Icom IC-M402

[MAIN UNIT][LOGIC BOARD]
S.=Surface mount
EP1 0910053453 PCB B 5584C
EP2 8930054970 LCD CONTACT SRCN-2438-SP-N-W
R1 7210002350 VARIABLE TP96N97N15F-10KA-1301
W1 8900010510 CABLE OPC-1044
EP1 0910053462 PCB B 5585B
R1 7210002360 VARIABLE TP96N97-15F-10KB-1301
EP1 0910053472 PCB B 5586B
IC1 1110003200 S.IC TA31136FN (EL)
IC2 1130007610 S.IC µPD3140GS-E1 (DS8)
IC3 1150001540 IC M57710-A/SC-1302
IC4 1130008090 S.IC BU4066BCFV-E1
IC5 1130008090 S.IC BU4066BCFV-E1
IC6 1110003650 S.IC NJM2211M-TE1
IC7 1110002680 S.IC NJM2902M-T1
IC8 1180001070 S.IC TA7805F (TE16L)
IC9 1110003090 IC LA4425A
Q1 1580000660 S.FET 3SK272-(TX)
Q2 1530002360 S.TRANSISTOR 2SC2714-Y (TE85R)
Q3 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q4 1590000430 S.TRANSISTOR DTC144EUA T106
Q5 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q6 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q7 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q8 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q9 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q10 1530002240 S.TRANSISTOR 2SC3775-3-TB
Q11 1530003710 S.TRANSISTOR 2SC3268 (TE12L)
Q12 1520000380 TRANSISTOR 2SB1143 S
Q14 1590000430 S.TRANSISTOR DTC144EUA T106
Q15 1590000670 S.TRANSISTOR FMW1 T148
Q16 1590000430 S.TRANSISTOR DTC144EUA T106
Q17 1540000550 S.TRANSISTOR 2SD1664 T100Q
Q18 1590000430 S.TRANSISTOR DTC144EUA T106
Q19 1590000720 S.TRANSISTOR DTA144EUA T106
Q20 1560000810 S.FET 2SK1069-4-TL
Q21 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q22 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q23 1590000430 S.TRANSISTOR DTC144EUA T106
Q24 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q25 1590000430 S.TRANSISTOR DTC144EUA T106
Q26 1590000430 S.TRANSISTOR DTC144EUA T106
Q27 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q28 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
D1 1790000620 S.DIODE MA77 (TX)
D2 1790000620 S.DIODE MA77 (TX)
D3 1720000370 S.VARICAP HVU350TRF
D4 1720000370 S.VARICAP HVU350TRF
D5 1790000620 S.DIODE MA77 (TX)
D6 1790000620 S.DIODE MA77 (TX)
D7 1750000550 S.DIODE 1SS355 TE-17
D8 1790000690 S.DIODE HSM88ASR-TR
D9 1790000690 S.DIODE HSM88ASR-TR
D10 1710001080 DIODE XB15A308
D11 1790000700 DIODE DSA3A1
D12 1750000550 S.DIODE 1SS355 TE-17
D14 1750000130 S.DIODE DA204U T107
D15 1710001080 DIODE XB15A308
D16 1790001210 S.DIODE 1SS375-TL
D19 1790000620 S.DIODE MA77 (TX)
D20 1790000620 S.DIODE MA77 (TX)
D21 1790000660 S.DIODE MA728 (TX)
FI1 2010002420 MONOLITH 21R15AB (FL-310)
FI2 2010002420 MONOLITH 21R15AB (FL-310)
FI3 2020001680 CERAMIC ALFY450E
X1 6070000210 S.DISCRIMINATOR CDBCA450CX24
X2 6050010800 S.XTAL CR-659 (21.25 MHz)
L1 6200003050 S.COIL NL 322522T-R82J-3
L2 6200002410 S.COIL NL 252018T-056J
L3 6200002430 S.COIL NL 252018T-082J
L4 6200003090 S.COIL NL 322522T-2R7J-3
L5 6200008190 S.COIL 0.25-1.9-8TL 80N
L6 6200009180 S.COIL ELJRE R10J-F3
L7 6200009180 S.COIL ELJRE R10J-F3
L8 6200009180 S.COIL ELJRE R10J-F3
L9 6200002430 S.COIL NL 252018T-082J
L10 6200002430 S.COIL NL 252018T-082J
L11 6170000230 COIL LW-25
L12 6110001600 COIL LA-243
L13 6110001600 COIL LA-243
L14 6110001670 COIL LA-253
L15 6110001600 COIL LA-243
L16 6200007760 S.COIL LQN21A 82NJ04
L17 6200007760 S.COIL LQN21A 82NJ04
L19 6200007760 S.COIL LQN21A 82NJ04
L20 6200007760 S.COIL LQN21A 82NJ04
L21 6200007760 S.COIL LQN21A 82NJ04
L22 6200007760 S.COIL LQN21A 82NJ04
L24 6200007760 S.COIL LQN21A 82NJ04
L25 6200007760 S.COIL LQN21A 82NJ04
L26 6200004720 S.COIL MLF1608D R10K-T
L27 6200003550 S.COIL MLF1608A 4R7K-T
L28 6200009150 S.COIL ELJRE 82NJ-F3
L29 6200009170 S.COIL ELJRE 47NJ-F2
L30 6200002600 S.COIL NL 252018T-047J
L31 6200002600 S.COIL NL 252018T-047J
R3 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R5 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R6 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R7 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R8 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R9 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R10 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R11 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R12 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R13 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R14 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R15 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R16 7310002760 S.TRIMMER RV-152 (RH03A3AJ4X0HA) 223
R17 7510001050 S.THERMISTOR NTCCM1608 4LH 333KC-T
R18 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R19 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R20 7030003740 S.RESISTOR ERJ3GEYJ 334 V (330 kΩ)
R21 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R22 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R25 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R26 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R27 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
6 - 2
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[VR-B BOARD]
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[VR-A BOARD]
REF ORDER
DESCRIPTION
NO. NO.
