7 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the BoTom side)
S.=Surface mount
[MAIN-A UNIT] (for Low band)
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R78 7030005310 S.RES ERJ2GEJ 124 X (120 k) B 74.9/29.1
R79 7030006020 S.RES RR0510P-682-D (6.8 k) B 74.7/34.3
R80 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 75.5/28.7
R82 7030010040 S.RES ERJ2GEJ-JPW B 74.3/23.7
R83 7030006020 S.RES RR0510P-682-D (6.8 k) B 74.3/22.7
R84 7030006020 S.RES RR0510P-682-D (6.8 k) B 72.8/24.9
R85 7030006020 S.RES RR0510P-682-D (6.8 k) B 72.2/34.3
R86 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 69.3/22.5
R87 7030005000 S.RES ERJ2GEJ 471 X (470) T 69.5/32.4
R88 7030009280 S.RES ERJ2GEJ 391 X T 73.3/32.7
R89 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 77.5/30.1
R90 7030005170 S.RES ERJ2GEJ 474 X (470 k) T 71/22.5
R91 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 72.7/20.7
R92 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 72.7/22.5
R94 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) T 77.1/33.1
R95 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) T 76/30.1
R96 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 77.1/32.2
R98 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 99/22.1
R100 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 74.4/22.5
R101 7030004990 S.RES ERJ2GEJ 221 X (220) T 77.1/28.7
R103 7030005230 S.RES ERJ2GEJ 334 X (330 k) B 46.2/38.1
R104 7030005700 S.RES ERJ2GEJ 274 X (270 k) B 47.2/38.1
R105 7030005230 S.RES ERJ2GEJ 334 X (330 k) B 46.2/39.7
R106 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 47.2/39.7
R108 7030004980 S.RES ERJ2GEJ 101 X (100) B 65.2/37.7
R110 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 69.3/20.7
R111 7030006610 S.RES ERJ2GEJ 394 X (390 k) T 66.6/34.9
R115 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 83.4/25.7
R116 7030007060 S.RES ERJ2GEJ 684X (680 k) T 80.7/25.5
R121 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 68.9/41.3
R122 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 98.2/39.1
R123 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 99.8/42.1
R125 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 39.8/6.2
R126 7030004980 S.RES ERJ2GEJ 101 X (100) B 23.2/4.5
R127 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) B 33.7/10.9
R128 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) B 33.7/9.2
R129 7030005720 S.RES ERJ2GEJ 563 X (56 k) B 35.7/9.2
R133 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 35.4/5.3
R134 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 43.9/8.5
R135 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) B 43.9/9.5
R136 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 40.7/9.5
R137 7030005080 S.RES ERJ2GEJ 823 X (82 k) B 45/12.8
R138 7030005000 S.RES ERJ2GEJ 471 X (470) B 45/14.4
R139 7030005700 S.RES ERJ2GEJ 274 X (270 k) B 43.8/16.6
R140 7030005700 S.RES ERJ2GEJ 274 X (270 k) B 42.1/17.5
R141 7030010040 S.RES ERJ2GEJ-JPW B 37.4/18.6
R142 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) B 36.7/9.2
R143 7030005100 S.RES ERJ2GEJ 154 X (150 k) B 33.7/16
R144 7030005700 S.RES ERJ2GEJ 274 X (270 k) B 37.4/17.5
R145 7030005100 S.RES ERJ2GEJ 154 X (150 k) B 34.7/17.7
R146 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 34.7/16
R147 7030005100 S.RES ERJ2GEJ 154 X (150 k) B 35.7/17.7
R148 7030005000 S.RES ERJ2GEJ 471 X (470) B 37.4/16.3
R149 7030006610 S.RES ERJ2GEJ 394 X (390 k) B 33.7/17.7
R151 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 35/38.5
R152 7030005230 S.RES ERJ2GEJ 334 X (330 k) B 34.1/42.9
R153 7030005310 S.RES ERJ2GEJ 124 X (120 k) B 35.9/42.9
R154 7030005080 S.RES ERJ2GEJ 823 X (82 k) B 35.9/41.3
R155 7030005720 S.RES ERJ2GEJ 563 X (56 k) B 35.9/37.1
R156 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 48.1/16.4
R157 7030004980 S.RES ERJ2GEJ 101 X (100) B 30.1/8
R158 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 37.9/37.1
R159 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 35.9/39.7
R160 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 35/39.7
R161 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 48/19.3
R162 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 48/18.4
R163 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 87.6/11.7
R164 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 85.7/10.5
R165 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 102.6/14.7
R166 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 101.2/24.6
R167 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 48.2/6.3
R168 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 49.1/6.3
R169 7030004980 S.RES ERJ2GEJ 101 X (100) B 101.2/25.5
R172 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 90.8/35.2
R181 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 57/6.3
R182 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 57/8
R183 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 55.2/8
R184 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 53.4/10
R185 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) B 52.4/10
R186 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 57/10
R187 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 55.2/12.8
R188 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 53.4/8
R190 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) B 54.3/12.8
R194 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 56.8/21
R195 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 60.2/23.5
R196 7030007350 S.RES ERJ2GEJ 393 X (39 k) B 60.2/24.4
R197 7030005080 S.RES ERJ2GEJ 823 X (82 k) B 60.2/26.7
R198 7030008300 S.RES ERJ2GEJ 184 X (180 k) B 56.8/24.4
R199 7030006610 S.RES ERJ2GEJ 394 X (390 k) B 58.4/24.4
R200 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) B 11.2/32.3
R201 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 96.6/39.1
[MAIN-A UNIT] (for Low band)
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R202 7030004980 S.RES ERJ2GEJ 101 X (100) T 96.6/38.1
R203 7030010040 S.RES ERJ2GEJ-JPW B 58.4/25.4
R209 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 47.2/41.3
R210 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 46.2/42.9
R211 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 46.2/41.3
R213 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 42.2/37
R214 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 44.2/37
R215 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 54.8/32
R216 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 56.6/32
R217 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 60.2/30
R218 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 60.2/32
R219 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 58.4/33
R220 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 60.2/34
R221 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 48.2/39.7
R222 7030008300 S.RES ERJ2GEJ 184 X (180 k) B 7.2/18.6
R223 7030005720 S.RES ERJ2GEJ 563 X (56 k) B 7.2/20.2
R224 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 7.2/21.1
R225 7030007260 S.RES ERJ2GEJ 330 X (33) T 94.4/20.7
R226 7030005300 S.RES ERJ2GEJ 150 X (15) T 94.5/16
R227 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) T 97.4/22.5
R228 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 95.6/22.5
R229 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 95.3/26.8
R230 7030005230 S.RES ERJ2GEJ 334 X (330 k) B 34.1/22.6
R231 7030005100 S.RES ERJ2GEJ 154 X (150 k) B 34.1/21.6
R233 7030004980 S.RES ERJ2GEJ 101 X (100) T 98.7/12.1
R234 7030005530 S.RES ERJ2GEJ 100 X (10) T 103.3/16.8
R235 7030005000 S.RES ERJ2GEJ 471 X (470) T 80.5/8
R236 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 77.2/8.5
R237 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) T 78.7/5.5
R238 7030005000 S.RES ERJ2GEJ 471 X (470) B 85.7/5.4
R239 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 26.3/19.5
R240 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 50.4/24.4
R241 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 50.4/28.6
R242 7030005230 S.RES ERJ2GEJ 334 X (330 k) B 50.4/27.6
R243 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 52/24.4
R244 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 53.6/24.4
R245 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 50.4/25.4
R246 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 45.8/32.1
R247 7030005000 S.RES ERJ2GEJ 471 X (470) B 45.8/35.1
R248 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 43.9/5.3
R249 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 45.2/21.2
R254 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 58.4/34
R255 7030008290 S.RES ERJ2GEJ 183 X (18 k) B 56.6/33
R256 7510001730 S.TMR ERTJOEP 473J B 18.7/39.4
R257 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 18.7/37.4
R258 7030005530 S.RES ERJ2GEJ 100 X (10) B 24.7/31.3
R259 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 26.3/33.4
R260 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 27.7/28.4
R261 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 26.3/29.4
R262 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 26.3/28.4
R263 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 16.8/41.4
R264 7030005820 S.RES RR0510P-103-D (10 k) B 10.7/4.7
R265 7030005820 S.RES RR0510P-103-D (10 k) B 8.8/4.7
R272 7030004980 S.RES ERJ2GEJ 101 X (100) T 55.5/4.8
R273 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 7.3/9.5
R274 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 7.3/10.4
R275 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 7.3/11.3
R276 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 7.1/14.2
R277 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 10.6/37
R278 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 14.5/40.1
R279 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 12.8/4.7
R280 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 14.2/4.7
R281 7030009270 S.RES ERJ2GEJ 821 X (820) B 18.6/4
R288 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 7.1/15.6
R291 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 9.9/15.2
R292 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 5.5/31.5
R293 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 5.5/32.5
R295 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 62.1/14.1
R300 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 61.7/16.4
R302 7030006610 S.RES ERJ2GEJ 394 X (390 k) T 73.5/26.8
R303 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 73.6/25.6
R304 7030010040 S.RES ERJ2GEJ-JPW B 72.4/31.8
R305 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 68.3/32.6
R306 7030005530 S.RES ERJ2GEJ 100 X (10) B 68.5/24.3
R307 7030005580 S.RES ERJ2GEJ 560 X (56) T 84.5/34.2
R308 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 67.7/21.6
R309 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 48.2/41.3
R315 7210003061 VAR TP76N00N-15F-A103-2251A
R321 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 14.5/41.4
R345 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 82/39.3
R346 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 82.9/39.3
R347 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 83.8/39.3
R348 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 84/30.1
R349 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 26.3/23
R350 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 8.5/29.4
R351 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 26.3/21.6
R352 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 7.6/27.6
R353 7410001130 S.ARY EXB28V102JX B 12.1/15.7
R354 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 13.2/35
R361 7030005000 S.RES ERJ2GEJ 471 X (470) B 90.9/26.3
R363 7030005100 S.RES ERJ2GEJ 154 X (150 k) T 84/27.7
