PANEL DESCRIPTION
SIREN
Push to emit a siren sound.
TX CODE ENTER KEY (PMR operation only)
Push to enter the TX code edit mode directly.
Then set the desired digit using [CH Up]/[CH Down]. (p. 10)
TX CODE CHANNEL SELECT KEY
➥ Push to enter the TX code channel selection mode. Then
set the desired channel using [CH Up]/[CH Down]. (p. 9)
➥ While in the TX code channel selection mode, hold down
this key for 1 second to enter the TX code edit mode. Then
set the desired digit using [CH Up]/[CH Down]. (p. 10)
TX CODE CHANNEL UP/DOWN KEYS
Push to select a TX code channel directly.
ID-MR SELECT KEY (PMR operation only)
➥ Recalls detected ID codes.
• Push this key, then select the ID code using [CH Up]/
[CH Down].
• Up to 5 ID’s are memorized.
➥ Hold down this key for 1 second to erase the selected ID’s.
SCRAMBLER KEY
➥ Push to turn the voice scrambler function ON or OFF.
USER SET MODE KEY
➥ Hold down for 1 second to enter the User Set mode.
• During the User Set mode, push this key to select an item*, and
change the value or condition using [CH Up]/[CH Down].
*Selectable items may differ depending on the presetting.
➥ Hold down this key for 1 second again to exit the User Set
mode.
OPT 1/2/3 OUT KEYS
Push to control the output signal level from the optional unit
connector.
OPT 1/2/3 MOMENTARY KEYS
Control the output signal level from the optional unit
connector while holding down this key.
Ext. CH Sel Mode KEY
Push to turn the Ext. CH Select function ON or OFF.
When the function is turned ON, memory channels can be
selected only with an external input operation.
When the function is turned OFF, memory channels can be
selected with [CH Up] or [CH Down] operation, and cannot be
selected with external input operation.
• This function can be used when the external unit, such as a dimmer
control connected to the transceiver with an optional cable, OPC-
1939. (p. 14)
• Ask your dealer for details of external input operation.
