3 - 2
3-2 OPTIONAL UNIT INSTALLATIONS
1 Remove the option cover.
2 Remove the bottom protective paper of sponge.
3 Connect either a UT-80, UT-96 or UT-105 optional unit to J5.
4 Attached the 1556 sponge to the specified position at the unit as following illustration.
5 Replace the option cover to the chassis-hole.
Option cover
Option unit
J5
SPONGE
Parts name : 1556 sponge
Order No. : 8930013545
UT-80 UT-96
To Next Page
