Icom IC-F4003 User Manual

6 - 4
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
C391 4030011320 S.CER C1005 CH 1H 470J-T B 37.3/46.3
C393 4520000020 S.NIO NOJC227M006 B 19.8/40.9
C395 4520000020 S.NIO NOJC227M006 T 21.7/37.1
C397 4030019740 S.CER C1005 JB 1H 102K-T T 26/36.5
C398 4030019740 S.CER C1005 JB 1H 102K-T B 12.2/32
C399 4030019930 S.CER C1005 JB 1A 104K-T B 22.2/37.1
C400 4550006250 S.TAN TEESVA 1A 106M8R T 12.9/40.8
C401 4030019930 S.CER C1005 JB 1A 104K-T B 12.2/37.6
C403 4030019930 S.CER C1005 JB 1A 104K-T B 15.8/39.6
C404 4030019930 S.CER C1005 JB 1A 104K-T B 12.2/38.5
C405 4030019970 S.CER C1005 JB 0J 105K-T B 19.3/33.7
C406 4030019740 S.CER C1005 JB 1H 102K-T T 20.7/32.2
C408 4030019930 S.CER C1005 JB 1A 104K-T T 5.2/37.8
C410 4030019740 S.CER C1005 JB 1H 102K-T T 11.3/39.3
C412 4030019740 S.CER C1005 JB 1H 102K-T T 6.5/42.8
C413 4030019740 S.CER C1005 JB 1H 102K-T T 6.8/44.8
C414 4030019740 S.CER C1005 JB 1H 102K-T T 8.1/23.1
C415 4030019740 S.CER C1005 JB 1H 102K-T T 6.5/30.8
C416 4030019740 S.CER C1005 JB 1H 102K-T T 6.1/23.1
C417 4030019740 S.CER C1005 JB 1H 102K-T T 3.7/30.8
C421 4030019930 S.CER C1005 JB 1A 104K-T T 75.4/12
C423 4030019810 S.CER C1005 JB 1E 103K-T B 65.2/38.4
C424 4030019740 S.CER C1005 JB 1H 102K-T T 63.8/34.4
C426 4030019810 S.CER C1005 JB 1E 103K-T B 69/30.3
C427 4030019930 S.CER C1005 JB 1A 104K-T T 73.7/26
C429 4030019810 S.CER C1005 JB 1E 103K-T B 77.2/25.7
C430 4030019930 S.CER C1005 JB 1A 104K-T T 65.9/11.4
C431 4510009870 S.ELE 10 CE 100 LD T 14.7/27.1
C432 4030019740 S.CER C1005 JB 1H 102K-T T 14.3/31.7
C433 4030019930 S.CER C1005 JB 1A 104K-T T 16.2/32.2
C434 4030019810 S.CER C1005 JB 1E 103K-T T 14.3/32.6
C435 4030019740 S.CER C1005 JB 1H 102K-T T 18/32.2
C436 4550007320 S.TAN F930J226MAABMA B 85.2/44.4
C437 4030019930 S.CER C1005 JB 1A 104K-T T 17.1/32.2
C451 4030009790 S.CER C1005 CH 1H 330J-T B 86.6/38.5
C452 4030009740 S.CER C1005 CH 1H 100C-T B 86.1/37.3
C453 4030009770 S.CER C1005 CH 1H 220J-T B 87/35.2
C454 4030019930 S.CER C1005 JB 1A 104K-T B 86.1/32.2
C456 4030019930 S.CER C1005 JB 1A 104K-T B 87.9/32.2
C457 4030019870 S.CER C1005 JB 1A 273K-T B 86.8/46.9
C458 4030019930 S.CER C1005 JB 1A 104K-T T 84.7/45.5
C459 4030019930 S.CER C1005 JB 1A 104K-T B 85.2/40.6
C460 4030019930 S.CER C1005 JB 1A 104K-T B 79.5/46.1
C461 4030019930 S.CER C1005 JB 1A 104K-T B 80.4/46.1
C462 4030019930 S.CER C1005 JB 1A 104K-T B 81.3/46.1
C465 4030019930 S.CER C1005 JB 1A 104K-T T 77.4/35
C466 4030019810 S.CER C1005 JB 1E 103K-T T 79/35
C467 4030019930 S.CER C1005 JB 1A 104K-T B 85.2/32.2
J51 6450000131 CON HSJ1102-018540
J52 6450002250 CON HSJ1456-010320
J53 6510021901 S.CON BM02B-ASRS-TF(LF)(SN) T 30.5/34.5
F51 5210000970 S.FUS ERBSE3R00U T 10.7/37.6
DS51 5040002670 S.LED CL-165HR/YG T 2.6/37.9
MC51 7700002920 MIC EM9745P-38-G-01 <HOR>
S51 2260001900 SWI SW-149 (SKHLLD)
S52 2260002800 S.SWI SW-167 (SKQTLAE010) B 39.2/1.8
S53 2260002800 S.SWI SW-167 (SKQTLAE010) B 48.7/1.8
S54 2250000670 ENC TP70TF5169-15.9F-3285
EP3 6910018460 S.BEA MMZ1005Y102C-T T 63.7/19.3
EP4 6910018460 S.BEA MMZ1005Y102C-T T 41.9/19.4
EP5 6910018460 S.BEA MMZ1005Y102C-T T 41/10.9
EP6 6910014730 S.BEA MPZ2012S331A-T B 22.4/17
EP11 6910021240 S.BEA MMZ1005A152ET T 54.9/24.5
EP14 6910021240 S.BEA MMZ1005A152ET T 60.4/22.2
EP51 6910018460 S.BEA MMZ1005Y102C-T B 20.3/46.6
MP3 8510016471 S.CAS 2775 VCO CASE-1 T 58.8/23.2
MP4 6910014760 S.PLA OG-503040 B 66.8/18.4
MP5 6910014760 S.PLA OG-503040 B 17.9/9.5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
