■ MB-86 contents
Qty.
Belt clip........................................ 1
Base clip....................................... 1
Supplied screws ................................. 2
■ Attachment
q Screw the base clip to the back of the transceiver using
the two screws (supplied) as shown below.
w Clip the belt clip over your belt and insert the transceiver.
e Once the transceiver is locked in place, it swivels as illus-
trated below.
■ Detachment
➥ Turn the transceiver upside down in the direction of the
arrow and pull out from the belt clip.
Supplied screws
R CAUTION!
HOLD THE TRANSCEIVER TIGHTLY, WHEN HANGING OR
DETACHING THE TRANSCEIVER FROM THE BELT CLIP�
Otherwise the transceiver may not be attached to the belt
clip or swivelled properly attached to the belt clip and may
not swivel properly. The transceiver could then be acciden-
tally dropped and scratched or damaged .
19
8
OPTIONAL SWIVEL BELT CLIP
