PANEL DESCRIPTION
RX SPEAKER KEY
Push to turn the RX speaker function ON or OFF.
WhentheRXspeakerfunctionisturnedON,thereceived
audio can be heard via the external speaker.
•Thisfunctionisavailablewhentheexternalspeakerisadditionally
connected.
•Thisfunctionisusefulwhenyouareoutofthevehicle.
•Theaudiooutputlevelislinkedtothetransceiver’svolumecontrol.
LIGHT KEY
Push to turn the transceiver’s backlight ON for about 5 sec.
when the backlight function is turned OFF in user set mode.
LOCK KEY
Push and hold to electronically lock all programmable keys
except the following:
[Moni(Audi)], [Light], [Lock], [Call] (incl. Call A and Call B),
[Emergency],[Surveillance],[LoneWorker]and[OPT1/2/3].
LONE WORKER KEY
PushtoturntheLoneWorkerfunctionONorOFF.
•IftheLoneWorkerfunctionisactivated,theEmergencyfunctionis
automatically turned ON after the specified time period has passed
with no operation is performed.
HIGH/LOW KEY
Push to select the transmit output power temporarily or per-
manently, depending on the pre-setting.
•Askyourdealerfortheoutputpowerlevelforeachselection.
TONE/RAN CH SELECT KEY
➥Whileinanalogmodeoperation,pushtoenterthecon-
tinuous tone channel selection mode. Then select the
desired tone frequency/code setting with [CH Up] or [CH
Down]. After the selection, push this key again to set.
➥Whileindigitalmodeoperation,pushtoentertheRAN
channel selection mode. Then select the desired RAN set-
ting with [CH Up] or [CH Down]. After the selection, push
this key again to set.
➥Whileinmixed(digitalandanalog)modeoperation,push
to enter the continuous tone channel selection mode.
Then select the desired tone frequency/code setting with
[CH Up] or [CH Down]. After the selection, push this key
to set. After that, the RAN channel selection screen ap-
pears. Select the desired RAN setting with [CH Up] or [CH
Down]. After the selection, push this key again to set.
C.TONE CH ENT KEY
Push to select the continuous tone channel using [CH Up]/
[CH Down] to change the tone frequency/code setting after
pushing this key. The selected channel remains set as the
continuous tone channel until another channel is designated
as such. (Analog or mixed mode operation only)
TALK AROUND KEY
Push to turn the talk around function ON and OFF.
•Thetalkaroundfunctionequalizesthetransmitfrequencytothe
receive frequency for transceiver-to-transceiver communication.
