The underlined parts have been updated from the addendum of the previous version, or from the original page.
5-52g
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[VOLUME-B UNIT] (for only IC-A220)
REF PART
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
(Amended page)
July 2019
R1 7210003270 VAR TP76N00NA-26F-10KB-2974
R2 7030015010 S.RES RMC1/16-101JTP (100) T 12.7/2.3
R3 7030015010 S.RES RMC1/16-101JTP (100) T 12.7/3.5
C1 4030023860 S.CER 0603B103K500CT T 12.7/4.7
Eqv. 4030026180 S.CER MG18B103K500CT
C2 4030023860 S.CER 0603B103K500CT T 12.7/1.1
Eqv. 4030026180 S.CER MG18B103K500CT
C3 4030023850 S.CER 0603B102K500CT T 12.8/7.6
Eqv. 4030026460 S.CER MG18B102K500CT
C4 4030023850 S.CER 0603B102K500CT T 12.8/6.4
Eqv. 4030026460 S.CER MG18B102K500CT
J1 6510025690 S.CON 06FLZ-RSM2-TB (LF) (SN) T 20.8/116.0
To Next Page
