Icom IC-F3

F3/S
The combination of this page and the next page
shows the unit layout in the same configuration as
the actual P.C. Board.
BATT
VOLIN
VOLOUT
GND
VCC
to
MAIN UNIT
J7
9 - 2 VR BOARD (common)
• TOP VIEW
9 - 1
SECTION 9 BOARD LAYOUTS
9-1 IC-F3/S MAIN UNIT
• TOP VIEW
VCC
VOL GND
VOL OUT
VOL IN
HV
to VR UNIT
SP SPG
P1
ANTENNA
SPEAKER
SP1
MICROPHONE
