Icom IC-F11 Service Manual

5 - 4
L16
PLL lock voltage adjustment
TOP VIEW
RF power meter
LV
PLL lock voltage check point
5-2 PLL ADJUSTMENT
PLL LOCK
VOLTAGE
1
2
3
• Operating frequency:
174.000 MHz
• Transmitting
• Operating frequency:
146.000 MHz
• Receiving
• Transmitting
MAIN Connect a digital multi
meter to check point
LV.
4.0 V
0.8–1.8 V
0.8–1.8 V
MAIN L16
Verify
ADJUSTMENT ADJUSTMENT CONDITIONS
UNIT LOCATION
VALUE
UNIT ADJUST
MEASUREMENT ADJUSTMENT
