Icom IC-A23 Service Manual

9 - 3
EXT SP/MIC
J2
ANTENNA
Battery
BP-200L
9—9.6 V
J3
40
21
20
1
CE SBATT CHGC TXC SDATA VCC VCC UNLK PCK PSTB PDATA EXTMIC GND +5V HV HV VORDET RFDET VORON RSSI
JACKDET VOLCK RFSTB SCK VOLDATA GND GND PTT EXTPTT LIGHT DASTB GND GND GND VREC GND BEEP MOD GND GND
to RF unit J3
J1
DC IN 9—12 V
CHG
12P1
SP1
3
12
PTT
LIGHT
1
2
3
MP1
2
7
6
1
4
5
9 - 2 RF UNIT
• TOP VIEW
The combination of this page and the next page shows
the unit layout in the same configuration as the actual
P.C. Board.
