Icom IC-M402

[LOGIC BOARD]
IC1 1140009410 S.IC HD6433847RA29H (FX-2438A)
IC2 1130009680 S.IC HN58X2432TI
IC3 1130007570 S.IC BU4094BCFV-E2
IC4 1130005290 S.IC TC74HC14AF
IC5 1130006080 S.IC TC74HC02AF (TP1)
IC6 1130009110 S.IC S-80942ANMP-DD6-T2
IC7 1170000350 S.IC PC357N6T
Q1 1590000720 S.TRANSISTOR DTA144EUA T106
Q2 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q3 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q4 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q5 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q6 1590000680 S.TRANSISTOR DTC114EUA T106
Q7 1510000510 S.TRANSISTOR 2SA1576A T106R
Q8 1560000810 S.FET 2SK1069-4-TL
Q9 1590001330 S.TRANSISTOR DTA114EUA T106
Q10 1560000810 S.FET 2SK1069-4-TL
Q11 1560000810 S.FET 2SK1069-4-TL
D1 1750000550 S.DIODE 1SS355 TE-17
D2 1750000550 S.DIODE 1SS355 TE-17
X1 6050011090 S.XTAL CR-691 (9.8304 MHz)
R1 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R2 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R3 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R4 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R5 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R6 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R7 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R8 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R9 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R10 7030003250 S.RESISTOR ERJ3GEYJ 270 V (27 Ω)
R11 7030003250 S.RESISTOR ERJ3GEYJ 270 V (27 Ω)
R12 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R13 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R14 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R15 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R16 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R17 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R18 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R19 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R20 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R21 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R22 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R26 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R34 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R35 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R36 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R39 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R41 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R42 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R43 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R44 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R45 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R46 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R47 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R50 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R51 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R52 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R53 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R54 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R55 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R56 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R57 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R58 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R59 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R60 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
S.=Surface mount
R61 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R62 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R63 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R64 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R65 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R66 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R67 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R68 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R69 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R70 7030003790 S.RESISTOR ERJ3GEYJ 824 V (820 kΩ)
R71 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R72 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R73 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R74 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R75 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R76 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R77 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R78 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R79 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R80 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R81 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R82 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R83 7030003250 S.RESISTOR ERJ3GEYJ 270 V (27 Ω)
R84 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R85 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R86 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R87 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
C1 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C2 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C3 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C4 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C5 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C6 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C7 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C8 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C9 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C10 4030008890 S.CERAMIC C1608 JB 1C 273K-T-A
C11 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C12 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C13 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C14 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C18 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C20 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C21 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C22 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C23 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C24 4030007060 S.CERAMIC C1608 CH 1H 270J-T-A
C25 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C26 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C27 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C28 4030009650 S.CERAMIC C1608 CH 1H 240J-T-A
C29 4510005860
S.ELECTROLYTIC ECEV1HA2R2SR
C30 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C31 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C32 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
J1 6510015540 S.CONNECTOR B4B-ZR-SM3-TF
J2 6510018960 S.CONNECTOR B2B-PH-SM3-TB
J3 6510018960 S.CONNECTOR B2B-PH-SM3-TB
J4 6510022470 S.CONNECTOR 40FLT-SM1-TB
DS1 5030001950 LCD TTR5341
DS3 5040002310 S.LED SML-311YTT86
DS4 5040002310 S.LED SML-311YTT86
DS5 5040002310 S.LED SML-311YTT86
DS6 5040002310 S.LED SML-311YTT86
DS7 5040002660 S.LED FY1101F-TR (LED)
DS8 5040002660 S.LED FY1101F-TR (LED)
