Icom IC-F210 Service Manual

S.=Surface mount
[MAIN UNIT][MAIN UNIT]
R120 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R121 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R122 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R124 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R125 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R126 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R127 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R128 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R129 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R130 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R133 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R134 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R135 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R136 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R137 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R138 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R139 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R140 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R141 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R142 7410001130 S.ARRAY EXB28V102JX
R143 7410001130 S.ARRAY EXB28V102JX
R144 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R145 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R146 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R147 7410001130 S.ARRAY EXB28V102JX
R148 7410001130 S.ARRAY EXB28V102JX
R149 7410001130 S.ARRAY EXB28V102JX
R150 7410001130 S.ARRAY EXB28V102JX
R156 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R159 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R163 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R164 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R183 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R184 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R185 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R186 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R187 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R188 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R191 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R192 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R193 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R194 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R195 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R196 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R197 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R198 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R199 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R200 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R201 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R202 7030000440 S.RESISTOR MCR10EZHJ 3.3 kΩ
R203 7030000440 S.RESISTOR MCR10EZHJ 3.3 kΩ
R204 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R205 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R206 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R207 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R208 7030000440 S.RESISTOR MCR10EZHJ 3.3 kΩ
R209 7510001470 S.THERMISTOR NTCG20 4AG 473JT
R210 7030005871 S.RESISTOR ERA3YKD 104V (100 kΩ)
R211 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω)
R215 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R217 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R218 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R219 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R220 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R222 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R223 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R224 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R225 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R226 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R227 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R228 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R229 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R230 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R231 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R232 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R234 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R235 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R236 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R237 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 kΩ)
R238 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R240 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R241 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R242 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R243 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R244 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R245 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R246 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R247 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R248 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R249 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R250 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R251 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R252 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R261 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R262 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R263 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R264 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R265 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R266 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R267 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R268 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R269 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R270 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R271 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R285 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R287 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R290 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R291 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R292 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
G
7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ) H
R297 7030005651 S.RESISTOR ERA3YKD 304V (300 kΩ)
R298 7030005871 S.RESISTOR ERA3YKD 104V (100 kΩ)
R304 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R305 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R306 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R308 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R309 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R310 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R315 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R316 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R317 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R318 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R319 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R320 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R321 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
F only
R322 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R323 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
G only
C1 4030011040 S.CERAMIC
GRM31M4C2H2R0CY21L (GRM42-6 CK)
E
4030011100 S.CERAMIC GRM31M2C2H8R0DV01L (GRM42-6 CH)
F
C2 4030011060 S.CERAMIC GRM31M2C2H4R0CY21L (GRM42-6 CH)
E
4030011080 S.CERAMIC GRM31M2C2H6R0DV01L (GRM42-6 CH)
F
C3 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C4 4030006990 S.CERAMIC C1608 CH 1H 080D-T
E
4030007010 S.CERAMIC C1608 CH 1H 100D-T F
C5 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C6 4030011020 S.CERAMIC GRM31M4C2H1R0CY21L (GRM42-6 CK)
C7 4030011040 S.CERAMIC GRM31M4C2H2R0CY21L (GRM42-6 CK)
B, K
4030011060 S.CERAMIC GRM31M2C2H4R0CY21L (GRM42-6 CH)
D, E
C8 4030011020 S.CERAMIC GRM31M4C2H1R0CY21L (GRM42-6 CK)
C9 4030011060 S.CERAMIC GRM31M2C2H4R0CY21L (GRM42-6 CH)
C10 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C11 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C12 4030011340 S.CERAMIC C1608 CH 1H 471J-T
C13 4030007090 S.CERAMIC C1608 CH 1H 470J-T
C14 4030011240 S.CERAMIC
GRM31M2C2H470JV01L (GRM42-6 CH)
6 - 4
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
A: 440–490 MHz for [F210] B: 440–490 MHz for [F211] C: 400–430 MHz for [F210] D: 400–430 MHz for [F211] E: [F221] and [F211]
F: [F210] G: 440–490 MHz H: 400–430 MHz I: Wide/Narrow J: Middle/Narrow K: [F221]
