6 - 5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
R625 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 85.8/24.9
R628 7030010040 S.RES ERJ2GE-JPW T 88.6/22.4
R629 7030005570 S.RES ERJ2GEJ 820 X (82
Ω
) B 102.4/20.3
C1 4030017330 S.CER ECJ0EF1C104Z B 71.3/41.6
C2 4030017420 S.CER ECJ0EC1H470J B 72.9/43.6
C3 4030017420 S.CER ECJ0EC1H470J B 73.8/43.6
C4 4030017330 S.CER ECJ0EF1C104Z B 80.2/42.4
C5 4030017420 S.CER ECJ0EC1H470J B 75.1/41.6
C6 4030017460 S.CER ECJ0EB1E102K B 81.7/38.9
C7 4030017420 S.CER ECJ0EC1H470J T 73.2/42.3
C8 4030017490 S.CER C1608 JB 1A 105K-T B 77.8/42.4
C9 4030017460 S.CER ECJ0EB1E102K T 71.8/34.6
C10 4030017460 S.CER ECJ0EB1E102K B 77.4/41
C11 4030016930 S.CER ECJ0EB1A104K B 65.7/42.4
C13 4030017420 S.CER ECJ0EC1H470J B 75.1/32.3
C14 4030017460 S.CER ECJ0EB1E102K B 69.8/34.4
C16 4030017460 S.CER ECJ0EB1E102K T 76.7/2.2
C17 4030016790 S.CER ECJ0EB1C103K B 77.4/31.5
C18 4030017460 S.CER ECJ0EB1E102K B 83.5/33.3
C19 4030016930 S.CER ECJ0EB1A104K B 64/42.1
C20 4030017380 S.CER ECJ0EC1H050B B 84/36.2
C21 4030017460 S.CER ECJ0EB1E102K T 78.9/21.3
C22 4030017580 S.CER ECJ0EC1H060C B 85.6/35.3
C23 4030017460 S.CER ECJ0EB1E102K T 81.1/18.9
C24 4550006430 S.TAN ECST1VY474R B 73.9/28.5
C25 4030017620 S.CER ECJ0EC1H100C B 84.7/31
C27 4030017340 S.CER ECJ0EC1H010B B 84.5/34.5
C28 4030017530 S.CER ECJ0EC1H0R5B B 86.4/30.2
C29 4030016790 S.CER ECJ0EB1C103K [H] B 81.9/31.2
4030016970 S.CER ECJ0EB1C223K [L] B 81.9/31.2
C30 4030017460 S.CER ECJ0EB1E102K B 86.7/23.6
C31 4030016790 S.CER ECJ0EB1C103K [H] B 82.8/31.2
4030016970 S.CER ECJ0EB1C223K [L] B 82.8/31.2
C32 4030017420 S.CER ECJ0EC1H470J B 88.3/20.3
C33 4030017770 S.CER ECJ0EB1E332K B 82.7/22.9
C34 4030016930 S.CER ECJ0EB1A104K B 88.8/21.5
C35 4030017490 S.CER C1608 JB 1A 105K-T B 85.6/21.5
C36 4030017720 S.CER ECJ0EB1H331K B 89.2/20.3
C37 4030017580 S.CER ECJ0EC1H060C B 88.3/30.2
C40 4030016790 S.CER ECJ0EB1C103K B 93.3/39.5
C44 4550006760 S.TAN TEESVB21A336M8R B 87.9/34.9
C50 4030017330 S.CER ECJ0EF1C104Z B 82/32.9
C51 4030017490 S.CER C1608 JB 1A 105K-T B 80.9/33.1
C52 4030017330 S.CER ECJ0EF1C104Z B 78.7/32
C53 4030017490 S.CER C1608 JB 1A 105K-T T 79.6/35.5
C54 4030017460 S.CER ECJ0EB1E102K B 79.6/32
C55 4030017460 S.CER ECJ0EB1E102K B 77.4/32.4
C104 4030017620 S.CER ECJ0EC1H100C B 67.4/36.2
C109 4030016790 S.CER ECJ0EB1C103K B 65.2/40.3
C112 4030017500 S.CER ECJ0EC1H560J B 63/36
C117 4030017570 S.CER ECJ0EC1H040B B 62.1/36
C118 4030016930 S.CER ECJ0EB1A104K B 65.2/39.4
C120 4030016790 S.CER ECJ0EB1C103K B 61.4/39
C125 4030017590 S.CER ECJ0EC1H070C B 61.8/37.7
C127 4030016930 S.CER ECJ0EB1A104K B 61.5/24.5
C128 4030016930 S.CER ECJ0EB1A104K B 60/22.5
C129 4030017360 S.CER ECJ0EC1H030B B 61.2/35.2
C130 4030016930 S.CER ECJ0EB1A104K B 54.1/24.7
C131 4030016930 S.CER ECJ0EB1A104K B 54.1/22.9
C132 4030016930 S.CER ECJ0EB1A104K B 62.3/22.3
C133 4030016930 S.CER ECJ0EB1A104K B 58.4/25.4
C134 4030016930 S.CER ECJ0EB1A104K B 61.4/22.3
C135 4030016930 S.CER ECJ0EB1A104K B 56.6/25.6
C136 4030016930 S.CER ECJ0EB1A104K B 54.1/27.7
C137 4030017690 S.CER ECJ0EC1H121J B 55.4/25.1
C138 4030017690 S.CER ECJ0EC1H121J B 54.1/26.8
C139 4030017430 S.CER ECJ0EC1H101J B 51.5/26.1
C140 4030017460 S.CER ECJ0EB1E102K B 57.5/25.6
C141 4030017460 S.CER ECJ0EB1E102K B 53.1/34.8
C142 4030017420 S.CER ECJ0EC1H470J B 52.7/35.7
C143 4550006050 S.TAN TEESVA 0J 106M8L B 52.1/30.9
C144 4030017460 S.CER ECJ0EB1E102K B 59/34.7
C145 4030017650 S.CER ECJ0EC1H270J B 61.1/33.5
C146 4030017680 S.CER ECJ0EC1H820J B 55.6/34.8
C147 4030017460 S.CER ECJ0EB1E102K B 58.4/36.5
C152 4030016930 S.CER ECJ0EB1A104K B 52.2/22.3
C162 4030016790 S.CER ECJ0EB1C103K B 67.1/31.7
C200 4030017460 S.CER ECJ0EB1E102K B 104/23.7
C201 4030017380 S.CER ECJ0EC1H050B [L] B 101.4/22.3
4030017600 S.CER ECJ0EC1H080C [H] B 101.4/22.3
C202 4030016790 S.CER ECJ0EB1C103K B 102.8/23.3
C203 4030017570 S.CER ECJ0EC1H040B B 100.5/22.3
C204 4030017360 S.CER ECJ0EC1H030B [H] B 100/25.3
4030017570 S.CER ECJ0EC1H040B [L] B 100/25.3
C205 4030017570 S.CER ECJ0EC1H040B [L] B 100.4/28.9
4030017580 S.CER ECJ0EC1H060C [H] B 100.4/28.9
C206 4030017460 S.CER ECJ0EB1E102K B 104.3/26.2
C207 4030017460 S.CER ECJ0EB1E102K B 102.6/27.1
C208 4030017460 S.CER ECJ0EB1E102K B 101.3/29.8
C209 4030016930 S.CER ECJ0EB1A104K B 104.3/27.1
C210 4030017440 S.CER ECJ0EC1H221J B 102.8/24.2
C211 4030017380 S.CER ECJ0EC1H050B T 104.3/35.5
C213 4030017460 S.CER ECJ0EB1E102K B 104.2/33
C214 4030017460 S.CER ECJ0EB1E102K T 103.4/33.9
C215 4030017350 S.CER ECJ0EC1H020B [H] B 102.1/28.1
4030017570 S.CER ECJ0EC1H040B [L] B 102.1/28.1
C216 4030017350 S.CER ECJ0EC1H020B [H] B 102.8/35.6
4030017550 S.CER ECJ0EC1H1R5B [L] B 102.8/35.6
C219 4030017600 S.CER ECJ0EC1H080C [H] T 101.1/34
4030017630 S.CER ECJ0EC1H120J [L] T 101.1/34
C220 4030017600 S.CER ECJ0EC1H080C [L] T 101.1/32.4
4030017610 S.CER ECJ0EC1H090C [H] T 101.1/32.4
C221 4030017460 S.CER ECJ0EB1E102K T 101.3/31.1
C222 4030017400 S.CER ECJ0EC1H220J [L] T 104.9/28.9
4030017670 S.CER ECJ0EC1H390J [H] T 104.9/28.9
C223 4030017460 S.CER ECJ0EB1E102K T 116.9/27
C224 4030017620 S.CER ECJ0EC1H100C [L] T 103.9/27.8
4030017630 S.CER ECJ0EC1H120J [H] T 103.9/27.8
C225 4030016930 S.CER ECJ0EB1A104K T 100.6/29
C226 4030017400 S.CER ECJ0EC1H220J [L] T 103.9/26.8
4030017620 S.CER ECJ0EC1H100C [H] T 103.9/26.8
C227 4030016790 S.CER ECJ0EB1C103K T 115.9/27
C229 4550006650 S.TAN ECST1CY685R T 101.3/24
C230 4030017650 S.CER ECJ0EC1H270J [L] T 103.9/25.9
4030017670 S.CER ECJ0EC1H390J [H] T 103.9/25.9
C231 4030017460 S.CER ECJ0EB1E102K T 104.3/22.5
C232 4030017460 S.CER ECJ0EB1E102K T 103.4/21.3
C233 4030018860 S.CER ECJ0EB0J105K T 101.2/20.6
C234 4030017460 S.CER ECJ0EB1E102K B 115.7/26.7
C235 4030017460 S.CER ECJ0EB1E102K T 103.8/23.7
C236 4030016790 S.CER ECJ0EB1C103K B 115.7/27.6
C237 4030007030 S.CER C1608 CH 1H 150J-T T 114.5/20.7
C238 4030011810 S.CER C1608 JB 1A 224K-T T 103.9/18.8
C239 4030007040 S.CER C1608 CH 1H 180J-T T 115.7/20.7
C240 4030007000 S.CER C1608 CH 1H 090D-T [L] B 116.3/17.5
4030009350 S.CER C1608 CH 1H 3R5B-T [H] B 116.3/17.5
C241 4030017780 S.CER ECJ0EB1E472K T 100.8/15.3
C242 4030006860 S.CER C1608 JB 1H 102K-T B 118.2/17.9
C243 4030017460 S.CER ECJ0EB1E102K T 109.1/13.5
C244 4030017420 S.CER ECJ0EC1H470J T 102.7/15.8
C245 4030009910 S.CER C1608 CH 1H 040B-T B 119.9/15.4
C246 4030017460 S.CER ECJ0EB1E102K B 109.5/12.5
C247 4030017460 S.CER ECJ0EB1E102K B 108.6/12.5
C248 4030009910 S.CER C1608 CH 1H 040B-T B 119.9/13.7
C249 4030017460 S.CER ECJ0EB1E102K T 110/11.8
C250 4030017420 S.CER ECJ0EC1H470J B 110.4/12.5
C251 4030006860 S.CER C1608 JB 1H 102K-T B 115.5/12.6
C253 4030017460 S.CER ECJ0EB1E102K T 111.8/11.1
C254 4030006990 S.CER C1608 CH 1H 080D-T [L] B 116.3/18.7
4030007000 S.CER C1608 CH 1H 090D-T [H] B 116.3/18.7
C255 4030016790 S.CER ECJ0EB1C103K B 98.4/27
C256 4030017730 S.CER ECJ0EB1E471K B 104.3/17.3
C300 4030017420 S.CER ECJ0EC1H470J B 35.7/23.2
C301 4030017420 S.CER ECJ0EC1H470J B 36/35.9
C302 4030017640 S.CER ECJ0EC1H150J B 34.7/10.4
C303 4030017420 S.CER ECJ0EC1H470J B 36.6/23.2
C304 4030017420 S.CER ECJ0EC1H470J B 34.7/34.7
C305 4030017460 S.CER ECJ0EB1E102K T 79.3/39.6
C306 4030017420 S.CER ECJ0EC1H470J B 37.5/23.2
C307 4030016970 S.CER ECJ0EB1C223K B 34.6/28.9
C308 4030016930 S.CER ECJ0EB1A104K B 34.6/31.3
C309 4030017390 S.CER ECJ0EC1H180J B 34.7/8.6
C310 4030017420 S.CER ECJ0EC1H470J B 38.4/23.2
C311 4030016930 S.CER ECJ0EB1A104K B 33.6/16.5
C312 4030017460 S.CER ECJ0EB1E102K B 45.1/24.2
C313 4550000460 S.TAN TEESVA 1C 105M8L B 44.5/21.1
C314 4030017420 S.CER ECJ0EC1H470J B 42.1/25
C315 4030018860 S.CER ECJ0EB0J105K T 63.3/28.6
C316 4030018860 S.CER ECJ0EB0J105K T 65.2/35.9
C317 4030018860 S.CER ECJ0EB0J105K [L] only T 66.2/35.9
C318 4550000460 S.TAN TEESVA 1C 105M8L B 45/27.3
C319 4030017730 S.CER ECJ0EB1E471K T 77/42.2
C320 4030016930 S.CER ECJ0EB1A104K B 24.1/6.5
C321 4550006250 S.TAN TEESVA 1A 106M8L T 80.4/42.4
C322 4030017910 S.CER ECJ0EB1H152K B 42.2/22.4
C323 4030017680 S.CER ECJ0EC1H820J B 44.5/30.9
C324 4030018860 S.CER ECJ0EB0J105K [H] only T 67.6/35.9
C325 4030017400 S.CER ECJ0EC1H220J B 37.6/36.2
C326 4030016930 S.CER ECJ0EB1A104K T 77.9/32.2
C327 4030016930 S.CER ECJ0EB1A104K B 42.2/21.5
C328 4030017400 S.CER ECJ0EC1H220J B 40.1/36.2
C329 4550006350 S.TAN TEESVB2 1A 226M8L B 30.6/38.8
C330 4030016790 S.CER ECJ0EB1C103K T 76.1/32.2
C331 4030017460 S.CER ECJ0EB1E102K T 39/33.5
C332 4030016930 S.CER ECJ0EB1A104K B 32.6/32.9
C333 4030016930 S.CER ECJ0EB1A104K B 44/35.9
C334 4030017460 S.CER ECJ0EB1E102K B 33.8/34.7
C335 4030017720 S.CER ECJ0EB1H331K B 32.4/28
C336 4030016930 S.CER ECJ0EB1A104K T 69.5/19.1
C337 4030016940 S.CER ECJ0EB1A393K T 78.8/32.8
C338 4030017760 S.CER ECJ0EB1H222K B 30/25.5
C339 4030016930 S.CER ECJ0EB1A104K B 46.3/30.9
C340 4030017750 S.CER ECJ0EB1E122K B 46.8/32.2
C341 4030017460 S.CER ECJ0EB1E102K T 77.1/29.5
C342 4030016930 S.CER ECJ0EB1A104K T 45.7/18.6
C343 4030017460 S.CER ECJ0EB1E102K T 57.2/18.3
C344 4030017260 S.CER C2012 JB 0J 475KT T 66.5/30.5
C345 4030016930 S.CER ECJ0EB1A104K T 74.8/31.7
[L]=Low band, [H]=High band
