6 - 5
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
C331 4030006900 S.CER C1608 JB 1H 103K-T T 51.5/4.4
C332 4030006860 S.CER C1608 JB 1H 102K-T T 42.1/7.1
C333 4030006900 S.CER C1608 JB 1H 103K-T T 42.1/5.8
C334 4030007050 S.CER C1608 CH 1H 220J-T T 63.7/21.7
C335 4030006860 S.CER C1608 JB 1H 102K-T T 65/21.7
C336 4030006860 S.CER C1608 JB 1H 102K-T T 67/12.7
C337 4030007050 S.CER C1608 CH 1H 220J-T T 53.1/3
C338 4030006860 S.CER C1608 JB 1H 102K-T T 68.7/24.4
C339 4030007090 S.CER C1608 CH 1H 470J-T T 68.7/25.7
C340 4030007090 S.CER C1608 CH 1H 470J-T T 68.7/28.3
C341 4030007090 S.CER C1608 CH 1H 470J-T T 68.7/29.6
C342 4030006860 S.CER C1608 JB 1H 102K-T T 38/13.5
C343 4030006860 S.CER C1608 JB 1H 102K-T T 39.3/7.5
C344 4030011340 S.CER C1608 CH 1H 471J-T T 17.3/75.4
C345 4030011340 S.CER C1608 CH 1H 471J-T T 16/73.9
C346 4030006860 S.CER C1608 JB 1H 102K-T T 50.4/7.5
C347 4030007120 S.CER C1608 CH 1H 820J-T T 50.4/6.2
C348 4030007120 S.CER C1608 CH 1H 820J-T T 42.2/15.2
C349 4030006860 S.CER C1608 JB 1H 102K-T T 42.2/13.9
C351 4030006900 S.CER C1608 JB 1H 103K-T T 10.7/68.7
C352 4510005860 S.ELE ECEV1HA2R2SR T 15.5/69.2
C353 4030017490 S.CER C1608 JB 1A 105K-T T 5/72.8
C354 4030006860 S.CER C1608 JB 1H 102K-T T 4.1/74.8
C355 4510009210 ELE 16 WXA 470 M 8X9
C356 4510004590 ELE 16 MV 470 HC
C357 4030011600 S.CER C1608 JB 1E 104K-T T 18.6/74.9
C358 4030007090 S.CER C1608 CH 1H 470J-T T 4.1/77.7
C359 4030007090 S.CER C1608 CH 1H 470J-T T 5.4/77.7
C360 4030006860 S.CER C1608 JB 1H 102K-T T 9.2/61.9
C361 4030006860 S.CER C1608 JB 1H 102K-T T 10.6/61.9
C367 4030006860 S.CER C1608 JB 1H 102K-T T 35.6/78.5
C368 4030007090 S.CER C1608 CH 1H 470J-T T 32.4/81.9
C369 4510006021 ELE 2200 16V ME-HC
C370 4030011600 S.CER C1608 JB 1E 104K-T T 19.3/66.8
C373 4030007050 S.CER C1608 CH 1H 220J-T T 54.6/82.6
C374 4030007050 S.CER C1608 CH 1H 220J-T T 39.3/72.9
C375 4030007130 S.CER C1608 CH 1H 101J-T T 38/72.9
C376 4030011340 S.CER C1608 CH 1H 471J-T T 36.7/72.9
C377 4030007090 S.CER C1608 CH 1H 470J-T T 5.4/80.5
C378 4030006860 S.CER C1608 JB 1H 102K-T T 4.1/80.5
C379 4030007130 S.CER C1608 CH 1H 101J-T T 34.3/78.5
C380 4030011340 S.CER C1608 CH 1H 471J-T T 34.6/81.9
C381 4510006220 S.ELE ECEV1CA101UP T 4.5/56.3
C382 4030006900 S.CER C1608 JB 1H 103K-T T 6.3/62.5
C383 4030011600 S.CER C1608 JB 1E 104K-T T 5.7/65
C384 4030011600 S.CER C1608 JB 1E 104K-T T 7/67.8
C385 4030006900 S.CER C1608 JB 1H 103K-T T 5.7/67.8
C386 4510006220 S.ELE ECEV1CA101UP T 14.8/61.8
C387 4030011600 S.CER C1608 JB 1E 104K-T T 30/58.9
C388 4030006860 S.CER C1608 JB 1H 102K-T T 21.1/61.6
C389 4510004630 S.ELE ECEV1CA100SR T 24.9/63.8
C390 4030011600 S.CER C1608 JB 1E 104K-T T 32/56.4
C391 4030006860 S.CER C1608 JB 1H 102K-T T 30/60.2
C392 4510004630 S.ELE ECEV1CA100SR T 32.8/63.8
C393 4510004630 S.ELE ECEV1CA100SR T 39.6/65.6
C411 4030006900 S.CER C1608 JB 1H 103K-T T 39.9/24.3
C412 4030007090 S.CER C1608 CH 1H 470J-T T 37.2/22.7
C421 4510005860 S.ELE ECEV1HA2R2SR T 11.5/13.6
C422 4510005860 S.ELE ECEV1HA2R2SR T 10/23.8
C423 4030011600 S.CER C1608 JB 1E 104K-T T 8.4/10.7
C424 4030007090 S.CER C1608 CH 1H 470J-T T 2.4/20.5
C425 4030007090 S.CER C1608 CH 1H 470J-T T 2/12.8
C431 4030017480 S.CER C1608 JB 1A 474K-T T 4.4/21.5
C432 4030017490 S.CER C1608 JB 1A 105K-T T 5/27.8
C433 4030006860 S.CER C1608 JB 1H 102K-T T 4.1/29.8
C441 4030006860 S.CER C1608 JB 1H 102K-T T 26.8/67.9
C443 4510004590 ELE 16 MV 470 HC
C444 4510004590 ELE 16 MV 470 HC
C445 4030011600 S.CER C1608 JB 1E 104K-T T 5.4/32.6
C446 4030007090 S.CER C1608 CH 1H 470J-T T 4.1/32.6
J2 6510015540 S.CNR B4B-ZR-SM3-TF T 79.5/12.5
J3 6510015540 S.CNR B4B-ZR-SM3-TF T 37.7/27.2
J4 6510021720 S.CNR 30FLT-SM1-TB T 46/10.5
J5 6510021720 S.CNR 30FLT-SM1-TB T 62.9/16.5
W1 7120000470 JMP ERDS2T0
W2 9091201210 WIR 74/98/050/X99/X99
W3 7120000470 JMP ERDS2T0
W4 8900014020 CBL OPC-1439 <TJM>
W5 8900014020 CBL OPC-1439 <TJM>
W6 7120000470 JMP ERDS2T0
EP2 9033003901 TUB IRRAX 1.0 (d) L=2 mm
EP3 6910017290 TUB IRRAX 1.5 (d) L=30 mm
EP341 6910014690 S.BEA MPZ1608S221A-T T 9.9/63.9
EP342 6910014690 S.BEA MPZ1608S221A-T T 10/66.7
EP441 6910014690 S.BEA MPZ1608S221A-T T 9.4/34.1
EP442 6910014690 S.BEA MPZ1608S221A-T T 7.4/35.7
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R1 7210003220 VAR TP96N97A-15.7SK-10KB-2852
W1 8900014010 CBL OPC-1442
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[SQL BOARD]
R1 7210003150 VAR TP96N97-15SK-10KB-2685
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[CHASSIS PARTS]
[VR BOARD]
J1 6510004880 CNR MR-DS-E 01
W1 8900014000 CBL OPC-1405 <TJM>
W2 8900014090 CBL OPC-1489
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
R1 7010007590 RES 12K R20
R2 7010007600 RES 6.8K R20
R3 7010007610 RES 15K R20
R4 7010007620 RES 33K R20
C1 4030018660 S.CER 0.022 C1608 16V B B 40.9/43.6
MC1 7700002640 MIC KUC3523-040245
S1 2260002780 SW SKHHLPA010
S2 2260002790 SW KHHAMA010
S3 2260002790 SW KHHAMA010
S4 2260002790 SW KHHAMA010
W1 9027150010 W 71/98/010/X98/X98
W2 9027150010 W 71/98/010/X98/X98
W3 9027150020 W 24/00/020/W01/W01
W4 9027150030 W 24/04/020/W01/W01
6-2 HM-150B/SW
