■ Options
•RMK-3 s e p a r at i o n k i t +
OPC-607/OPC-608/OPC-609
s e pa r at i o n c a b l e
Allows you to install the transceiver main unit separately
from the front panel for operating convenience.
• OPC-1132/OPC-347
d c p o w e r c a b l e
OPC-1132 : 3 m (9.8 ft)
OPC-347 : 7 m (23 ft)
•HM-152/HM-152T/HM-148G/HM-148T
h a n d m i c r o p h o n e s
HM-152 : Hand microphone
HM-152T : DTMF microphone
HM-148G : Self ground heavy duty microphone
HM-148T : Self ground heavy duty DTMF microphone
The 10-keypad of this microphone can be used
for the DTMF code transmission only.
•SM-25
d e s k t o p m i c r o p h o n e
•SP-5/SP-10/SP-22/SP-30 e x t e r n a l s p e a k e r s
Input impedance : 4 ø
Max.inputpower:6W(SP-5)/5W(SP-10)/7W(SP-22)/
30W(SP-30)
SP-5 : Large speaker for good audio quality.
SP-10 : For all-round mobile operation.
SP-22 : Compact and easy-to-install.
SP-30 : High input power level.
• UT-109R/UT-110R s c r a m b l e r u n i t s
Non-rolling type (UT-109R)/Rolling type (UT-110R) voice
scrambler unit provides higher communication security.
•UT-96R
5t o n e u n i t
• UT-126H d i g i tal m o d u l a t o r /d e m o d u l at o r u n i t
Provides 6.25 kHz digital mode operation.
( UT-126H is a upgrade version of UT-119H. UT-119H can
be used depending on the version. Ask your dealer for de-
tails.)
Approved Icom optional equipment is designed for optimal
performance when used with an Icom transceiver.
Icom is not responsible for the destruction or damage to an
Icom transceiver in the event the Icom transceiver is used
with equipment that is not manufactured or approved by
Icom.
Some options may not be available in some countries. Please ask
your dealer for details.
