Icom IC-A220T Service Manual

The underlined parts have been updated from the addendum of the previous version, or from the original page.
5-39g
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[K-CONNECT UNIT] (for IC-A210 and IC-A210E)
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[K-CONNECT UNIT] (for IC-A210 and IC-A210E)
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
(Amended page)
July 2019
D1 1750002020 S.DIO DA2S10100L T 10.9/9.7
D2 1750002020 S.DIO DA2S10100L T 10.9/8.1
D3 1750002020 S.DIO DA2S10100L T 15.4/12.3
D4 1750002020 S.DIO DA2S10100L T 15.4/8.8
D5 1790001750 S.DIO DSM3MA4 [#01] T 69.6/6.4
1790001750 S.DIO DSM3MA4 [#02]
1750004020 S.DIO DFM3MF2 [#03]
1790001750 S.DIO DSM3MA4 [#05]
1790001750 S.DIO DSM3MA4 [#11]
1790001750 S.DIO DSM3MA4 [#21]
1790001750 S.DIO DSM3MA4 [#23]
1790001750 S.DIO DSM3MA4 [#25]
D6 1750002020 S.DIO DA2S10100L T 36.5/9.6
L1 6110001660 COI LA-252
R1 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#01] B 12.5/81.7
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#02]
7030015190 S.RES RMC1/16-332JTP (3.3 k) [#03]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#05]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#11]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#21]
7030015190 S.RES RMC1/16-332JTP (3.3 k) [#23]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#25]
R2 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#01] B 6.5/80.1
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#02]
7030015190 S.RES RMC1/16-332JTP (3.3 k) [#03]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#05]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#11]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#21]
7030015190 S.RES RMC1/16-332JTP (3.3 k) [#23]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#25]
R3 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#01] B 12.6/72.2
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#02]
7030015190 S.RES RMC1/16-332JTP (3.3 k) [#03]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#05]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#11]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#21]
7030015190 S.RES RMC1/16-332JTP (3.3 k) [#23]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#25]
R4 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#01] B 7.5/58.7
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#02]
7030015190 S.RES RMC1/16-332JTP (3.3 k) [#03]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#05]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#11]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#21]
7030015190 S.RES RMC1/16-332JTP (3.3 k) [#23]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#25]
R5 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#01] B 6.0/75.9
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#02]
7030015190 S.RES RMC1/16-332JTP (3.3 k) [#03]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#05]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#11]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#21]
7030015190 S.RES RMC1/16-332JTP (3.3 k) [#23]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#25]
R6 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#01] T 146.8/84.8
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#02]
7030015190 S.RES RMC1/16-332JTP (3.3 k) [#03]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#05]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#11]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#21]
7030015190 S.RES RMC1/16-332JTP (3.3 k) [#23]
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) [#25]
R7 7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#01] T 135.4/87.1
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#02]
7030015330 S.RES RMC1/16-473JTP (47 k) [#03]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#05]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#11]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#21]
7030015330 S.RES RMC1/16-473JTP (47 k) [#23]
7030003640 S.RES ERJ3GEYJ 473 V (47 k) [#25]
R8 7030003580 S.RES ERJ3GEYJ 153 V (15 k) [#01] B 40.6/63.5
7030003580 S.RES ERJ3GEYJ 153 V (15 k) [#02]
7030015270 S.RES RMC1/16-153JTP (15 k) [#03]
7030003580 S.RES ERJ3GEYJ 153 V (15 k) [#05]
7030003580 S.RES ERJ3GEYJ 153 V (15 k) [#11]
7030003580 S.RES ERJ3GEYJ 153 V (15 k) [#21]
7030015270 S.RES RMC1/16-153JTP (15 k) [#23]
7030003580 S.RES ERJ3GEYJ 153 V (15 k) [#25]
R9 7030003440 S.RES ERJ3GEYJ 102 V (1 k) [#01] T 81.4/69.9
7030003440 S.RES ERJ3GEYJ 102 V (1 k) [#02]
7030015130 S.RES RMC1/16-102JTP (1 k) [#03]
7030003440 S.RES ERJ3GEYJ 102 V (1 k) [#05]
7030003440 S.RES ERJ3GEYJ 102 V (1 k) [#11]
7030003440 S.RES ERJ3GEYJ 102 V (1 k) [#21]
7030015130 S.RES RMC1/16-102JTP (1 k) [#23]
7030003440 S.RES ERJ3GEYJ 102 V (1 k) [#25]
R10 7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#01] B 38.7/64.5
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#02]
7030015370 S.RES RMC1/16-104JTP (100 k) [#03]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#05]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#11]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#21]
7030015370 S.RES RMC1/16-104JTP (100 k) [#23]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#25]
R11 7540000250 ABS SA05C 401N
R12 7030003320 S.RES ERJ3GEYJ 101 V (100) [#01] B 23.0/16.7
7030003320 S.RES ERJ3GEYJ 101 V (100) [#02]
7030015010 S.RES RMC1/16-101JTP (100) [#03]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#05]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#11]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#21]
7030015010 S.RES RMC1/16-101JTP (100) [#23]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#25]
R13 7030003320 S.RES ERJ3GEYJ 101 V (100) [#01] B 25.7/16.7
7030003320 S.RES ERJ3GEYJ 101 V (100) [#02]
7030015010 S.RES RMC1/16-101JTP (100) [#03]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#05]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#11]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#21]
7030015010 S.RES RMC1/16-101JTP (100) [#23]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#25]
R14 7030003860 S.RES ERJ3GE JPW V [#01] B 24.4/16.7
7030003860 S.RES ERJ3GE JPW V [#02]
7030015520 S.RES RMC1/16JPTP [#03]
7030003860 S.RES ERJ3GE JPW V [#05]
7030003860 S.RES ERJ3GE JPW V [#11]
7030003860 S.RES ERJ3GE JPW V [#21]
7030015520 S.RES RMC1/16JPTP [#23]
7030003860 S.RES ERJ3GE JPW V [#25]
R15 7030003860 S.RES ERJ3GE JPW V [#01] B 28.2/16.7
7030003860 S.RES ERJ3GE JPW V [#02]
7030015520 S.RES RMC1/16JPTP [#03]
7030003860 S.RES ERJ3GE JPW V [#05]
7030003860 S.RES ERJ3GE JPW V [#11]
7030003860 S.RES ERJ3GE JPW V [#21]
7030015520 S.RES RMC1/16JPTP [#23]
7030003860 S.RES ERJ3GE JPW V [#25]
R16 7030003860 S.RES ERJ3GE JPW V [#01] B 123.7/24.5
7030003860 S.RES ERJ3GE JPW V [#02]
7030015520 S.RES RMC1/16JPTP [#03]
7030003860 S.RES ERJ3GE JPW V [#05]
7030003860 S.RES ERJ3GE JPW V [#11]
7030003860 S.RES ERJ3GE JPW V [#21]
7030015520 S.RES RMC1/16JPTP [#23]
7030003860 S.RES ERJ3GE JPW V [#25]
R17 7030003860 S.RES ERJ3GE JPW V [#01] T 57.8/14.9
7030003860 S.RES ERJ3GE JPW V [#02]
7030015520 S.RES RMC1/16JPTP [#03]
7030003860 S.RES ERJ3GE JPW V [#05]
7030003860 S.RES ERJ3GE JPW V [#11]
7030003860 S.RES ERJ3GE JPW V [#21]
7030015520 S.RES RMC1/16JPTP [#23]
7030003860 S.RES ERJ3GE JPW V [#25]
R19 7540000410 ABS ERZV14D470
C1 4030006900 S.CER C1608 JB 1H 103K-T [#01] B 6.8/56.6
4030006900 S.CER C1608 JB 1H 103K-T [#02]
4030023860 S.CER 0603B103K500CT [#03]
Eqv. 4030026180 S.CER MG18B103K500CT [#03]
C1 4030006900 S.CER C1608 JB 1H 103K-T [#05] B 6.8/56.6
4030006900 S.CER C1608 JB 1H 103K-T [#11]
4030006900 S.CER C1608 JB 1H 103K-T [#21]
4030023860 S.CER 0603B103K500CT [#23]
4030006900 S.CER C1608 JB 1H 103K-T [#25]
C2 4030004750 S.CER C2012 JB 1H 103K-T [#01] B 30.7/58.5
4030004750 S.CER C2012 JB 1H 103K-T [#02]
4030024290 S.CER 0805B103K500CT [#03]
4030004750 S.CER C2012 JB 1H 103K-T [#05]
4030004750 S.CER C2012 JB 1H 103K-T [#11]
4030004750 S.CER C2012 JB 1H 103K-T [#21]
4030024290 S.CER 0805B103K500CT [#23]
4030004750 S.CER C2012 JB 1H 103K-T [#25]
C3 4030021600 S.CER C2012 JB 1H 104KT [#01] B 42.7/61.6
4030021600 S.CER C2012 JB 1H 104KT [#02]
4030024300 S.CER 0805B104K500CT [#03]
4030021600 S.CER C2012 JB 1H 104KT [#05]
4030021600 S.CER C2012 JB 1H 104KT [#11]
4030021600 S.CER C2012 JB 1H 104KT [#21]
4030024300 S.CER 0805B104K500CT [#23]
4030021600 S.CER C2012 JB 1H 104KT [#25]
C4 4030006860 S.CER C1608 JB 1H 102K-T [#01] B 41.2/66.6
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C4 4030006860 S.CER C1608 JB 1H 102K-T [#05] B 41.2/66.6
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C5 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 22.3/12.3
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C5 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 22.3/12.3
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
