Icom IC-A220T Service Manual

The underlined parts have been updated from the addendum of the previous version, or from the original page.
5-40g
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[K-CONNECT UNIT] (for IC-A210 and IC-A210E)
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[K-CONNECT UNIT] (for IC-A210 and IC-A210E)
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
(Amended page)
July 2019
C6 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 41.7/12.7
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C6 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 41.7/12.7
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C7 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 37.8/12.7
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C7 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 37.8/12.7
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C8 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 24.3/13.2
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C8 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 24.3/13.2
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C9 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 35.2/12.7
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C9 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 35.2/12.7
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C10 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 36.5/12.7
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C10 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 36.5/12.7
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C11 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 43.0/12.7
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C11 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 43.0/12.7
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C12 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 40.4/12.7
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C12 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 40.4/12.7
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C13 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 19.3/12.3
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C13 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 19.3/12.3
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C14 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 10.8/12.3
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C14 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 10.8/12.3
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C15 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 13.5/12.3
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C15 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 13.5/12.3
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C16 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 14.1/8.8
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C16 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 14.1/8.8
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C17 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 7.5/12.3
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C17 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 7.5/12.3
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C18 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 12.2/12.3
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C18 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 12.2/12.3
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C19 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 12.9/8.8
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C19 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 12.9/8.8
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C20 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 44.2/12.6
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C20 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 44.2/12.6
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C21 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 45.4/12.6
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C21 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 45.4/12.6
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C22 4030011070 S.CER GRM31M2C2H5R0CY21L
(GRM42-6) T 121.8/15.1
C23 4030011070 S.CER GRM31M2C2H5R0CY21L
(GRM42-6) T 121.0/6.4
C24 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 67.6/11.5
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C24 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 67.6/11.5
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C25 4030018980 S.CER C1608 JB 1H 104K-T [#01] T 12.7/107.9
4030018980 S.CER C1608 JB 1H 104K-T [#02]
4030023870 S.CER 0603B104K500CT [#03]
Eqv. 4030026160 S.CER MG18B104K500CT [#03]
C25 4030018980 S.CER C1608 JB 1H 104K-T [#05] T 12.7/107.9
4030018980 S.CER C1608 JB 1H 104K-T [#11]
4030018980 S.CER C1608 JB 1H 104K-T [#21]
4030023870 S.CER 0603B104K500CT [#23]
4030018980 S.CER C1608 JB 1H 104K-T [#25]
C26 4030018910 S.CER C1608 JB 0J 475K-T T 3.4/104.0
C27 4030007130 S.CER C1608 CH 1H 101J-T [#01] B 49.3/49.6
4030007130 S.CER C1608 CH 1H 101J-T [#02]
4030023460 S.CER 0603N101J500CT [#03]
Eqv. 4030026120 S.CER MG18N101J500CT [#03]
C27 4030007130 S.CER C1608 CH 1H 101J-T [#05] B 49.3/49.6
4030007130 S.CER C1608 CH 1H 101J-T [#11]
4030007130 S.CER C1608 CH 1H 101J-T [#21]
4030023460 S.CER 0603N101J500CT [#23]
4030007130 S.CER C1608 CH 1H 101J-T [#25]
C28 4510010810 S.ELE 50SVPF39M T 3.4/105.2
J1 6510014210 CON BNC-BJ 0E2-M100
J3 6510011591 CON B2P-VH (LF) (SN)
J4 6510018941 S.CON B13B-PH-SM4-TB (LF) (SN) B 105.0/3.6
J6 6510017150 CON TMP-S01X-C1 [#01]
6510017150 CON TMP-S01X-C1 [#02]
6510030790 CON SJ070010 (TMP-S01X-C1) [#03]
6510017150 CON TMP-S01X-C1 [#05]
6510017150 CON TMP-S01X-C1 [#11]
6510017150 CON TMP-S01X-C1 [#21]
6510030790 CON SJ070010 (TMP-S01X-C1) [#23]
6510017150 CON TMP-S01X-C1 [#25]
J7 6510031470 CON HSJ1650-010720
F1 5210001070 S.FUS 0451008.MRL T 75.2/11.2
W1 7030014290 JUM RJ25S0OHM
