S.=Surface mount
6 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R57 7030005590 S.RES ERJ2GEJ 680 X (68
Ω
) T 56.5/28.5
R58 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 54.6/27.5
R59 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 54.6/26.5
R61 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 54.1/30.8
R62 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 52.6/31.3
R63 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 53.6/26.7
R65 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) B 51.6/26.7
R67 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 53.1/25.2
R68 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 53.6/23.8
R69 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 52.2/19.9
R70 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 49.3/24.7
R71 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 49.3/23.7
R72 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) B 48.6/24.3
R75 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 44.2/30.1
R76 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 44.5/34.9
R77 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 49.3/26.7
R78 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 47.3/26.4
R79 7030008340 S.RES RR0510P-182-D (1.8 k
Ω
) B 43.9/32.3
R80 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 44.7/24
R81 7030010040 S.RES ERJ2GE-JPW B 42.9/32.3
R82 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) B 44/24.8
R83 7030008340 S.RES RR0510P-182-D (1.8 k
Ω
) B 45/24.8
R84 7030011000 S.RES RR0510P-392-D (3.9 k
Ω
) B 43/25.6
R85 7030011000 S.RES RR0510P-392-D (3.9 k
Ω
) B 45.9/32.3
R86 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 36.4/22.2
R87 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 45.5/28.3
R88 7030008370 S.RES ERJ2GEJ 561 X (560
Ω
) T 46.2/24.3
R89 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 44.5/17.3
R90 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 32.2/14
R91 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 31.2/14
R92 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 29.2/14
R93 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 31/28.4
R94 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) B 30.9/29.7
R95 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) T 40.7/20.7
R96 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
) T 40.7/19.7
R97 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 32.6/25.6
R98 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 45/37.6
R100 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 47.1/15.2
R101 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 45.5/15.2
R102 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 19.1/3.7
R103 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 29.1/23.8
R104 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 26.1/14.6
R105 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) T 30.7/22.2
R108 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 24.6/27.4
R109 7030005580 S.RES ERJ2GEJ 560 X (56
Ω
) T 34.3/31.6
R110 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 30.3/15
R111 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 30.4/32.7
R113 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 37.2/26.8
R115 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
) B 27.1/19.8
R116 7030007060 S.RES ERJ2GEJ 684X (680 k
Ω
) B 25.3/19.8
R117 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 31.7/19.3
R118 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 30.7/19.3
R119 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 18.4/12.7
R120 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 25.2/12.7
R121 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) T 27.1/17.2
R122 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) T 27.1/18.2
R123 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) T 13/16.9
R124 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 13.5/15.6
R125 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 16.6/14.3
R126 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 14/18.7
R127 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 20.7/24.8
R128 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 21.7/24.8
R129 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 21.8/13.3
R130 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 22.4/19.2
R131 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 22.9/21.5
R132 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 24.2/22
R133 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 24.3/21.9
R134 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 25.9/20.6
R135 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 14/21.5
R139 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 4.8/21
R141 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 26.5/32.2
R144 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
)
Except [USA-02], [EUR-02], [GEN-02] B 22.5/36.5
R145 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
)
Except [USA-02], [EUR-02], [GEN-02] B 24.3/36.5
R147 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 29.8/5.3
R148 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 30.3/4
R150 7030010040 S.RES ERJ2GE-JPW [EUR-88] only T 16.7/3
R151 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 26.6/10.7
R152 7030008310 S.RES ERJ2GEJ 564 X (560 k
Ω
) T 28.1/3
R153 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 26.1/7.1
R154 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
)
[EUR-88] only T 27.1/7.1
R155 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 27.1/3
R157 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 25.4/3.4
R161 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 50.9/36.6
R162 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 49.6/36.1
R163 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 34.5/39.8
R164 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 32.7/37.4
R165 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 74.6/28.5
R166 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 69.8/28.8
R167 7030005700 S.RES ERJ2GEJ 274 X (270 k
Ω
) T 75.1/24.4
R168 7030010080 S.RES ERJ2RHD 104 X (100 k
Ω
) T 76.1/23.5
R169 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 47.7/40.7
R170 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 46.3/41.2
R171 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 50.1/10.5
R172 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 50.1/8.7
R173 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) T 44.5/9.6
R174 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 43.5/9.6
R175 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 44/10.9
R180 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 5.8/22.9
R181 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 31.9/2.6
R182 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 32.4/4
R183 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 31.9/5.3
R184 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 34.2/11.4
R185 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 34.2/12.4
R186 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 4.8/22.9
R187 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
)
[EUR-88] only T 31.2/16
R188 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
)
[EUR-88] only T 28.2/14.6
R189 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
)
[EUR-88] only T 29.4/14
R190 7510001730 S.TMR ERTJOEP 473J B 25.9/31.9
R191 7030010080 S.RES ERJ2RHD 104 X (100 k
Ω
) B 24.7/29.8
R192 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 13.6/31.8
R193 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 13.6/30
R194 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 20.4/38.2
R195 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
)
Except [USA-02], [EUR-02], [GEN-02] T 14.3/36.7
R196 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 25.2/11.7
C1 4030007000 S.CER C1608 CH 1H 090D-T B 69.9/9.8
C2 4030006990 S.CER C1608 CH 1H 080D-T B 65.8/6.9
C3 4030009650 S.CER C1608 CH 1H 240J-T B 67.9/4.7
C4 4030011530 S.CER C1608 CH 1H 110J-T B 63.1/7.3
C5 4030007050 S.CER C1608 CH 1H 220J-T B 61.1/4.5
C6 4030017460 S.CER ECJ0EB1E102K B 60.4/6.2
C7 4030017460 S.CER ECJ0EB1E102K B 61.6/9
C8 4030007040 S.CER C1608 CH 1H 180J-T B 64.1/9.8
C9 4030007030 S.CER C1608 CH 1H 150J-T B 59.1/13
C10 4030017460 S.CER ECJ0EB1E102K B 64.4/13
C11 4030007050 S.CER C1608 CH 1H 220J-T B 66.3/15.9
C13 4030007100 S.CER C1608 CH 1H 560J-T B 68.2/16.4
C14 4030011530 S.CER C1608 CH 1H 110J-T B 59.7/4.5
C15 4030017460 S.CER ECJ0EB1E102K B 54.6/14.4
C16 4030017400 S.CER ECJ0EC1H220J B 54.2/7.3
C17 4030017630 S.CER ECJ0EC1H120J T 59.7/6.4
C18 4030017380 S.CER ECJ0EC1H050B T 57/5.1
C19 4030017460 S.CER ECJ0EB1E102K T 57.9/6.4
C20 4030017430 S.CER ECJ0EC1H101J T 53.5/3.8
C22 4030017340 S.CER ECJ0EC1H010B T 52.4/6.4
C23 4030016930 S.CER ECJ0EB1A104K T 42.5/9.6
C24 4030017460 S.CER ECJ0EB1E102K B 52.9/9.8
C25 4030017580 S.CER ECJ0EC1H060C T 56.1/6.4
C26 4030017430 S.CER ECJ0EC1H101J T 50.2/3.8
C27 4030017460 S.CER ECJ0EB1E102K T 52.4/5.1
C28 4030017370 S.CER ECJ0EC1H3R5B T 49/5.1
C29 4030017560 S.CER ECJ0EC1H2R5B T 48.7/6.4
C30 4030016930 S.CER ECJ0EB1A104K T 49.1/10.5
C31 4030016930 S.CER ECJ0EB1A104K B 51/8.2
C32 4030017460 S.CER ECJ0EB1E102K T 46.4/5.1
C33 4030017420 S.CER ECJ0EC1H470J T 46.8/6.4
C35 4030017490 S.CER C1608 JB 1A 105K-T B 49.6/7.2
C36 4030017460 S.CER ECJ0EB1E102K B 47.1/9.2
C37 4030016790 S.CER ECJ0EB1C103K T 45.4/6.9
C38 4030017360 S.CER ECJ0EC1H030B T 44.4/5.1
C39 4030017460 S.CER ECJ0EB1E102K T 43/3.8
C40 4030017550 S.CER ECJ0EC1H1R5B T 41/6.4
C41 4030017620 S.CER ECJ0EC1H100C B 41.9/7.3
C42 4030017460 S.CER ECJ0EB1E102K T 38/3.8
C43 4030017460 S.CER ECJ0EB1E102K T 41/5.1
C44 4030017570 S.CER ECJ0EC1H040B B 39.8/5.2
C45 4030017460 S.CER ECJ0EB1E102K T 39.8/3.8
C48 4030016790 S.CER ECJ0EB1C103K B 41.5/11.1
C49 4030017350 S.CER ECJ0EC1H020B B 44.1/10.6
C50 4030017460 S.CER ECJ0EB1E102K B 41.5/12.1
C51 4030017460 S.CER ECJ0EB1E102K B 37.6/7.7
C52 4030017630 S.CER ECJ0EC1H120J B 38.5/9.7
C53 4030016790 S.CER ECJ0EB1C103K B 36.6/8.7
C54 4030017460 S.CER ECJ0EB1E102K B 36.6/9.7
C55 4030017570 S.CER ECJ0EC1H040B B 37.6/5.7
C56 4030017400 S.CER ECJ0EC1H220J B 33.3/9.1
C57 4030017460 S.CER ECJ0EB1E102K B 35/12.2
C58 4030017460 S.CER ECJ0EB1E102K B 23.6/4.4
C59 4030017460 S.CER ECJ0EB1E102K B 22.3/8.9
C60 4030016790 S.CER ECJ0EB1C103K B 23.3/8.9
C61 4030017430 S.CER ECJ0EC1H101J B 19.1/5.8
C62 4030017680 S.CER ECJ0EC1H820J B 17.9/10.4
C63 4030017420 S.CER ECJ0EC1H470J B 18.9/7.4
C65 4030017460 S.CER ECJ0EB1E102K B 18.4/9.1
C66 4030017460 S.CER ECJ0EB1E102K B 18.4/11.7
C67 4030017460 S.CER ECJ0EB1E102K B 9.9/5.1
C68 4030017430 S.CER ECJ0EC1H101J B 13.6/14.7
