Icom IC-M402

[MAIN UNIT]
S.=Surface mount
IC1 1140009280 S.IC µPD78F9418AGK-9EU (FX-2345D)
IC2 1110001810 S.IC TA7368F (TP1)
IC3 1110004490 S.IC M62429FP 700C
IC4 1120002830 S.IC NJM2125F-TE1
IC5 1180000420 S.IC TA78L05F (TE12R)
IC6 1180001250 S.IC TA7808F (TE16L)
IC7 1110004710 S.IC S-80928ANMP-DDR-T2
IC8 1130007420 S.IC TC7W14FU (TE12L)
IC9 1130006220 S.IC TC4W53FU (TE12L)
Q1 1560000810 S.FET 2SK1069-4-TL
Q2 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q3 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q4 1590001390 S.FET 2SJ144-Y (TE85R)
Q5 1590000430 S.TRANSISTOR DTC144EUA T106
Q6 1590000980 S.TRANSISTOR DTB123EK T147
Q9 1560000810 S.FET 2SK1069-4-TL
Q10 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q11 1510000510 S.TRANSISTOR 2SA1576A T106R
Q12 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
D1 1750000130 S.DIODE DA204U T107
D2 1160000060 S.DIODE DAN202U T107
D3 1750000550 S.DIODE 1SS355 TE-17
X1 6060000750 S.CERAMIC CSTCC4.91MG
R1 7030000270 S.RESISTOR MCR10EZHJ 120 Ω (121)
R2 7030000270 S.RESISTOR MCR10EZHJ 120 Ω (121)
R3 7030000280 S.RESISTOR MCR10EZHJ 150 Ω (151)
R6 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R7 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R8 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R9 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R10 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R11 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R12 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R13 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R14 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R15 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R16 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R17 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R18 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R19 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R20 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R21 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R22 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R23 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R24 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R25 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R26 7510001150 S.THERMISTOR NTCCM1608 4BH 103KC
R27 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R28 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R29 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R30 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R31 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R32 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R33 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R34 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R35 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R36 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R37 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R38 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R39 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R40 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R41 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R42 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R43 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R44 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R45 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R46 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R47 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R50 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R51 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R52 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R53 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R54 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R55 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R56 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R57 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R58 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R59 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R60 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R61 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R62 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R63 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R64 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R65 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R66 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R67 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R68 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R69 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R70 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω)
R75 7030000180 S.RESISTOR MCR10EZHJ 22 Ω (220)
R76 7030000180 S.RESISTOR MCR10EZHJ 22 Ω (220)
R77 7030000180 S.RESISTOR MCR10EZHJ 22 Ω (220)
C1 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C3 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C4 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C5 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C6 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C7 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C9 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C10 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C11 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C12 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C13 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C14 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C15 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C16 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C17 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C18 4510006250 S.ELECTROLYTIC ECEV1CA331UP
C22 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C23 4510005430
S.ELECTROLYTIC ECEV0JA220SR
C24 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C25 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C26 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C27 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C28 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C29 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C30 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C31 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C32 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C33 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C34 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C35 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C36 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C37 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C38 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C39 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C40 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C41 4510006250 S.ELECTROLYTIC ECEV1CA331UP
C42 4030008890 S.CERAMIC C1608 JB 1C 273K-T-A
C44 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C45 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C46 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C47 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C50 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C51 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C52 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C53 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C54 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
J1 6510019420 S.CONNECTOR B8B-ZR-SM3-TF
J2 6510021440 S.CONNECTOR B6B-ZR-SM3-TF
DS1 5030001900 LCD A0119 LCD36*28.5
DS2 5040002660 S.LED FY1101F-TR (LED)
DS3 5040002660 S.LED FY1101F-TR (LED)
DS4 5040002310 S.LED SML-311YTT86
DS5 5040002660 S.LED FY1101F-TR (LED)
DS6 5040002660 S.LED FY1101F-TR (LED)
