R9
R10
• Idling current pre-setting
• Idling current adjustment
L6
PA1–PA4 boards
Connect the lead of L6 to ground
L5
Connect the lead of L5
to ground
4 - 3
Front side (after removed front panel)
Ammeter
WS1
ID ALC and ID meter check point
R56
R57
Meter maximum point adjustment
Switch board
FRONT
SIDE
PA-1 BOARD
PA-2 BOARD
PA-3 BOARD
PA-4 BOARD
SW BOARD
FRONT
SIDE
• Idling current adjustment
• Meter maximum point adjustment
