NOTE: The above screen is an example.
Each transceiver has its own specific values for each setting.
q: Adjustment condition
w: Reference frequency
e: RF output power
r: FM deviation (Wide)
t: Receive sensitivity (Automaticaly)
y: Receive sensitivity (Manualy)
u: Squelch level
i: S-meter
o: VOX
q
w
e
i
o
r
t
u
y
I/O check button
• PC SCREEN EXAMPLE
5 - 3
