Icom IC-F6020 Series - Supplied Accessories; Mounting the Transceiver

15
3
15
■ Supplied Accessories
Microphone
Microphone hanger
and screw set
Microphone
hanger cable
DC power cable
Flat washers
Spring washers
Bracket bolts
Mounting screws
(M5×12)
Self-tapping screws
(M5×20)
Nuts
Function name
stickers*
Used for labelling the programmable function
keys according to their assinged functions.
*
Mounting bracket
■ Mounting the transceiver
The universal mounting bracket supplied with your transceiver
allows overhead mounting.
• Mount the transceiver securely with the 4 supplied screws
to a thick surface which can support more than 1.5 kg
(3.3 lb).
Flat w
asher
Felt*
Spr
ing washer
When using
self-tapping scre
ws
Felt*
*Felts reduce the vibration effects.
