Icom IC-F3 Service Manual

S.=Surface mount
Ò: L-band, Ó: H-band, N: N-type, M: M-type, W: W-type
e: ETS/CEPT version, u: EIA/TIA version
R115 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R116 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R117 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R119 7310004140 S.TRIMMER EVM-1YSX50 B35 (304)
R120 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R121 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R122 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R123 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R125 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R126 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R127 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω)
R128 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R130 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R131 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R132 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R133 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R134 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R135 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R137 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R139 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R141 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R142 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R144 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R145 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R146 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R147 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R148 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R149 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R150 7310004110 S.TRIMMER EVM-1YSX50 B54 (503)
R151 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R153 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R154 7030008120 S.RESISTOR RR0816P-682-D (6.8 kΩ)
R155 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R156 7030000160 S.RESISTOR MCR10EZHJ 15 Ω (150)
R157 7030000160 S.RESISTOR MCR10EZHJ 15 Ω (150)
R158 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R159 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R160 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R161 7030007330 S.RESISTOR ERJ1WRSJR15U (0.15 Ω)
R162 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R163 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R166 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R167 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R168 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R169 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R170 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R171 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R174 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R175 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R176 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R177 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R178 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R181 7030005870 S.RESISTOR RR0816R-104-D (100 kΩ)
R182 7510000910 S.THERMISTOR NTCCF2012 4AH 473KC-T
R183 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R184 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R185 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R186 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R187 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R190 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R191 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R192 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R193 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R194 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R195 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R196 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R197 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R198 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R199 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R200 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R201 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R202 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R203 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R204 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R205 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R207 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R208 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R209 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R210 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R213 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R214 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
[MAIN UNIT][MAIN UNIT]
R20 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R21 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R22 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R23 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R24 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R25 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R26 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R27 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R28 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R29 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R30 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R31 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R32 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R33 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R34 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R35 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R41 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) Ò
7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) Ó
R42 7410000950 S.ARRAY EXB-V8V 102JV
R44 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R45 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R48 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R49 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R50 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R51 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R52 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R53 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R54 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R55 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R57 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R58 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R59 7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω)
R61 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R62 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R63 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R64 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R65 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R66 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R67 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R68 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R69 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R70 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R72 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R75 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R77 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R79 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R80 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R81 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R82 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ) N
7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) M
7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ) W
R83 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R84 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R85 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R86 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R87 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R88 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R91 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) N
7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
M, W
R92 7310004110 S.TRIMMER EVM-1YSX50 B54 (503)
R93 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R94 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R95 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R96 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R97 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R98 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R99 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R100 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R101 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R102 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R103 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R104 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R105 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R106 7410000950 S.ARRAY EXB-V8V 102JV
R107 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R108 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R109 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R112 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R113 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R114 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) N
7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) M, W
6 - 2
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
F3/S
