015250 S.RES RMC1/16-103JTP (10 k) [#23]
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [#25]
R31 7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#01] B 82.7/2.9
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#02]
7030015330 S.RES RMC1/16-473JTP (47 k) [#03]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#05]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#11]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#21]
7030015330 S.RES RMC1/16-473JTP (47 k) [#23]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#25]
