Icom IC-A220T Service Manual

The underlined parts have been updated from the addendum of the previous version, or from the original page.
5-51g
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[D-CONNECT UNIT] (for only IC-A220)
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[D-CONNECT UNIT] (for only IC-A220)
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
(Amended page)
July 2019
D5 1750004020 S.DIO DFM3MF2 T 14.0/6.0
D6 1750002020 S.DIO DA2S10100L T 46.1/11.1
D7 1750002040 S.ZEN DZ2J091M0L T 22.2/10.5
D10 1750001810 S.DIO L1SS400T1G T 47.9/19.5
L1 6110001660 COI LA-252
R1 7030015190 S.RES RMC1/16-332JTP (3.3 k) T 18.2/5.4
R2 7030015190 S.RES RMC1/16-332JTP (3.3 k) T 6.8/7.8
R3 7030015190 S.RES RMC1/16-332JTP (3.3 k) T 6.8/3.3
R4 7030015190 S.RES RMC1/16-332JTP (3.3 k) T 25.2/13.8
R5 7030015190 S.RES RMC1/16-332JTP (3.3 k) T 23.6/13.8
R6 7030015190 S.RES RMC1/16-332JTP (3.3 k) T 26.8/13.8
R7 7030015330 S.RES RMC1/16-473JTP (47 k) T 30.3/19.5
R8 7030015330 S.RES RMC1/16-473JTP (47 k) T 43.7/19.5
R10 7030015370 S.RES RMC1/16-104JTP (100 k) T 49.3/19.5
R11 7540000250 ABS SA05C 401N
R12 7030015010 S.RES RMC1/16-101JTP (100) T 50.1/11.1
R13 7030015010 S.RES RMC1/16-101JTP (100) T 52.1/11.1
R14 7030015520 S.RES RMC1/16JPTP T 34.8/11.1
R15 7030015520 S.RES RMC1/16JPTP T 32.8/11.1
R16 7030015520 S.RES RMC1/16JPTP T 38.3/11.1
R17 7030015640 S.RES RMC1/10JPTP T 40.4/11.3
R19 7540000410 ABS ERZV14D470
R20 7030015520 S.RES RMC1/16JPTP T 44.1/11.1
R21 7030015200 S.RES RMC1/16-392JTP (3.9 k) T 24.4/11.1
R22 7030015190 S.RES RMC1/16-332JTP (3.3 k) T 26.0/11.1
C1 4030023860 S.CER 0603B103K500CT B 54.2/6.9
Eqv. 4030026180 S.CER MG18B103K500CT
C2 4030024290 S.CER 0805B103K500CT T 46.5/10.9
C3 4030024300 S.CER 0805B104K500CT B 99.4/8.4
C4 4030023850 S.CER 0603B102K500CT T 55.5/5.3
Eqv. 4030026460 S.CER MG18B102K500CT
C5 4030023850 S.CER 0603B102K500CT T 28.4/13.8
Eqv. 4030026460 S.CER MG18B102K500CT
C6 4030023850 S.CER 0603B102K500CT T 28.7/19.5
Eqv. 4030026460 S.CER MG18B102K500CT
C7 4030023850 S.CER 0603B102K500CT B 127.5/6.6
Eqv. 4030026460 S.CER MG18B102K500CT
C8 4030023850 S.CER 0603B102K500CT B 114.3/25.9
Eqv. 4030026460 S.CER MG18B102K500CT
C9 4030023850 S.CER 0603B102K500CT T 53.2/14.3
Eqv. 4030026460 S.CER MG18B102K500CT
C10 4030023850 S.CER 0603B102K500CT B 4.6/23.4
Eqv. 4030026460 S.CER MG18B102K500CT
C11 4030023850 S.CER 0603B102K500CT B 16.7/24.3
Eqv. 4030026460 S.CER MG18B102K500CT
C12 4030023850 S.CER 0603B102K500CT T 82.1/7.7
Eqv. 4030026460 S.CER MG18B102K500CT
C13 4030023850 S.CER 0603B102K500CT T 90.4/14.9
Eqv. 4030026460 S.CER MG18B102K500CT
C14 4030023850 S.CER 0603B102K500CT B 134.5/15.8
Eqv. 4030026460 S.CER MG18B102K500CT
C15 4030023850 S.CER 0603B102K500CT B 134.5/10.6
Eqv. 4030026460 S.CER MG18B102K500CT
C16 4030023850 S.CER 0603B102K500CT B 56.8/6.9
Eqv. 4030026460 S.CER MG18B102K500CT
C17 4030023850 S.CER 0603B102K500CT T 56.3/13.4
Eqv. 4030026460 S.CER MG18B102K500CT
C18 4030023850 S.CER 0603B102K500CT B 131.3/7.5
Eqv. 4030026460 S.CER MG18B102K500CT
C19 4030023850 S.CER 0603B102K500CT B 134.5/11.9
Eqv. 4030026460 S.CER MG18B102K500CT
C20 4030023850 S.CER 0603B102K500CT B 143.2/13.3
Eqv. 4030026460 S.CER MG18B102K500CT
C21 4030023850 S.CER 0603B102K500CT B 143.2/14.6
Eqv. 4030026460 S.CER MG18B102K500CT
C22 4030011070 S.CER GRM31M2C2H5R0CY21L
(GRM42-6) B 136.0/17.1
C23 4030011070 S.CER GRM31M2C2H5R0CY21L
(GRM42-6) B 74.3/6.2
C24 4030023850 S.CER 0603B102K500CT T 17.8/7.4
Eqv. 4030026460 S.CER MG18B102K500CT
C25 4030023870 S.CER 0603B104K500CT T 12.7/107.9
Eqv. 4030026160 S.CER MG18B104K500CT
C26 4030018910 S.CER C1608 JB 0J 475K-T T 3.4/104.0
C27 4030023460 S.CER 0603N101J500CT B 97.8/21.5
Eqv. 4030026120 S.CER MG18N101J500CT
C28 4510010810 S.ELE 50SVPF39M B 107.9/15.5
C29 4030023850 S.CER 0603B102K500CT T 37.1/11.1
Eqv. 4030026460 S.CER MG18B102K500CT
C30 4030023860 S.CER 0603B103K500CT B 108.9/22.5
Eqv. 4030026180 S.CER MG18B103K500CT
J1 6510014210 CON BNC-BJ 0E2-M100
J3 6510021071 CON S2P-VH (LF) (SN)
J4 6510030810 S.CON B15B-PH-SM4-TB (LF) (SN) T 38.1/4.5
J6 6510030790 CON SJ070010 (TMP-S01X-C1)
J7 6510031470 CON HSJ1650-010720
J8 6510030820 CON 1210-0V4-25P-AAE
F1 5210001070 S.FUS 0451008.MRL T 17.0/13.2
W1 7030014290 JUM RJ25S0OHM
EP1 6910014690 S.BEA MPZ1608S221A-T T 39.2/14.0
