PANEL DESCRIPTION
TX CODE CHANNEL UP/DOWN KEYS
Push to select a TX code channel directly.
SCRAMBLER/ENCRYPTION KEY
➥Whileinanalogmodeoperation,pushtotogglethevoice
scrambler function ON and OFF.
➥While in digital mode operation,push to toggle the
encryption transmission function ON and OFF.
COMPANDER KEY
Push to toggle the compander function ON and OFF.
The compander function reduces noise components from
the transmitted audio to provide clear communication.
ID-MR SELECT KEY (PMR operation only)
➥ Recalls detected ID codes.
•Push thiskey, then selecttheID codeusing [CH Up]/
[CH Down].
•Upto5ID’sarememorized.
➥ Push and hold for 1 sec. to erase the selected ID’s.
HOOK SCAN KEY
Whentheonhookscanfunctionisactivated,pushthiskey
to disables on hook scan function (stop scanning) temporar-
ily. Push this key again to re-start scanning.
USER SET MODE KEY
➥ Push and hold for 1 sec. to enter user set mode.
•Duringusersetmode,pushthiskeytoselectanitemthatis
enabled by your dealer, and change the value or condition using
[CH Up]/[CH Down].
➥
Push and hold this key for 1 sec. again to exit user set mode.
User set mode is also available via the ‘Power ON function.’
Refer to p. 12 also.
10Key ENT KEY
Push to enable the connected microphone's 10-keypad oper-
ation.
•Thedesiredmemorychannel,TXcodechannel(5-tone),ID list
number (digital), TX status (MSK/Digital) or Short Data Message
(digital) can be selected. (Depends on the pre-programming.)
OPT 1/2/3 KEYS
Push to control the output signal level from the optional unit
connector.
POWER OFF EMERGENCY
Whilepushingandholdingthis key,turnthetransceiver’s
power OFF to activate the Power OFF Emergency function.
After the specified time period has passed, from the time this
function is activated, the emergency call is transmitted with
no beep emission and no display indication. (p. 14)
