BATTERY CHARGING (FOR ON-BOARD USE ONLY)
18
D Charging connections
q Attach the BC-173 to a flat surface, such as a desk.
w Connect the AC adapter as shown below.
e Insert the battery pack with/without the transceiver into
the charger.
• The charge indicator lights green.
r Charge the battery pack approx. 8 hours, depending on
the remaining power condition.
DO NOT charge the BP-252 more than 12 hours. Oth-
erwise, the BP-252 will be damaged.
AC adapter*
IC-GM1600
BP-252
BC-173
Supplied
screws
Charge indicator
Lights green when the
BP-252 (with/without
IC-GM1600) is inserted.
Tu rn power OFF
*Plug type is dependent
on version.
MIC
/SP
