Icom IC-F11 Service Manual

S.=Surface mount
[MAIN UNIT]
C239 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C240 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C242 4030008470 S.CERAMIC C1608 JB 1H 272K-T-A
C243 4030008770 S.CERAMIC C1608 JB 1H 562K-T-A
C244 4030007160 S.CERAMIC C1608 CH 1H 181J-T-A
C245 4030009630 S.CERAMIC C1608 JB 1H 822K-T-A
C246 4030007110 S.CERAMIC C1608 CH 1H 680J-T-A
C247 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C248 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C249 4030017480 S.CRAMIC C1608 JB 1A 474K-T-N
A only
C252 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C253 4030007000 S.CERAMIC C1608 CH 1H 090D-T-A
C255 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C257 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C258 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C259 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C260 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C261 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C262 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C265 4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
C266 4550000530 S.TANTALUM TESVA 1V 104M1-8L
C267 4030011770 S.CERAMIC C1608 CH 1H 060B-T-A
C268 4030009550 S.CERAMIC C1608 CH 1H 2R5B-T-A
C269 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C270 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
J1 6910013720 CONNECTOR IMSA-9230B-04Z120-T
C only
J2 6910013730 CONNECTOR IMSA-9230B-07Z120-T
J3 6510021900 S.CONNECTOR BM02B-ASRS-TF
J4 6450001680 CONNECTOR HSJ1122-010010
J5 6450001690 CONNECTOR HSJ1456-01-220
MC1 7700002540 MICROPHON SKP-4538
S1 2230001060 S.SWITCH EVQ-PUL 02K
S2 2230001060 S.SWITCH EVQ-PUL 02K
S3 2230001060 S.SWITCH EVQ-PUL 02K
W8 7030003860 S.JUMPER ERJ3GE JPW V
W11 7030003860 S.JUMPER ERJ3GE JPW V
D only
W12 7030003860 S.JUMPER ERJ3GE JPW V
D only
W13 7030003860 S.JUMPER ERJ3GE JPW V
D only
EP1 0910054482 PCB B 5680B
EP4 6910013370 S.BEAD BLM11B221SB
EP5 6910013370 S.BEAD BLM11B221SB
EP6 6910013370 S.BEAD BLM11B221SB
EP7 6910013370 S.BEAD BLM11B221SB A only
6 - 5
REF ORDER
DESCRIPTION
NO. NO.
A: [F12] and [F12S] B: [F11], [F11BR] and [F11S]
C: [F11]and [F12] D: [F11BR], [F11S] and [F12S]
