Icom IC-F210 Service Manual

S.=Surface mount
[MAIN UNIT][FRONT UNIT]
C78 4030017460 S.CERAMIC ECJ0EB1E102K
C79 4030016930 S.CERAMIC ECJ0EB1A104K
C80 4030016930 S.CERAMIC ECJ0EB1A104K
C81 4030017460 S.CERAMIC ECJ0EB1E102K
C82 4030017420 S.CERAMIC ECJ0EC1H470J
C83 4030017420 S.CERAMIC ECJ0EC1H470J
C84 4030017420 S.CERAMIC ECJ0EC1H470J
C85 4030017420 S.CERAMIC ECJ0EC1H470J
J1 6450002210 CONNECTOR 3017-8821 <KIN>
J2 6510022470 S.CONNECTOR 40FLT-SM1-TB
DS1 5040002310 S.LED SML-311YTT86
DS2 5040002310 S.LED SML-311YTT86
DS3 5040002310 S.LED SML-311YTT86
DS4 5040002310 S.LED SML-311YTT86
DS5 5040002310 S.LED SML-311YTT86
DS6 5040002310 S.LED SML-311YTT86
DS7 5040002310 S.LED SML-311YTT86
DS8 5040002310 S.LED SML-311YTT86
DS9 5040002310 S.LED SML-311YTT86
DS11 5030002510 LCD L2-0607TAY
SP1 2510001220 SPEAKER C052SB500-13
W1 8900010500 CABLE OPC-1046
EP1 0910055684 PCB B 5910D
EP2 8930059170 LCD CONTACT SRCN-2622-SP-N-W
IC1 1110003490 S.IC TA31136FN (D,EL)
IC2 1110002750 S.IC TA75S01F (TE85R)
IC3 1150002031 IC RA30H4452M-21
A
1150002061 IC RA45H4452M-21 B, K
1150002091 IC RA30H4047M-21 C
1150002141 IC RA45H4047M-21 D
IC4 1140005990 S.IC MB15A02PFV1-G-BND-ER
IC5 1110005330 S.IC NJM12904V-TE1
IC6 1190000350 S.IC M62363FP-650C
IC8 1110003090 IC LA4425A
IC9 1180001250 S.IC TA7808F (TE16L)
IC10 1180000970 S.IC AN78L05M-(E1)
IC14 1130008090 S.IC BU4066BCFV-E1
IC15 1110002750 S.IC TA75S01F (TE85R)
IC16 1110005340 S.IC NJM12902V-TE1
IC17 1130007570 S.IC BU4094BCFV-E2
Q1 1560000840 S.FET 2SK1829 (TE85R)
Q2 1580000730 S.FET 3SK293 (TE85L)
Q3 1580000760 S.FET 3SK299-T1 U73
Q4 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q5 1590000430 S.TRANSISTOR DTC144EUA T106
Q8 1530000371 S.TRANSISTOR 2SC3356-T1B R25
Q9 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q10 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q11 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q12 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q13 1530002920 S.TRANSISTOR 2SC4226-T1 R25
Q14 1530002920 S.TRANSISTOR 2SC4226-T1 R25
Q15 1590001400 S.TRANSISTOR XP1214 (TX)
Q16 1590000430 S.TRANSISTOR DTC144EUA T106
Q17 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q18 1560000540 S.FET 2SK880-Y (TE85R)
Q19 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q20 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
E only
Q23 1550000020 S.FET 2SJ377 (TE16R)
Q24 1590000430 S.TRANSISTOR DTC144EUA T106
Q25 1540000550 S.TRANSISTOR 2SD1664 T100Q
Q26 1510000920 S.TRANSISTOR 2SA1577 T106 Q
Q27 1510000920 S.TRANSISTOR 2SA1577 T106 Q
Q28 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q29 1590001050 S.TRANSISTOR DTC114TUA T106
Q30 1590000430 S.TRANSISTOR DTC144EUA T106
Q31 1590001450 S.FET 2SJ144-GR (TE85R)
Q33 1590000430 S.TRANSISTOR DTC144EUA T106
Q34 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q35 1590000990 S.TRANSISTOR DTC363EK T146
Q36 1590000430 S.TRANSISTOR DTC144EUA T106
Q37 1530003090 S.TRANSISTOR 2SC4213-B (TE85R)
Q38 1590000430 S.TRANSISTOR DTC144EUA T106
Q39 1590000430 S.TRANSISTOR DTC144EUA T106
D1 1790000660 S.DIODE MA728 (TX)
D2 1750000510 S.DIODE UM9401F
F only
D3 1710001060 DIODE XB15A407
E only
D4 1750000710 S.VARICAP HVC350BTRF
D5 1750000510 S.DIODE UM9401F
D7 1790000660 S.DIODE MA728 (TX)
D8 1750000710 S.VARICAP HVC350BTRF
D9 1750000710 S.VARICAP HVC350BTRF
D10 1750000710 S.VARICAP HVC350BTRF
D11 1790000660 S.DIODE MA728 (TX)
D14 1750000580 S.DIODE 1SV307 (TPH3)
D15 1790000620 S.DIODE MA77 (TX)
D16 1750000710 S.VARICAP HVC350BTRF
D17 1750000710 S.VARICAP HVC350BTRF
D18 1720000570 S.VARICAP MA368 (TX)
D20 1790001250 S.DIODE MA2S111-(TX)
D21 1750000830 S.VARICAP HVC362TRF
D22 1790000700 DIODE DSA3A1
D23 1750000370 S.DIODE DA221 TL
D25 1790001250 S.DIODE MA2S111-(TX)
D26 1790001250 S.DIODE MA2S111-(TX)
D28 1790001250 S.DIODE MA2S111-(TX)
D29 1790001250 S.DIODE MA2S111-(TX)
D31 1750000520 S.DIODE DAN222TL
D37 1790001250 S.DIODE MA2S111-(TX)
D38 1790001250 S.DIODE MA2S111-(TX)
D39 1160000140 S.DIODE DAP222 TL
D40 1160000140 S.DIODE DAP222 TL
D43 1750000710 S.VARICAP HVC350BTRF
G only
FI1 2030000150 S.MONOLITH FL-335 (46.350 MHz)
FI2 2020001840 CERAMIC ALFYM450F=K
FI3 2040001440 S.LC NFE31PT152Z1E9L (NFM60R20T152)
FI4 2040001440 S.LC NFE31PT152Z1E9L (NFM60R20T152)
FI5 2040001440 S.LC NFE31PT152Z1E9L (NFM60R20T152)
E only
X1 6070000190
S.DISCRIMINATOR CDBCB450KCAY24-R0 (CDBC450CX24)
X2 6050011540 S.XTAL CR-741 (15.300 MHz)
L1 6200010150 S.COIL AS080340-15N
L2 6200010150 S.COIL AS080340-15N
L3 6200010040 S.COIL AS100340-10N
L4 6200008210 S.COIL 0.45-1.5-5TL 23.2N
L5 6200010420 S.COIL FHW1210HC 1R0JGT
L7 6200007230 S.COIL
LQW2BHN15NJ01L (LQN21A 15NJ04)
H
6200007680 S.COIL LQW2BHN12NJ01L (LQN21A 12NJ04)
G
L8 6200007230 S.COIL LQW2BHN15NJ01L (LQN21A 15NJ04)
H
6200007680 S.COIL LQW2BHN12NJ01L (LQN21A 12NJ04)
G
6 - 2
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
A: 440–490 MHz for [F210] B: 440–490 MHz for [F211] C: 400–430 MHz for [F210] D: 400–430 MHz for [F211] E: [F221] and [F211]
F: [F210] G: 440–490 MHz H: 400–430 MHz I: Wide/Narrow J: Middle/Narrow K: [F221]
