6 - 1
SECTION 6 PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1110003200 S.IC TA31136FN (EL) B 13.6/9.1
IC2 1110002750 S.IC TA75S01F (TE85R) T 52.3/18.1
IC4 1140005990 S.IC MB15A02PFV1-G-BND-ER B 28.7/24.1
IC5 1110005340 S.IC NJM12902V-TE1 T 30.4/9.7
IC6 1190000350 S.IC M62363FP-650C T 19.7/8.9
IC7 1190001860 S.IC EW-460-FT B 50.7/39.9
IC9 1110005350 S.IC NJM2870F05-TE1 T 73.8/28.6
IC10 1110006220 S.IC AK2346-E2 T 18.9/19.6
IC11 1130006220 S.IC TC4W53FU (TE12L) T 25.2/25
IC12 1130007570 S.IC BU4094BCFV-E2 T 16.9/32.2
IC13 1130008090 S.IC BU4066BCFV-E1 T 22.7/32.2
IC14 1110004990 S.IC FX214LG/TR
Except [USA-02], [EUR-02], [GEN-02] B 9.8/32.5
IC15 1130007990 S.IC TC3W03FU (TE12L)
Except [USA-02], [EUR-02], [GEN-02] B 22.5/33.4
IC16 1110005330 S.IC NJM12904V-TE1 T 29.6/28.4
IC17 1130004200 S.IC TC4S66F (TE85R) T 30.2/34.9
Q1 1560000840 S.FET 2SK1829 (TE85R) T 46.4/10.8
Q2 1580000730 S.FET 3SK293 (TE85L) T 47.3/8.2
Q3 1580000760 S.FET 3SK299-T1 U73 B 41.2/9.1
Q4 1530002600 S.TR 2SC4215-O (TE85R) B 21.3/4.5
Q7 1560001230 S.FET RD07MVS1 T 59.8/21.9
Q8 1560001240 S.FET RD01MUS1 T 60.2/28
Q9 1530003420 S.TR 2SC5110-O (TE85R) B 52.4/29
Q10 1530003310 S.TR 2SC5107-O (TE85R) B 47.9/21.9
Q11 1530003310 S.TR 2SC5107-O (TE85R) T 43.7/32.1
Q12 1530003310 S.TR 2SC5107-O (TE85R) B 47.6/29.5
Q13 1530002920 S.TR 2SC4226-T1 R25 B 45/22.4
Q14 1530002920 S.TR 2SC4226-T1 R25 B 43.9/29.9
Q15 1590001400 S.TR XP1214 (TX) T 45.8/26.2
Q16 1590000430 S.TR DTC144EUA T106 T 43.2/26.8
Q17 1530002850 S.TR 2SC4116-BL (TE85R) B 46.9/37.8
Q18 1560000540 S.FET 2SK880-Y (TE85R) T 46.4/17.3
Q19 1530002850 S.TR 2SC4116-BL (TE85R) B 25.6/17.8
Q21 1510000920 S.TR 2SA1577 T106 Q B 52.8/36.5
Q22 1510000920 S.TR 2SA1577 T106 Q B 34.5/37.9
Q23 1520000450 S.TR 2SB1132 T100 Q B 72.1/25.4
Q24 1590001190 S.TR XP6501-(TX) AB B 72.1/29.2
Q25 1590000720 S.TR DTA144EUA T106 B 68.8/31.6
Q26 1590003320 S.FET TPC6103 (TE85L) T 72.9/25.1
Q27 1590000720 S.TR DTA144EUA T106
Except [USA-02], [EUR-02], [GEN-02] B 19.5/34.5
Q29 1590000430 S.TR DTC144EUA T106 B 54.9/39.7
D1 1790001670 S.DIO RB706F-40T106 B 55.5/12.3
D2 1750000580 S.DIO 1SV307 (TPH3) B 59.8/8.3
D4 1750000720 S.VCP HVC375BTRF T 50.2/5.6
D5 1750000580 S.DIO 1SV307 (TPH3) B 57/3.5
D6 1790001260 S.DIO MA2S077-(TX) T 59.9/7.9
D7 1790001240 S.DIO MA2S728-(TX) T 56.6/7.9
D8 1750000720 S.VCP HVC375BTRF T 54.6/5.6
D9 1750000710 S.VCP HVC350BTRF T 43.2/5.6
D10 1750000710 S.VCP HVC350BTRF T 38.8/5.6
D12 1790001250 S.DIO MA2S111-(TX) B 45.9/40
D14 1790001260 S.DIO MA2S077-(TX) B 51.8/23.7
D15 1790001260 S.DIO MA2S077-(TX) B 51.8/18
D16 1750000770 S.VCP HVC376BTRF B 40.6/20.5
D17 1750000770 S.VCP HVC376BTRF B 42.8/21.8
D18 1720000470 S.VCP 1SV239 (TPH3) T 37.9/21.5
D19 1750000770 S.VCP HVC376BTRF B 40.8/27.4
D20 1750000770 S.VCP HVC376BTRF B 40.8/28.8
D21 1750000720 S.VCP HVC375BTRF B 37.2/22.7
D22 1750000720 S.VCP HVC375BTRF B 37.2/29.4
D23 1790001250 S.DIO MA2S111-(TX) T 42.8/8.1
D24 1790001250 S.DIO MA2S111-(TX) B 32.5/29.2
D25 1790001250 S.DIO MA2S111-(TX) T 53.3/15
FI1 2030000150 S.MLH FL-335 (46.350 MHz) B 31.7/5.8
FI2 2020001840 CER ALFYM450F=K
X1 6070000190 S.DCR CDBCB450KCAY24-R0 T 11.6/8.8
X2 6050011710 S.XTL CR-763 (15.3 MHz) B 28.4/32.9
X3 6050011560 S.XTL CR-746 (4.000 MHz)
Except [USA-02], [EUR-02], [GEN-02] B 22.8/39.7
X4 6050011730 S.XTL CR-765 (3.6864 MHz) B 15.3/21.4
L1 6200008580 S.COL 0.30-1.4-6TL 32N B 67.8/7
L2 6200009800 S.COL 0.26-1.1-7TR 30N B 63.4/5.5
L3 6200008280 S.COL 0.30-1.7-7TL 50N B 62/11.4
L4 6200008490 S.COL 0.30-0.9-3TR 7.5N B 67.4/13.4
L5 6200008280 S.COL 0.30-1.7-7TL 50N B 57.3/5.8
L6 6200010400 S.COL ELJRE 39NJ-F B 56.5/7.9
L7 6200008090 S.COL LQW2BHN68NJ01L B 53.6/4.5
L8 6200008090 S.COL LQW2BHN68NJ01L B 50.9/4.5
L9 6200007750 S.COL LQW2BHN56NJ01L B 47.3/7.7
L11 6200007750 S.COL LQW2BHN56NJ01L B 41.3/5.2
L12 6200009350 S.COL ELJRE R22G-F3 B 43.5/12.8
L13 6200007850 S.COL ELJNC R82K-F B 38.5/11.5
L15 6200002860 S.COL NL 252018T-4R7J B 57.2/9.8
L16 6200009710 S.COL 0.30-0.9-4TL 10.5N B 68.6/18.3
L17 6200008210 S.COL 0.45-1.5-5TL 23.2N B 67.3/21.4
L18 6200005700 S.COL ELJRE 22NG-F
[USA-88], [EUR-88] only T 65.5/26.5
L19 6200005740 S.COL ELJRE 47NG-F B 54.4/29
L20 6200003590 S.COL EXCCL3225U1 B 71.9/21.4
L21 6200009180 S.COL ELJRE R10J-F3 T 47.8/21.4
L22 6200009180 S.COL ELJRE R10J-F3 B 47.7/27.6
L24 6200003640 S.COL MLF1608E 100K-T B 41.4/24.4
L25 6200007760 S.COL LQW2BHN82NJ01L B 38.8/24.9
L26 6200008090 S.COL LQW2BHN68NJ01L B 37.8/31.6
L27 6200007170 S.COL MLF1608A 3R3K-T T 41/21.9
L28 6200007170 S.COL MLF1608A 3R3K-T T 40.4/25.1
L31 6200007000 S.COL ELJRE 82NG-F T 58.8/4.8
L32 6200005720 S.COL ELJRE 33NG-F T 37.1/32.1
L33 6200004480 S.COL MLF1608D R82K-T B 25.8/15.7
L35 6200003540 S.COL MLF1608D R22K-T B 27.5/18
L37 6200003640 S.COL MLF1608E 100K-T B 40.8/30.1
L38 6200008090 S.COL LQW2BHN68NJ01L B 37.7/21
L39 6200007720 S.COL LQW2BHN33NJ01L B 37.9/27.7
L41 6200009180 S.COL ELJRE R10J-F3 T 41.3/30.9
L42 6200007170 S.COL MLF1608A 3R3K-T T 36.6/28.5
L43 6200007170 S.COL MLF1608A 3R3K-T T 36.6/25.1
R1 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
Ω
) B 59.1/11.7
R2 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 55.5/15.2
R3 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 52.6/20.3
R4 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 56.5/17
R5 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 54.5/15.2
R6 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 52.1/15.2
R7 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 50.8/15.7
R8 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 54.5/17
R9 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 55/18.3
R10 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) T 54.2/20.5
R11 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 53.4/5.1
R12 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 49.1/8.7
R13 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 51.4/5.1
R14 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 52.4/7.7
R15 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 47.7/4.4
R16 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) T 45.4/5.1
R17 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 49/9.7
R18 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) B 50.3/9.2
R19 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 49.6/7.4
R20 7030009270 S.RES ERJ2GEJ 821 X (820
Ω
) T 44.4/6.9
R21 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 42/5.1
R22 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 37.5/5.1
R23 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 40/5.1
R24 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 49.5/11.5
R25 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 40.1/7.3
R26 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 46.1/11.6
R27 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 44.7/12.1
R28 7030010430 S.RES ERJ2GEJ 120 X (12
Ω
) B 46.1/10.6
R29 7030009160 S.RES ERJ2GEJ 181 X (180
Ω
) B 41.5/13.1
R31 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 36/12.2
R32 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 37.6/6.7
R33 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) B 25.4/4.4
R34 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 23.1/5.9
R35 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 22.6/7.6
R36 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) T 13.1/13.3
R38 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 20.2/7.6
R39 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 11.9/5.8
R40 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) B 9.9/6.1
R42 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 12.6/12.9
R43 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 16.6/12.3
R44 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) B 10.6/12.9
R45 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) B 12.6/14.7
R46 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 11.6/14.7
R48 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) B 21.8/6.4
R50 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 48.5/13.5
R51 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) B 69.9/7.2
R52 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) B 53.9/9.8
R53 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
) T 55.8/23.8
R54 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 54.2/23.8
R55 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 54.2/22.8
S.=Surface mount
To Next Page
