6 - 1
SECTION 6 PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[FRONT UNIT]
MC1 0800007890 MIC HM-150B ACC <FG> [BLK]
0800007900 MIC HM-150SW ACC <FG> [SW]
SP1 2510001240 SP 045P0803 <FG>
W1 7120000470 JMP ERDS2T0
W2 7120000470 JMP ERDS2T0
IC1 1140012751 S.IC M30220MA-137RP B 48.1/48.5
IC2 1110005770 S.IC S-80942CNMC-G9C-T2 B 79.7/48.8
IC3 1180000970 S.IC AN78L05M-(E1) B 55.3/20.8
IC4 1140008650 S.IC HN58X2464TI B 51.9/27.7
IC5 1110002700 S.IC NJM2904M-TE1 B 39.3/7.7
IC6 1170000350 S.IC PC357N6T B 77.2/11.6
IC7 1130007420 S.IC TC7W14FU (TE12L) B 22/44.5
Q1 1520000840 S.TR KTA1664Y-RTF/P B 74/18.8
Q2 1530003900 S.TR KTC4075 BL-RTK/P B 69.7/17.5
Q3 1530003900 S.TR KTC4075 BL-RTK/P B 69.7/21.3
Q4 1590003590 S.TR KRC414 RTK/P B 46.3/28.6
Q5 1530002280 S.TR 2SC4081 T106 S B 11.8/34.8
Q6 1590003580 S.TR KRC404 RTK/P B 15.6/34.6
Q7 1530002280 S.TR 2SC4081 T106 S B 22.7/49.7
Q8 1510000510 S.TR 2SA1576A T106R B 19.6/51
Q9 1560000810 S.FET 2SK1069-4-TL B 26.7/39.6
D1 1750001180 S.DIO KDS122 RTK/P B 47.5/25.8
D2 1750000550 S.DIO 1SS355 TE-17 B 83.7/11.4
D3 1750001180 S.DIO KDS122 RTK/P B 13.4/31.7
D4 1730002360 S.ZEN MA8062-M (TX) B 12.7/29.2
X1 6050011500 S.XTL CR-739 (9.8304 MHz) B 60.8/34
R1 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 54.2/37.2
R2 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 54.9/35.9
R3 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 56.2/38.3
R4 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 57.3/40.3
R5 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 63.2/40.4
R6 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 63.2/41.7
R11 7030005631 S.RES ERA3YKD 154V (150 k
Ω
) B 67.4/47.6
R12 7030005681 S.RES ERA3YKD 473V (47 k
Ω
) B 67.4/48.9
R13 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 64.2/33.4
R14 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) B 74/48.1
R15 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 71.4/48.1
R16 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k
Ω
) B 72.7/48.1
R17 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 59.4/54.7
R18 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 62/53.9
R19 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 60.7/53.3
R21 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 80.9/51.9
R22 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 76.7/48.1
R23 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 77/50.9
R25 7030010610 S.RES ERJ1TYJ 470U (47
Ω
) B 61.9/19.3
R31 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 51.9/33.6
R32 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 51.9/34.9
R35 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) B 45.3/25.9
R36 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 44/25.3
R37 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 44.5/31.3
R41 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) B 44.9/11.2
R42 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 44.2/6.4
R43 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 45.8/6.4
R45 7030005321 S.RES ERA3YED 103V B 33.2/7.7
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[LOGIC BOARD]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[LOGIC BOARD]
R46 7030008121 S.RES ERA3YED 682V B 34.5/7.7
R48 7030003860 S.RES ERJ3GE JPW V B 33.2/10.5
R51 7030003250 S.RES ERJ3GEYJ 270 V (27
Ω
) B 71.9/22.7
R52 7030003250 S.RES ERJ3GEYJ 270 V (27
Ω
) B 73.2/22.7
R53 7030003250 S.RES ERJ3GEYJ 270 V (27
Ω
) B 74.5/22.7
R60 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
) B 66.8/19.5
R61 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 66.8/16.9
R62 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 68.8/24
R63 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 69.7/19.4
R64 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) B 67.5/21.6
R71 7030003430 S.RES ERJ3GEYJ 821 V (820
Ω
) B 84.9/6
R72 7030003430 S.RES ERJ3GEYJ 821 V (820
Ω
) B 12.1/12.2
R73 7030003430 S.RES ERJ3GEYJ 821 V (820
Ω
) B 11.4/8.7
R74 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
) B 12.4/50.4
R75 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
) B 12.4/39
R76 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
) B 12.4/43.9
R81 7030003430 S.RES ERJ3GEYJ 821 V (820
Ω
) B 87.3/10
R82 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 21.4/39.5
R83 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 70.9/12
R85 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 12.7/27.5
R86 7030003210 S.RES ERJ3GEYJ 120 V (12
Ω
) B 11.2/31.7
R87 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 13.7/34.8
R88 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 14.4/36.8
R91 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 19.6/49.1
R92 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) B 24.8/48.8
R95 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 26.1/36.8
R96 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 24.8/36.8
R97 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 23.1/39.9
R101 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 19.1/14.6
R103 7030003860 S.RES ERJ3GE JPW V B 20.5/14.6
R104 7030003860 S.RES ERJ3GE JPW V B 22.6/16.6
R106 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 17/16.9
C1 4550006210 S.TAN ECST1CX106R B 56.3/30
C2 4030006900 S.CER C1608 JB 1H 103K-T B 55.6/33.7
C3 4030009650 S.CER C1608 CH 1H 240J-T B 57.5/35.5
C4 4030009650 S.CER C1608 CH 1H 240J-T B 57.5/38.3
C5 4030006860 S.CER C1608 JB 1H 102K-T B 88.9/39.3
C6 4030006850 S.CER C1608 JB 1H 471K-T B 88.9/42.2
C7 4030011600 S.CER C1608 JB 1E 104K-T B 37.3/55.1
C8 4030006860 S.CER C1608 JB 1H 102K-T B 36.6/34.4
C11 4030008920 S.CER C1608 JB 1H 473K-T B 68.7/43.1
C12 4030008920 S.CER C1608 JB 1H 473K-T B 68.4/44.4
C13 4030008920 S.CER C1608 JB 1H 473K-T B 67.7/46.1
C14 4030008920 S.CER C1608 JB 1H 473K-T B 67.4/50.2
C15 4030008920 S.CER C1608 JB 1H 473K-T B 64.1/50.8
C16 4030008920 S.CER C1608 JB 1H 473K-T B 65.4/50.8
C17 4030011600 S.CER C1608 JB 1E 104K-T B 62.8/51.2
C18 4030006900 S.CER C1608 JB 1H 103K-T B 70.6/50.2
C21 4030017480 S.CER C1608 JB 1A 474K-T B 78.3/51.9
C22 4030008890 S.CER C1608 JB 1H 273K-T B 79.6/51.9
C25 4510004630 S.ELE ECEV1CA100SR B 49.6/19.7
C26 4030006900 S.CER C1608 JB 1H 103K-T B 59.4/20.7
C27 4550006210 S.TAN ECST1CX106R B 58/25
C28 4030006900 S.CER C1608 JB 1H 103K-T B 54.4/25
C31 4030011600 S.CER C1608 JB 1E 104K-T B 52.8/32.3
C41 4030011600 S.CER C1608 JB 1E 104K-T B 36.5/11.2
C42 4030007170 S.CER C1608 CH 1H 221J-T B 42.1/11.2
C43 4030007010 S.CER C1608 CH 1H 100D-T B 39.3/11.2
C51 4510004630 S.ELE ECEV1CA100SR B 77.6/23.5
C52 4030006860 S.CER C1608 JB 1H 102K-T B 70.1/24
C54 4030011600 S.CER C1608 JB 1E 104K-T B 66.8/18.2
C81 4030012660 S.CER C1608 JB 1E 683K-T B 85.3/11.1
C82 4030006900 S.CER C1608 JB 1H 103K-T B 72.3/12
C83 4030011600 S.CER C1608 JB 1E 104K-T B 23/36.5
C86 4030011600 S.CER C1608 JB 1E 104K-T B 17.8/33.8
C87 4030006860 S.CER C1608 JB 1H 102K-T B 11.6/37
C88 4030006860 S.CER C1608 JB 1H 102K-T B 83.3/7.8
C89 4030006860 S.CER C1608 JB 1H 102K-T B 82.1/11.2
C90 4030006860 S.CER C1608 JB 1H 102K-T B 71.5/9.9
C91 4030011600 S.CER C1608 JB 1E 104K-T B 22.7/51.6
C95 4030011600 S.CER C1608 JB 1E 104K-T B 19.5/43.5
C101 4030006860 S.CER C1608 JB 1H 102K-T B 17/15.6
C102 4030006860 S.CER C1608 JB 1H 102K-T B 17/13.9
C103 4030006850 S.CER C1608 JB 1H 471K-T B 23.3/14.6
C104 4030006860 S.CER C1608 JB 1H 102K-T B 25.4/13.9
C111 4030006860 S.CER C1608 JB 1H 102K-T B 7.4/15.7
C112 4030006860 S.CER C1608 JB 1H 102K-T B 9/53
C113 4030006860 S.CER C1608 JB 1H 102K-T B 48.6/7.2
C114 4030006850 S.CER C1608 JB 1H 471K-T B 47.2/7.2
C121 4030006900 S.CER C1608 JB 1H 103K-T B 81.5/17.2
C122 4030007090 S.CER C1608 CH 1H 470J-T B 88.2/20.2
C123 4030006860 S.CER C1608 JB 1H 102K-T B 87.5/22.2
C124 4030007090 S.CER C1608 CH 1H 470J-T B 88.8/22.2
C125 4030006860 S.CER C1608 JB 1H 102K-T B 87.5/25
C126 4030007090 S.CER C1608 CH 1H 470J-T B 78.9/30.1
[REPLACEMENT UNITS]
ORDER NO. UNIT NAME
0328520101
0328520201
0328520102
U M422 #01 FRONT (FRONT+LOGIC+VR+SQL)
[BLK]
U M422 #02 FRONT (FRONT+LOGIC+VR+SQL)
[SW]
U M422 #01 MAIN (MAIN+CHASSIS)
6-1 IC-M422
