Icom IC-PW1 Service Manual

S.=Surface mount
IC1 1110001340 S.IC NJM3403AM-T1
IC2 1110000960 S.IC NJM4558M-T1
IC3 1110000960 S.IC NJM4558M-T1
IC4 1110000960 S.IC NJM4558M-T1
IC5 1180001070 S.IC TA7805F (TE16L)
IC7 1140003610 S.IC X24C04S8-2.7T6
IC8 1180001260 S.IC BA9700AF-T1
IC9 1110000960 S.IC NJM4558M-T1
IC10 1130003920 S.IC TC4S69F (TE85R)
IC11 1130003920 S.IC TC4S69F (TE85R)
IC12 1140004120 S.IC M38022M2-138FP
IC13 1110001550 S.IC S-8054ALB-LM-T1
IC14 1160000130 S.IC TD62783AF (TP1)
IC15 1110004510 S.IC TD62597AFN (EL)
IC16 1130001880 S.IC µPD4069UBG-T1
IC17 1140004450 S.IC X24C01AS-3.0T6
IC18 1160000130 S.IC TD62783AF (TP1)
IC19 1160000130 S.IC TD62783AF (TP1)
IC20 1130008410 S.IC TC74AC393F (EL)
IC21 1110000960 S.IC NJM4558M-T1
IC25 1110001550 S.IC S-8054ALB-LM-T1
IC26 1140007690 S.IC TMP90PM38F
IC27 1130003760 S.IC TC4S81F (TE85R)
IC28 1140003830 S.IC TC4W66F (TE12L)
IC30 1130007430 S.IC TC7S14FU (TE85R)
IC31 1110000960 S.IC NJM4558M-T1
IC33 1130005820 S.IC TC4S584F (TE85R)
Q1 1510000780 S.TRANSISTOR 2SA1586-Y (TE85R)
Q2 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q3 1520000530 S.TRANSISTOR 2SB1119S-TD
Q4 1590002310 S.TRANSISTOR DTC114EE TL
Q5 1520000530 S.TRANSISTOR 2SB1119S-TD
Q6 1590002310 S.TRANSISTOR DTC114EE TL
Q7 1520000530 S.TRANSISTOR 2SB1119S-TD
Q8 1590002310 S.TRANSISTOR DTC114EE TL
Q9 1520000530 S.TRANSISTOR 2SB1119S-TD
Q10 1520000530 S.TRANSISTOR 2SB1119S-TD
Q11 1520000530 S.TRANSISTOR 2SB1119S-TD
Q12 1520000530 S.TRANSISTOR 2SB1119S-TD
Q13 1520000530 S.TRANSISTOR 2SB1119S-TD
Q14 1520000530 S.TRANSISTOR 2SB1119S-TD
Q15 1520000530 S.TRANSISTOR 2SB1119S-TD
Q16 1590002310 S.TRANSISTOR DTC114EE TL
Q17 1590002310 S.TRANSISTOR DTC114EE TL
Q18 1590002310 S.TRANSISTOR DTC114EE TL
Q19 1590002310 S.TRANSISTOR DTC114EE TL
Q20 1590002310 S.TRANSISTOR DTC114EE TL
Q21 1590002310 S.TRANSISTOR DTC114EE TL
Q22 1590002310 S.TRANSISTOR DTC114EE TL
Q23 1510000780 S.TRANSISTOR 2SA1586-Y (TE85R)
Q24 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q25 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q26 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q27 1520000530 S.TRANSISTOR 2SB1119S-TD
Q28 1590002310 S.TRANSISTOR DTC114EE TL
Q29 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q30 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q32 1590002310 S.TRANSISTOR DTC114EE TL
Q33 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q34 1530002370 S.TRANSISTOR 2SC2714-O (TE85R)
Q35 1560000270 S.FET 2SK302-Y (TE85R)
Q36 1590002310 S.TRANSISTOR DTC114EE TL
Q100 1590002310 S.TRANSISTOR DTC114EE TL
Q101 1520000580 S.TRANSISTOR 2SB1124S-TD
Q102 1590002310 S.TRANSISTOR DTC114EE TL
Q103 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q104 1590002310 S.TRANSISTOR DTC114EE TL
Q105 1590002310 S.TRANSISTOR DTC114EE TL
Q106 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q107 1590002310 S.TRANSISTOR DTC114EE TL
Q108 1590002310 S.TRANSISTOR DTC114EE TL
Q109 1590002310 S.TRANSISTOR DTC114EE TL
Q111 1590002310 S.TRANSISTOR DTC114EE TL
D1 1790001640 S.DIODE 1SS373 (TPH3)
D2 1790000620 S.DIODE MA77 (TX)
D3 1790000620 S.DIODE MA77 (TX)
D4 1730000680 S.ZENER RD4.7M-T2B2
D6 1730000680 S.ZENER RD4.7M-T2B2
D7 1790001640 S.DIODE 1SS373 (TPH3)
D8 1790001640 S.DIODE 1SS373 (TPH3)
D11 1750000270 S.DIODE 1SS301 (TE85R)
D12 1750000270 S.DIODE 1SS301 (TE85R)
D13 1750000290 S.DIODE 1SS300 (TE85R)
D14 1750000290 S.DIODE 1SS300 (TE85R)
D15 1790001130 S.DIODE D2FS4-4063
D16 1790000620 S.DIODE MA77 (TX)
D17 1790000620 S.DIODE MA77 (TX)
D18 1790000620 S.DIODE MA77 (TX) [USA] only
D20 1790000620 S.DIODE MA77 (TX)
D21 1790000620 S.DIODE MA77 (TX)
D23 1730000410 S.ZENER RD5.1M-T2B2
D24 1730000410 S.ZENER RD5.1M-T2B2
D26 1750000270 S.DIODE 1SS301 (TE85R)
D27 1790000620 S.DIODE MA77 (TX)
D50 1790000620 S.DIODE MA77 (TX)
D51 1790000620 S.DIODE MA77 (TX)
D52 1750000270 S.DIODE 1SS301 (TE85R)
D54 1790000620 S.DIODE MA77 (TX)
D55 1790000620 S.DIODE MA77 (TX)
D56 1790001640 S.DIODE 1SS373 (TPH3)
D59 1790001640 S.DIODE 1SS373 (TPH3)
D60 1790001640 S.DIODE 1SS373 (TPH3)
D61 1750000270 S.DIODE 1SS301 (TE85R)
D62 1750000290 S.DIODE 1SS300 (TE85R)
D63 1750000270 S.DIODE 1SS301 (TE85R)
D66 1790001130 S.DIODE D2FS4-4063
D67 1790001640 S.DIODE 1SS373 (TPH3)
D68 1790001640 S.DIODE 1SS373 (TPH3)
D69 1790000620 S.DIODE MA77 (TX)
D70 1790001640 S.DIODE 1SS373 (TPH3)
D71 1790000620 S.DIODE MA77 (TX)
D72 1750000270 S.DIODE 1SS301 (TE85R)
D73 1750000270 S.DIODE 1SS301 (TE85R)
D75 1750000270 S.DIODE 1SS301 (TE85R)
D76 1790001640 S.DIODE 1SS373 (TPH3)
X1 6050009890 S.XTAL CR-569 (6.144 MHz)
X2 6050009870 S.XTAL CR-567 (9.8304 MHz)
L1 6200003260 S.COIL NL 322522T-101J
L2 6200003260 S.COIL NL 322522T-101J
L3 6200003260 S.COIL NL 322522T-101J
L4 6200003260 S.COIL NL 322522T-101J
L5 6200003260 S.COIL NL 322522T-101J
L6 6200003260 S.COIL NL 322522T-101J
L7 6200003260 S.COIL NL 322522T-101J
L8 6200003260 S.COIL NL 322522T-101J
L9 6200001830 S.COIL NL 322522T-100J
L10 6200001830 S.COIL NL 322522T-100J
L11 6200003260 S.COIL NL 322522T-101J
L12 6200003260 S.COIL NL 322522T-101J
L13 6200003260 S.COIL NL 322522T-101J
L14 6200003260 S.COIL NL 322522T-101J
L15 6200003260 S.COIL NL 322522T-101J
L16 6200003260 S.COIL NL 322522T-101J
L17 6200001830 S.COIL NL 322522T-100J
L19 6200003260 S.COIL NL 322522T-101J
L21 6200003260 S.COIL NL 322522T-101J
L22 6200003260 S.COIL NL 322522T-101J
L24 6200003260 S.COIL NL 322522T-101J
L25 6200003260 S.COIL NL 322522T-101J
L27 6200001830 S.COIL NL 322522T-100J
L28 6140002220 COIL LR-270
L29 6190000220 COIL S0971136-101K
L30 6200003260 S.COIL NL 322522T-101J
L31 6200003260 S.COIL NL 322522T-101J
L32 6200003260 S.COIL NL 322522T-101J
L35 6140002220 COIL LR-270
5 - 1
SECTION 5 PARTS LIST
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
