6 - 4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
R336 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 57.2/17.4
R337 7030010040 S.RES ERJ2GE-JPW T 35/23.5
R338 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 60.7/15.9
R339 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 58.8/17.4
R340 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 4.6/31
R342 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) T 76.1/19.3
R344 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) T 23.8/11.8
R345 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) T 23.8/13.2
R346 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) T 20/12.4
R347 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 15.6/14.2
R348 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 17.1/12.1
R349 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 15.8/12.5
R350 7410001140 S.ARY EXB28V104JX T 4.4/9.9
R351 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) T 67.7/17.9
R352 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 67.6/19.1
R353 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) T 65.3/20.1
R354 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) T 63.3/18.1
R355 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 64.8/16.6
R356 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 37.6/35.3
R357 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 20/11.5
R358 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 22.4/12.3
R359 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 22.4/11.4
R360 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 51.8/9.1
R361 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 53.4/9.1
R362 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 52.2/16
R363 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 53/13.9
R364 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 53.2/12.1
R365 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 58.2/7.9
R366 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 51.9/10.8
R367 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 60.7/13.5
R368 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 50.4/12.1
R371 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 61.6/14.7
R372 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 51.3/14.5
R373 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 24.9/18.2
R374 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) B 25/17.4
R375 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) B 23.7/17.4
R376 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 23.7/18.3
R377 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 26.8/17.3
R378 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 49.4/21.7
R379 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 23.1/29.8
R380 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 23.1/28.9
R381 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 26.3/35.5
R382 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 47.6/18.1
R383 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 11/37.8
R384 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 26/29.9
R385 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 27/37.9
R386 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 27/25.8
R387 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 26/28.1
R388 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 24.8/27.4
R389 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 49.4/24.4
R391 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 21.7/32.7
R393 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) B 40.9/20.4
R394 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 40.9/19.5
R396 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 39.9/33.5
R397 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) B 30.9/25.5
R399 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 20.4/31.4
R400 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 50.4/35.8
R401 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) T 73/30.6
R402 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 24.8/23
R403 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 23.7/20.1
R404 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 23.7/21
R405 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 10.3/33.2
R406 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 23.7/19.2
R407 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 24.8/26.5
R408 7410001130 S.ARY EXB28V102JX B 7.8/30.1
R409 7410001130 S.ARY EXB28V102JX B 20.6/16.9
R410 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 5.5/31
R411 7410001130 S.ARY EXB28V102JX B 18.6/15.3
R412 7410001130 S.ARY EXB28V102JX B 5.8/28.1
R413 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 6.6/14.4
R414 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 12.3/27
R415 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 12.7/28.2
R416 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 19.3/12.2
R417 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 19.3/13.4
R418 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 3.2/16.9
R419 7410001140 S.ARY EXB28V104JX T 9.8/16.8
R420 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 106.1/43.1
R421 7410001130 S.ARY EXB28V102JX B 5.1/22.5
R422 7410001130 S.ARY EXB28V102JX B 7.8/18
R423 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 7.3/9.2
R424 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 107.9/42.3
R425 7410001130 S.ARY EXB28V102JX B 6.2/20
R426 7410001130 S.ARY EXB28V102JX B 9.9/16.4
R427 7410001130 S.ARY EXB28V102JX B 12.3/14.5
R428 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 95.5/34.1
R429 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 95.8/35.4
R430 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 82.8/40.2
R431 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 83.6/38.9
R432 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 79/14.1
R433 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 77.4/14.1
R434 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 108.8/42.3
R435 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 117/38.6
R436 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 122.2/40.8
R437 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 5.1/7.2
R438 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 3.1/8.1
R439 7030005700 S.RES ERJ2GEJ 274 X (270 k
Ω
) B 120.2/29.2
R440 7030010080 S.RES ERJ2RHD 104 X (100 k
Ω
) B 120.2/28.3
R441 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 5.4/36.8
R442 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 7.9/38.1
R443 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 10.8/40.8
R444 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 3.5/26.9
R445 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 3.5/28.7
R446 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 9.3/33.2
R447 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 29.3/23.1
R448 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 24/13.2
R449 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 22.9/13.2
R450 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 22/13.5
R451 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 27.5/22.2
R452 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 26.6/22.2
R453 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 25.6/22.2
R454 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 23.4/22.7
R455 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 24.6/22.2
R456 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 28.2/36.4
R457 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
Ω
) [L] B 28.2/37.3
7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) [H] B 28.2/37.3
R460 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 76.2/30.3
R461 7030010040 S.RES ERJ2GE-JPW B 25.1/6.5
R462 7030010040 S.RES ERJ2GE-JPW B 32.5/34.7
R464 7030010040 S.RES ERJ2GE-JPW T 56/17.8
R465 7030010040 S.RES ERJ2GE-JPW B 69.2/16
R466 7030010040 S.RES ERJ2GE-JPW B 20.6/12.1
R467 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 72.1/32.5
R500 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 62.3/26.7
R501 7030010040 S.RES ERJ2GE-JPW T 19.2/13.9
R502 7030009270 S.RES ERJ2GEJ 821 X (820
Ω
) B 65.1/30.1
R503 7030010040 S.RES ERJ2GE-JPW T 4.8/11.8
R504 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 65.1/28
R505 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 64.2/27.1
R506 7030010040 S.RES ERJ2GE-JPW T 34.3/35.1
R507 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 65.7/31.9
R508 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 83.1/10.5
R509 7030009270 S.RES ERJ2GEJ 821 X (820
Ω
) B 76.4/23.9
R510 7030010130 S.RES ERJ2GE 6R8 X (6.8
Ω
) B 75.8/22.5
R511 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 83.1/9.6
R512 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 75.9/16.9
R513 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) B 76.2/10.1
R514 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 90.8/14
R515 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 92.3/14.4
R516 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 93.5/15.9
R517 7030009270 S.RES ERJ2GEJ 821 X (820
Ω
) B 74.5/22
R518 7030000010 S.RES MCR10EZHJ JPW (000) B 85/5.8
R519 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 46.8/17.1
R520 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 102.2/15.5
R521 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 103.4/15
R525 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 87.1/6.4
R527 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 84.9/5.2
R529 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 89.3/5
R530 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 90.8/8.1
R532 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 96.1/12.4
R533 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 92.5/8.5
R534 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 96.6/9.9
R535 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) T 97.8/9.1
R536 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 96.2/9.8
R537 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 95/11.1
R539 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
) B 89.4/9.6
R540 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 102/5.1
R541 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 102.7/5.7
R542 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 90.7/6.7
R543 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 105.4/3
R545 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 89/8.4
R546 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) B 122.7/10.7
R548 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 23/27.9
R549 7030010040 S.RES ERJ2GE-JPW T 90.8/10.9
R600 7030010040 S.RES ERJ2GE-JPW T 85.2/28.2
R601 7030010040 S.RES ERJ2GE-JPW T 85.2/27.3
R602 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 84.4/23.9
R604 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 94.2/30.5
R605 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 95.1/23.4
R606 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
Ω
) T 93.9/18.6
R607 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) T 93.3/30.5
R608 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) T 94.9/24.6
R609 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 95.1/18.2
R610 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 97.2/30.5
R611 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 97.9/33.7
R612 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 97.6/23.1
R613 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 95.6/19.8
R614 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 94.2/22.5
R615 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 96/24.5
R616 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 94.4/18.7
R617 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 94.4/30.4
R618 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 95.4/30.1
R619 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 93.8/26.7
R620 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 93.2/28
R621 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) B 92.3/28
R622 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) [L] B 97.6/19.5
7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) [H] B 97.6/19.5
R623 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 96/18.7
R624 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 102.4/18.7
[L]=Low band, [H]=High band
To Next Page
Loading...
Need help?
General
