6 - 3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
FI1 2020001930 S.CER CFWCA450KFFA-R0 T 57.1/23.5
FI2 2020002120 S.CER CFWCA450KGFA-R0 B 56.7/17.1
FI200 2040001440 S.LC NFE31PT152Z1E9L B 116.8/30.9
FI500 2030000410 S.MLH FL-380 MFT46.3P 46.350MHZ B 69.6/24.7
X1 6050011860 S.XTL CR-778 (15.300 MHz) B 68.4/39.6
X2 6070000190 S.DCR CDBCB450KCAY24-R0 T 55.5/32.5
X300 6050012100 S.XTL CR-800 (3.579545 MHz) B 38.3/10.4
X301 6050012090 S.XTL CR-799 (3.6864 MHz) B 39.2/39.3
X302 6050012110 S.XTL CR-803 (19.6608 MHz) B 22.6/37.6
L1 6200004660 S.COL MLF1608A 1R8K-T B 79.6/41.2
L2 6200005690 S.COL ELJRE 18NG-F B 85.6/33.2
L3 6200005680 S.COL ELJRE 15NG-F B 86.6/31.3
L24 6200003540 S.COL MLF1608D R22K-T B 62.9/38.2
L25 6200004480 S.COL MLF1608D R82K-T B 60.7/37.3
L46 6200004660 S.COL MLF1608A 1R8K-T B 81.2/35
L200 6200005650 S.COL ELJRE 8N2Z-F [L] B 101.4/24.4
6200005660 S.COL ELJRE 10NG-F [H] B 101.4/24.4
L201 6200011130 S.COL C1608CB-12NG [H] B 103/29.2
6200011260 S.COL C1608CB-15NG [L] B 103/29.2
L203 6200011130 S.COL C1608CB-12NG B 104.1/34.8
L204 6200005630 S.COL ELJRE 5N6Z-F [H] T 102.2/33.2
6200005640 S.COL ELJRE 6N8Z-F [L] T 102.2/33.2
L205 6200005630 S.COL ELJRE 5N6Z-F [H] T 104/32.5
6200005640 S.COL ELJRE 6N8Z-F [L] T 104/32.5
L206 6200009460 S.COL 0.25-1.9-7TL 67N T 113.8/28.4
L207 6200005630 S.COL ELJRE 5N6Z-F [H] T 103.5/29.5
6200005640 S.COL ELJRE 6N8Z-F [L] T 103.5/29.5
L208 6200006770 S.COL ELJRE 1N5Z-F T 105.3/26.7
L209 6200008220 S.COL 0.40-1.4-5TR 21N B 117.2/24.4
L210 6200009110 S.COL 0.30-0.9-2TR 4.1N B 117.6/20.3
L212 6200008250 S.COL 0.30-0.9-7TL 21N B 117.6/14.8
L213 6200002850 S.COL NL 252018T-R82J B 112.5/13
L301 6200002860 S.COL NL 252018T-4R7J B 28.9/17.5
L500 6200005530 S.COL ELJFC R47M-F B 64.2/33.7
L501 6200003960 S.COL MLF1608A 1R0K-T B 64.6/24.5
L502 6200003630 S.COL MLF1608D R68K-T B 74.9/24.6
L503 6130003000 S.COL 617DB-1714=P3 B 79.2/18.8
L504 6130003000 S.COL 617DB-1714=P3 B 84.9/13.6
L506 6130003000 S.COL 617DB-1714=P3 B 79.2/8.4
L509 6200011430 S.COL C1608CB-22NG B 94.5/14.4
L510 6200010250 S.COL 0.28-1.0-9TR 34N T 86.7/8
L512 6200011430 S.COL C1608CB-22NG B 97.1/14.4
L513 6200008240 S.COL 0.30-0.9-5TL 14N [L] T 92.4/11.6
6200008530 S.COL 0.30-1.0-4TR 12N [H] T 92.4/11.6
L514 6200008090 S.COL LQW2BHN68NJ01L T 99.6/9.1
L516 6200010250 S.COL 0.28-1.0-9TR 34N T 102.8/7.9
L517 6200010250 S.COL 0.28-1.0-9TR 34N T 105.9/5.8
L518 6200007730 S.COL LQW2BHN39NJ01L T 110.5/6.6
L519 6200007730 S.COL LQW2BHN39NJ01L B 108.9/9.4
L520 6200011430 S.COL C1608CB-22NG B 109.9/6.8
L522 6200008250 S.COL 0.30-0.9-7TL 21N B 116.2/8
L523 6200008700 S.COL 0.30-0.9-6TR 17.5N B 120.2/8.8
L602 6200007120 S.COL ELJND 1R0J T 85.2/30.4
L603 6200007120 S.COL ELJND 1R0J T 88.4/28.1
L604 6200010090 S.COL ELJND R82JF T 84.4/21.4
L605 6200009970 S.COL C2012C-R39G T 87.3/32.6
L606 6200009970 S.COL C2012C-R39G T 87.3/24.5
L607 6200009970 S.COL C2012C-R39G T 86.6/19.1
L608 6200008330 S.COL 0.45-1.4-4TL 15N T 89.8/32.6
L609 6200008330 S.COL 0.45-1.4-4TL 15N T 91.6/24.6
L610 6200008240 S.COL 0.30-0.9-5TL 14N T 88.9/19.7
L611 6200009970 S.COL C2012C-R39G T 97/28.1
L612 6200009970 S.COL C2012C-R39G T 96/33.2
L613 6200009970 S.COL C2012C-R39G T 97.4/20.4
L614 6200011430 S.COL C1608CB-22NG B 94.1/20.4
L615 6200005690 S.COL ELJRE 18NG-F B 90.5/30.2
L616 6200011060 S.COL C1608CB-18NG [L] B 98.3/17.4
6200011260 S.COL C1608CB-15NG [H] B 98.3/17.4
R1 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 72.1/38.9
R2 7030005700 S.RES ERJ2GEJ 274 X (270 k
Ω
) T 74.9/41.4
R3 7030008310 S.RES ERJ2GEJ 564 X (560 k
Ω
) T 73.2/43.2
R4 7410001130 S.ARY EXB28V102JX B 73.1/41.6
R5 7030008310 S.RES ERJ2GEJ 564 X (560 k
Ω
) T 73.2/41.4
R6 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 69.8/36.2
R7 7030005580 S.RES ERJ2GEJ 560 X (56
Ω
) B 83.5/34.9
R8 7510001730 S.TMR ERTJOEP 473J B 64/40.5
R9 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 63.1/42.4
R10 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 81.1/18
R11 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 12.5/32.4
R13 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 76.8/28.7
R16 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) B 77.7/30.3
R17 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) [H] B 80.6/30.7
7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
) [L] B 80.6/30.7
R18 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 88.8/22.4
R19 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 84/23.3
R20 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 88.6/23.6
R21 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 87.4/21.5
R22 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 84.7/20.1
R23 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 90.5/19.1
R24 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 95.8/37
R25 7030008370 S.RES ERJ2GEJ 561 X (560
Ω
) T 79.2/20.1
R59 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
) B 64/38.9
R60 7030007060 S.RES ERJ2GEJ 684X (680 k
Ω
) B 65.4/38
R63 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
) B 58.4/23.8
R64 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
) T 65.4/27.5
R66 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 60/23.4
R67 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 62.4/23.9
R68 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 52.9/24.4
R69 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 53.2/22.9
R70 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) B 55.3/22
R71 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
) B 57.1/24.4
R72 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 51/30.7
R73 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) B 54.1/29.9
R74 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 55.4/26
R75 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 52.8/27.4
R77 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) B 53.4/25.9
R78 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 51.9/27.4
R79 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 54.1/33.9
R80 7030010040 S.RES ERJ2GE-JPW B 57.3/35.6
R81 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 59/35.6
R82 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) T 36.4/11.8
R83 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) T 50/30.7
R200 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 103.9/22.4
R201 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 103.9/21.5
R202 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) [L] B 102.6/26.2
7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) [H] B 102.6/26.2
R203 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 103.7/28.1
R204 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) B 103.5/30.9
R205 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 104.2/32.1
R206 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) [H] T 102.1/36
7030009160 S.RES ERJ2GEJ 181 X (180
Ω
) [L] T 102.1/36
R207 7030009530 S.RES ERJ2GEJ 270 X (27
Ω
) [L] T 103.4/35.5
7030010090 S.RES ERJ2GEJ 180 X (18
Ω
) [H] T 103.4/35.5
R208 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) [H] T 102.1/35.1
7030009160 S.RES ERJ2GEJ 181 X (180
Ω
) [L] T 102.1/35.1
R209 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) T 102.9/31.4
R210 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 101.5/29
R211 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) T 101.3/30.2
R212 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) T 104.7/23.7
R213 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 104.4/25
R214 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 102.9/23.7
R215 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 101.1/27.8
R216 7030009280 S.RES ERJ2GE T 104.7/21.3
R217 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 102.5/21.4
R218 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 105/19.7
R219 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 100.8/16.2
R220 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 88.5/12.6
R221 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 105/17.1
R222 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
Ω
) B 115.4/15.3
R223 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 109.1/11.8
R224 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 105.5/15.7
R225 7030003350 S.RES ERJ3GEYJ 181 V (180
Ω
) B 109.5/14.1
R226 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 111.8/12
R227 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
Ω
) B 116.7/11.4
R228 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) B 99.3/27
R300 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) B 39/21
R301 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 38.1/21
R302 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 33.3/30.5
R303 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 33.8/10.4
R304 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) [H] T 63.6/27
7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) [L] T 63.6/27
R305 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 63.7/35.9
R306 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 64.8/37.1
R307 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 33.8/8.6
R308 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) B 39.9/21.7
R309 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 34.6/29.8
R310 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) B 39.8/22.9
R311 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 78.8/40.8
R312 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) B 41.4/23.8
R313 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 42.3/23.8
R314 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 77/41.3
R315 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 77/43.1
R316 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 40.8/21.7
R317 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 36.1/20
R318 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 38.2/16
R319 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 41.4/35.6
R320 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 77/32.2
R321 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 44/35
R322 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 77.6/31
R323 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 39.8/23.8
R324 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 44.9/32.2
R325 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 45.4/30.9
R326 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 45.8/35.2
R327 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) B 30.9/23.9
R328 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 30.3/26.7
R329 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 78.8/31.2
R330 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 45.8/33.4
R331 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 38.9/35.3
R332 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 78.3/30
R333 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 73/32.2
R334 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 64/30.5
R335 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 74.8/32.6
[L]=Low band, [H]=High band
