M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
R106 7510001651 S.THM NTCG16 4BH 222JT T 72.3/75
R107 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) T 72.3/76.3
R108 7030003860 S.RES ERJ3GE JPW V T 62.8/78.5
R111 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 69.4/69.4
R112 7310005020 S.TRI RH03ADC14X (10 k
Ω
) T 73.8/69
R113 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
) T 78/69.5
R114 7030003360 S.RES ERJ3GEYJ 221 V (220
Ω
) T 77.6/78
R115 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 79.6/76.6
R116 7030003390 S.RES ERJ3GEYJ 391 V (390
Ω
) T 74.3/75.5
R121 7030005420 S.RES ERJ3GEYJ 202 V (2 k
Ω
) T 84.4/82.1
R122 7030005420 S.RES ERJ3GEYJ 202 V (2 k
Ω
) T 83.1/82.1
R123 7030005420 S.RES ERJ3GEYJ 202 V (2 k
Ω
) T 88.5/74.4
R124 7030005420 S.RES ERJ3GEYJ 202 V (2 k
Ω
) T 86.5/75.2
R125 7030001120 S.RES MCR50JZHJ 82
Ω
(820) T 83.4/69.7
R126 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) T 105.4/93.6
R127 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) T 78.3/75.9
R128 7030003690 S.RES ERJ3GEYJ 124 V (120 k
Ω
) T 78.3/73.1
R146 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 110.5/57.1
R147 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 106.4/57.4
R149 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 112.2/49.2
R150 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
) T 111.2/55
R151 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 113.3/54.4
R152 7030003260 S.RES ERJ3GEYJ 330 V (33
Ω
) T 111.6/46.6
R153 7030004050 S.RES ERJ3GEYJ 1R0 V (1
Ω
) T 107.3/54.4
R154 7030003410 S.RES ERJ3GEYJ 561 V (560
Ω
) T 107.3/55.9
R155 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 100/59.5
R171 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 94/61.6
R172 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 90.5/62.2
R173 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 98.7/59.5
R176 7030003820 S.RES ERJ3GEYJ 155 V (1.5 M
Ω
) T 81.2/57.7
R177 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 79.9/61.9
R178 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 76.6/59.4
R179 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 115.7/61
R180 7030003250 S.RES ERJ3GEYJ 270 V (27
Ω
) T 118/57.5
R181 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 79.9/57.7
R182 7030003200 S.RES ERJ3GEYJ 100 V (10
Ω
) T 81/49.9
R183 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 79.5/48.6
R185 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) T 81.9/44.9
R201 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) T 84.9/27.6
R202 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) T 86.3/27.6
R203 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 84.2/24.8
R204 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) T 82.5/24.8
R205 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k
Ω
) T 96.7/30.9
R206 7030003390 S.RES ERJ3GEYJ 391 V (390
Ω
) T 85.6/30.4
R208 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) T 87.3/18.4
R209 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) T 90.6/21
R211 7030003760 S.RES ERJ3GEYJ 474 V (470 k
Ω
) T 96.3/21.8
R212 7030003430 S.RES ERJ3GEYJ 821 V (820
Ω
) T 100.5/21.8
R213 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 101.9/21.8
R214 7310005040 S.TRI RH03ADCJ4X (22 k
Ω
) T 99.6/26.1
R215 7510001671 S.THM NTCG16 4BH 103JT T 103.3/24.6
R216 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 104.7/21.8
R217 7030003710 S.RES ERJ3GEYJ 184 V (180 k
Ω
) T 104.7/24.6
R218 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) T 103.3/27.4
R219 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) T 103.3/30.2
R222 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
) T 76.4/21.7
R223 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
Ω
) T 78.3/24.3
R224 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 80.1/24.3
R225 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) T 79.3/18.7
R226 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) T 76.6/18.7
R231 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 104/13.7
R232 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) T 104/8.1
R233 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 102.6/13.7
R234 7030003760 S.RES ERJ3GEYJ 474 V (470 k
Ω
) T 102.6/10.9
R235 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) T 105.4/10.9
R236 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
) T 101.2/10.9
R237 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
Ω
) T 99.8/10.9
R238 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 99.8/7.9
R239 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 97/7.9
R240 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 95.6/7.9
R241 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 13.8/23
R242 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 10.3/30.4
R243 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 13.8/21.7
R244 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 16.6/23
R245 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 16.1/35.1
R246 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 10.3/29.1
R247 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 16.1/33.8
R248 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 20.5/20.5
R249 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 28.9/29
R250 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 21.8/20.5
R251 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 22.7/22.5
R252 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 19.2/20.5
R253 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 17.9/20.5
R254 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 16.7/9.1
R256 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 19.3/9.1
R257 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
Ω
) T 23.2/12
R258 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 20.6/9.1
R259 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 21.9/9.1
R262 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 27.7/10.4
R263 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 26.4/8.3
R264 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k
Ω
) T 32.8/11.8
R265 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 30.6/13.5
R266 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 30.3/20
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
R267 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 30.2/22.1
R268 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 31.6/20
R269 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 32.8/13.1
R271 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
) T 113.4/36
R272 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 119/37.3
R273 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 116.2/37.3
R274 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 116.2/36
R275 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 116.2/30.8
R276 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 119/34.7
R277 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 119/33.4
R282 7030003760 S.RES ERJ3GEYJ 474 V (470 k
Ω
) T 114.3/27.1
R283 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) T 107.9/24.3
R284 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 118.9/16.4
R285 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
) T 118.9/20.3
R286 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) T 118.9/21.6
R287 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
Ω
) T 118.9/22.9
R292 7030003790 S.RES ERJ3GEYJ 824 V (820 k
Ω
) T 18.9/53.3
R293 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 18.9/54.7
R294 7030003200 S.RES ERJ3GEYJ 100 V (10
Ω
) T 34.1/49.3
R295 7030006091 S.RES ERA3YED 822V (8.2 k
Ω
) T 17.7/56.8
R301 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 22.9/49.1
R302 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 22.9/50.5
R303 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 21.4/46.3
R304 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) T 18.5/47
R305 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 18.9/51.9
R306 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 18.5/45.6
R307 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
) T 21.4/43.1
R308 7030003770 S.RES ERJ3GEYJ 564 V (560 k
Ω
) T 18.5/43.1
R309 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 18.9/50.5
R311 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 18.5/40.3
R312 7030003610 S.RES ERJ3GEYJ 273 V (27 k
Ω
) T 21.4/41.7
R313 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 25.7/41.7
R314 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
) T 24.2/40.3
R315 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) T 28.5/40.3
R316 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) T 31.3/40.3
R317 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) T 34.1/41.7
R318 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 25.7/44.9
R319 7030003610 S.RES ERJ3GEYJ 273 V (27 k
Ω
) T 27.2/51.9
R320 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 28.5/49.1
R321 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
Ω
) T 25.7/49.1
R323 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 36.8/45.2
R324 7510001671 S.THM NTCG16 4BH 103JT T 39.1/47.2
R325 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 36.5/47.2
R326 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) T 37.8/47.2
R327 7310005030 S.TRI RH03ADCS4X (47 k
Ω
) T 36.9/38.4
R328 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k
Ω
) T 43.2/40.3
R341 7030003860 S.RES ERJ3GE JPW V T 21.4/38.9
R353 7030003770 S.RES ERJ3GEYJ 564 V (560 k
Ω
) T 9.4/70.6
R354 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) T 11.9/71.3
R355 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 7.4/70.6
R356 7030000100 S.RES MCR10EZHJ 4.7
Ω
(4R7) T 18.6/72.7
R382 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 21.5/59.5
R383 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 21.5/56.7
R384 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 25.3/59.5
R385 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 25.3/56.7
R386 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) T 36.5/68.3
R387 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) T 36.5/65.5
R403 7030003860 S.RES ERJ3GE JPW V T 53.2/7
R404 7030003860 S.RES ERJ3GE JPW V T 54.7/4.3
R411 7030003860 S.RES ERJ3GE JPW V T 40.6/21.2
R413 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) T 33/30.1
R415 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) T 75.3/8.3
R416 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) T 74/15.4
R417 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) T 80.1/7.5
R421 7030003860 S.RES ERJ3GE JPW V T 9.1/17.4
R423 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 8.5/27.8
R424 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 4.1/26
R431 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 6.2/24.3
R432 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 2.4/23.8
R433 7030000100 S.RES MCR10EZHJ 4.7
Ω
(4R7) T 7.8/31.9
R441 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 21/69.4
R442 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 22.9/71.3
C1 4030008880 S.CER C1608 JB 1H 223K-T T 65.8/30.9
C2 4030006900 S.CER C1608 JB 1H 103K-T T 63/25.7
C3 4030011600 S.CER C1608 JB 1E 104K-T T 63/24.4
C4 4550000510 S.TAN TEESVA 1V 473M8L T 61.8/37.7
C5 4550006560 S.TAN ECST1CY225R T 55.4/37.7
C7 4030006860 S.CER C1608 JB 1H 102K-T T 53.1/27.7
C11 4030007020 S.CER C1608 CH 1H 120J-T T 51.3/35.1
C12 4610001590 S.TRI TZC3R100A110R00 T 47.8/35.3
C13 4030007040 S.CER C1608 CH 1H 180J-T T 51.3/33.8
C20 4030006860 S.CER C1608 JB 1H 102K-T T 41.2/53.9
C21 4510004630 S.ELE ECEV1CA100SR T 72.7/37.2
C22 4030006900 S.CER C1608 JB 1H 103K-T T 55.6/43.2
C23 4030006860 S.CER C1608 JB 1H 102K-T T 44.3/49
C24 4030011340 S.CER C1608 CH 1H 471J-T T 44.2/56.4
C26 4030006900 S.CER C1608 JB 1H 103K-T T 44.2/44.5
C27 4030017490 S.CER C1608 JB 1A 105K-T T 40.4/40.3
C29 4030011340 S.CER C1608 CH 1H 471J-T T 49.8/55
C31 4030011340 S.CER C1608 CH 1H 471J-T T 63.6/47.9
To Next Page
Loading...
